Welcome to Toshiba Setting the Colour System �������������������39 Setting the external input skip �������������39 • Thank you for purchasing this Toshiba LCD Colour TV. Labeling video input sources ���������������40 This manual will help you use the exciting features of Using REGZA-LINK ��������������������������40 your new TV�...
Introduction Attach the TV to the stand with the 3) Never stand or climb on the TV. mounting screw provided, or secure the TV • Educate children about the dangers of to the level surface using the strap if fitted, climbing on furniture to reach the TV or its or to a wall using a sturdy tie to the clip controls.
Page 4
Introduction 7) Never place the TV near a heater or in 11) Precautions for installing on outdoor aerial direct sunlight. An outside aerial system should not be The surface of the cabinet or power cord may located in the vicinity of overhead power lines, melt and result in a fire or an electric shock.
Page 5
Introduction These items may cause a fire or an electric shock. If these objects are inserted inside the TV, turn off the TV and remove the power plug from the outlet immediately and contact a service technician. Be especially careful that children do not insert objects in the TV.
Exemptions cloth. • Toshiba is not liable for any damage caused by fires, This dust may cause a fire due to reduced natural disaster (such as thunder, earthquake, etc�), acts insulation on the plug.
Introduction Trademark Information WAS ENCODED BY A CONSUMER ENGAGED IN A PERSONAL AND NONCOMMERCIAL • Manufactured under license from Dolby Laboratories. ACTIVITY AND/OR WAS OBTAINED FROM A Dolby and the double-D symbol are trademarks of VIDEO PROVIDER LICENSED TO PROVIDE AVC Dolby Laboratories�...
• Never mix battery types or combine used batteries Your Toshiba dealer or service personnel can best advise with new ones. you on which aerial to use in your area� Before connecting the aerial cable, turn off all main power Notes: switches�...
Getting started TV panel controls • You can operate your TV using the Touch Keys on the front of the panel or the remote control. The back and side of the panel provide the terminal connections to connect other equipment to your TV ( - “Connecting your TV” pages 49 – 82)� •...
Page 10
Getting started TV back and left side view * You can use the cable holders to hold the aerial cable, video and audio VIDEO RGB/PC cables etc. (AUDIO) Never grasp the holders HDMI 3 when moving the TV. (Headphone jack) — For use with headphones o HDMI 3 (input terminal) only —...
Getting started Learning about the remote control Location of controls To access “TOSHIBA PLACES” Top Page Power on/Standby To select TV mode Input source selection To display the channel list To access the Quick Menu Switch the Audio Description This button turns the sound off/on...
Page 12
Getting started Location of controls for REGZA-LINK To select input from external source To change volume of AV amplifier To operate menu To exit menu To return to previous menu accessed Press to STOP Press to PLAY Press to PAUSE Press to SKIP BACK Press...
Getting started Turning the TV on Press OK , to display the Location menu ( - page 19)� Switching on the TV Press v or w to select Home or Store � For normal home use, select Home � Connect the power cord to a wall outlet� The ! power Location indicator light should be red (standby mode)�...
Getting started Quick menu item example Press v or w to view the DTV (digital channel) or ATV (analogue channel) lists� Mode Quick menu item Description Auto Tuning Picture Mode - page 23� DTV Services Found : 7 ATV Services Found : 12 Picture Size - page 22�...
Movie Jump to Movie menu Music Jump to Music menu Media Player Setup Media Player Setup Menu Toshiba Places Jump to Toshiba Places Function Photo Frame Jump to Photo Frame On Timer On Timer Menu Sleep Timer Sleep Timer Menu...
Getting started ATV Manual Tuning - analogue - Programming channels into the Use the Manual Tuning operation if desired channels TV’s channel memory cannot be preset by Auto Tuning or if you would like to preset channels to specific position numbers one by one. Auto Tuning From the System Setup menu, press s or r to Auto Tuning will completely re-tune the TV and can be...
Page 18
Getting started DTV Manual Tuning G. Search operation - digital - Press r to search up the band or s to search This feature is available for service engineers or can be used down the band� for direct channel entry if the multiplex channel is known� Press s or r repeatedly until your desired channel is displayed�...
Page 19
Getting started Channels Sort Line No. 1/10 Sorting Type Number Pos. Name Sort Press v or w to set the sorting rule� Number mode: Position No� order (numerical sequence) A-Z Sort mode: Station name order (A to Z) Line Number Jump — Press the Number button Press s to select Sort and press OK �...
