CCD Specifications

KAF 0400

Detection Mode
High Signal to
Noise
High Dynamic
Range
High Sensitivity
* Binning must be a minimum of 2 pixels in the parallel and serial direction to reach the maximum ADC signal.
34
SenSys User Manual
H x V: 768 x 512
Pixel Size: 9µm x 9µm
Gain Relative
Setting Gain
1
1
≈
/
x
2
≈1x
2
≈4x
3
50
40
30
20
10
0
400 500
Typical QE Curve (not installed in camera)
QE response in the 200-400 nm range can be enhanced with Photometrics' proprietary Metachrome II coating.
Typical
Noise System Gain
- ≈40e -
26e /ADU
- ≈20e -
19e /ADU
- ≈5e -
13e /ADU
600 700
Wavelength (nm)
Typical Maximum ADC
Signal
-
160Ke (binned full well*)
-
80Ke (single pixel full
well)
-
20Ke (high sensitivity)
800 900 1000