Getting started Watching TV programmes System Setup Menu Language English Auto Tuning Antenna ATV Manual Tuning Programme Selection DTV Manual Tuning DTV Settings Quick Setup Digital programmes Auto Location USB 2 Port Setup Recorder After you have tuned the TV, you have several ways to navigate through all programmes: Displaying the on-screen information •...
Getting started • Teletext availability ( Press v or w to select On or Off � • Subtitle availability ( HDMI signal information is as follows: • Parental rating: G, PG, M, MA, AV, R, etc. Resolution, Scan Type, Frame Rate*, Aspect, Bit •...
Using the TV’s features (General) • Most of the picture/sound controls and functions are Cinema available in both digital and analogue modes� However, When watching “all sides panel format” films/video tapes, features not available will be greyed out� this setting will eliminate or reduce the black bars on all sides of the screen by zooming in and selecting the image without distortion�...
Using the TV’s features (General) PC Wide From the Display Settings in the Preferences Use this setting for a PC connected via HDMI or RGB/ menu, press s or r to select Picture Position � PC terminal when receiving PC signal format� This setting will display the image without picture clipping�...
Using the TV’s features (General) Using ClearScan 400Hz • To set another Picture Mode, use the Picture menu. This function eliminates motion blur without adding flicker or reducing image brightness and improves the Activating the picture preferences viewing quality of a motion picture� You can customise current Picture Mode settings as From the Advanced Picture Settings menu, press desired�...
Page 25
Using the TV’s features (General) Resetting Base Colour Adjustment Press OK to confirm the adjustment. The reset function returns base colour adjustment to the To cancel the adjustment when selecting a point, select factory settings� Cancel and press OK � To return the settings of all points to the factory From the Base Colour Adjustment menu, press defaults, select Reset and press OK �...
Using the TV’s features (General) Press s to select Level and press v or w to adjust Press s or r to select Test Pattern � the level� Press v or w to select On or Off � Notes: • This feature may not work properly depending on RGB Filter the content.
Page 27
Using the TV’s features (General) When 2P is selected: Press s , r , v or w and input the values to fill all RGBxy matrix table� Press s to select 2P White Balance � Highlight Start and press OK � Please wait until you Press s or r to select Red-Offset , Green-Offset , see “Manual Colour Calibration has been completed”...
Using the TV’s features (General) Sound From the Expert Picture Settings menu, press s Dual Dual 1 or r to select Reset and press OK � Balance Advanced Sound Settings A confirmation screen appears. Select Yes , press OK � Dolby Volume Dynamic Range Control Audio Level Offset...
Page 29
Using the TV’s features (General) Using Dolby Volume From the Sound menu, press s or r to select Advanced Sound Settings and press OK � This feature provides a consistent sound volume regardless of programmes, channels or input sources� Press s or r to select Sound Navigation and press OK �...
Using the TV’s features (General) Headphone Settings Other feature settings This setting is used to set the sound output when headphones are connected� Activating Blue Screen With the Blue Screen function On , the screen will Speaker Headphone Speakers automatically turn blue and the sound will be muted when Link no signal is being received�...
3D video images, remove the 3D indisposed while viewing 3D images� glasses and discontinue use until the condition Contact the Toshiba Call Center for repair of your 3D is eliminated. glasses� • Viewing in 3D may cause dizziness and/or •...
Page 32
Using the TV’s features (General) Therefore, to avoid injury do not place your TV near Notes on handling the 3D glasses’ liquid crystal open stairwells, balconies, or wires� shutter lenses Also do not sit near objects that could be broken if •...
Page 33
To set the 3D glasses: (which are not included): When you use for the first Peel off • Compatible Toshiba 3D glasses (only one supplied). time, peel off the protective • Compatible 3D playback device or 3D source. films from the lenses.
Using the TV’s features (General) • There will be restrictions on the Picture Size settings for 3D Mode and 3D to 2D Mode. • There are individual differences in perception of 3D images. • When viewing 3D images, wear the 3D glasses. •...
Page 35
Using the TV’s features (General) The 3D button's operation: Trigger of Switching The 3D key’s behaviour when in Native mode is different Display Mode Quick menu depending on the input mode� Input Signal Depending on the input mode, the screen for selecting 2D Additional Source Type...
Page 36
Using the TV’s features (General) Note: Press v or w to select Side by Side , Top and Depending on the input mode, the display mode Bottom or Native � switches between 2D and 3D. Trigger of Switching Quick menu Setting the Auto Start mode Display Mode 2D Format Select...
Using the TV’s features (General) Enter your 4-digit 3D PIN code and press s or r to Press s or r to select 2D to 3D Depth and press highlight 3D Start Message and press v or w to OK � select On or Off �...
Using the TV’s features (General) Press P u to advance to the next page, or press P U to When all the details have been entered, select Done and press OK to start the timer� go back to the previous page� Note: To cancel the On Timer When a timed programme is about to start, an...
Using the TV’s features (General) HDMI 1, HDMI 2, HDMI 3, HDMI 4 (HDMI input), Channel List PC ( o RGB/PC, PC input) Notes: Press the LIST button� The Channel List will appear� • If a REGZA-LINK device is connected to an HDMI input, the REGZA-LINK icon will appear.
This feature uses CEC (Consumer Electronics Controls) Side Shared Audio EXT 2 HDMI 3 Audio Digital technology and allows the control of Toshiba REGZA- HDMI Settings LINK compatible devices from the TV remote control via Digital Audio Output HDMI connection ( - page 54)�...
Using the TV’s features (General) Initial Speaker Setting • The proper function may not work when operating the AV amplifier. This feature allows the Initial Speaker Setting to be set to TV Speakers or Amplifier � The Amplifier option REGZA-LINK input source selection allows the remote control to adjust or mute the volume of the external audio�...
Please refer to the owner’s manual for all the connected devices. In LIST mode, you will see the page numbers currently stored for each colour button� To connect the Toshiba PC compatible with REGZA-LINK Sub-pages This feature automatically adjusts the suitable widescreen...
B To hold a specific page: Toshiba dealer� At times it is convenient to hold a page of text� Press B and B will appear in the top left of the screen� The page Using LIST mode will be held on screen until the button is pressed again�...
Using the TV’s features (General) Subtitle and Audio Selecting Subtitles - digital - In digital mode, this feature will show subtitles on the screen in the selected language provided they are being broadcast. From the DTV Settings menu, press s or r to select Subtitle and Audio and press OK . Press s or r to select Subtitle Display and use v or w to select On or Off .
Other Digital TV features and settings Locking Channels Using the EPG (Electronic Locking Channels stops the viewing of digital Programme Guide) channels� Locked channels can only be accessed by entering the PIN� When you press GUIDE , the EPG content created by Select a channel you want to lock in your channel list�...
Press s or r to select Auto Upgrade � Press OK to display the System Information � Use v or w to select On or Off � System Information TOSHIBA Searching for New Software 2011 x.x.x.x Xxx xx 2011 - xx:xx:xx XX:xx...
Other Digital TV features and settings Network Upgrade Press OK to display Digital Audio Format menu TOSHIBA may offer upgrades for the TV’s software in and press s or r to select an option� the future� Audio Format: The TV’s software is upgraded via the Network�...
Other Digital TV features and settings Dynamic Range Control This feature allows control of audio compression for digital TV programmes excluding those with MPEG-1 and MPEG-2 audio� From the Sound menu, press s or r to select Dynamic Range Control � Press v or w to select On or Off �...
Connecting your TV Connecting an audio system • Most of the picture/sound controls and functions are - digital - available in both digital and analogue modes� However, You can enjoy high quality dynamic sound by connecting features not available will be greyed out� the TV to an audio system�...
Connecting your TV You can enjoy dynamic realistic sound by connecting the This input is designed to accept HDCP programme TV to an amplifier equipped with a Dolby Digital decoder material in digital from CEA-861-D compliant consumer or Dolby Digital processor� When using this setup, select electronic devices (such as a set top box and DVD player Auto in the Digital Output menu ( - page 47)�...
Connecting your TV HDMI’s ARC (Audio Return Channel) feature Back and left side of TV This feature enables the audio signal of the TV to be sent to the AV amplifier via the HDMI cable. It will not be necessary to connect a cable from the audio output of the TV to the audio input of the AV amplifier to reproduce the audio received from the tuner of the TV through the AV amplifier.
Connecting your TV Setting the HDMI 3 audio mode Connecting a computer (PC) You can select from three sound modes for an HDMI or Connecting a PC to the RGB/PC terminal on the TV: DVI device connected to the HDMI 3 input terminal: An analogue RGB (15 pin) computer cable can be Auto , Digital or Analogue �...
Page 53
Connecting your TV • If the edges of the picture are stretched, re-adjust Back and left side of TV the picture position adjustments in the PC Settings menu. • Depending on the specification of the PC you are using the DVD-Video playing and the DVD’s title, some scenes may be skipped, or you may not be able to pause during multi-angle scenes.
HDMI cables with the HDMI Logo ( • This function is limited to models incorporating Toshiba’s REGZA-LINK. However, Toshiba is not liable for those operations. Refer to the individual owner’s manuals for compatibility information.
Reset Press s or r to select the option you want to adjust� The LAN port allows your Toshiba TV to connect to Press v or w to adjust the settings as desired� your home network. You can use this revolutionary home...
Because Wireless LAN products operate within the guidelines found in radio frequency safety standards and recommendations, TOSHIBA believes Wireless LAN is safe for use by consumers� These standards and recommendations reflect the consensus of the scientific...
Connecting your TV In some situations or environments, the use of Wireless Network Name, Authentication, and Encryption are LAN may be restricted by the proprietor of the building decided based on information from the AP. You will or responsible representatives of the organization� Such manually set the Security Key�...
Page 58
Connecting your TV To cancel searching for the AP: Press s or r to select Authentication and press v Press BACK while searching for the AP� A message will or w to select Open System , Shared Key , WPA- appear and press v or w to select Yes and press OK �...
Connecting your TV Wireless Information Note: Even if an AP for IEEE 802.11n is used when The settings configured in Wireless Setup can be Encryption is set to WEP or TKIP, the Speed value confirmed. might be low. It is recommended that Encryption be changed to AES.
Connecting your TV Note: Manual setup: Other items will be greyed out when Auto Setup is From the Preferences menu, select Network set to On. Setup and press OK � Manual Setup: Press s or r to select Advanced Network Setup From the Preferences menu, select Network and press OK �...
The maximum number of O P Q R S T U characters is 16� V W X Y Z Note: Toshiba does not guarantee normal operation with Input operation on the remote control: all connected devices. Button Description Terminology: DMS: DLNA CERTIFIED™...
(- page 45). of the value of Maximum Volume Setup. • When DMR playback ends, the TV volume will Press Menu and v or w to select the Toshiba return to the value in effect when DMR playback Places menu�...
Page 63
• You cannot post videos to service included in the page� If you select , see “To use the Drag Mode" Toshiba Places from this TV. Please use a PC to on this page� post videos. To use the Pointer: ON: •...
Page 64
Connecting your TV To use the Drag Mode: Item Description Press s or r to select Pointer: ON and press OK � Image Sets display/non-display of images� Table Sets effect/non-effect of tables� Press the BLUE button� Sets effect/non-effect of CSS� From the Function menu, press v or w to select Japanese Sets effect/non-effect of the Japanese hyphenation�...
CA Certificates , and press OK � owners to download or use copyrighted content� TOSHIBA cannot and does not grant such permission� Press s or r to select the desired certificate: • When OK is pressed, a detailed information window Basic operation will appear�...
Connecting your TV Selecting a file in the list of content: Press w to select Done and press OK to save� Press s , r , v or w to select a file or folder. Notes: • Up to 8 DMSs can be selected. Press OK to move to the next layer, or press BACK to •...
Connecting your TV Single View Settings Interval Time and Repeat: In this mode, only files located in the selected directory Press QUICK to open the Quick Menu � will be displayed� This view allows you to change the photo content manually� When moving from Multi View Press s or r to select Interval Time or Repeat �...
Connecting your TV Displaying the device information During playback: • Press W / w to pause� Press QUICK to open the Quick Menu from Multi You can move to the desired replay position by pressing View mode� v or w during PAUSE � PAUSE or operations during PAUSE may not be Press s or r to select Device Information �...
Page 69
Connecting your TV ® Item Description The DivX VOD window will appear and you will see the deactivation code� For details on registration, File Name File sorting rules: ® please visit the DivX website at http://vod�divx�com� (USB) 1� Unicode priority ABOUT DIVX VIDEO : DivX is a digital video format ®...
Connecting your TV The title is changed cyclically each time the RED button CC or cc may not be available depending on the is pressed� Playback will start from start time of selected content, DMC or DMS� title every s or r � •...
Connecting your TV Note: Press OK � The preview screen will appear� Sorting may not be supported by some DMSs. Photo Frame Setup Displaying the device information Press QUICK to open the Quick Menu in list mode� Press s or r to select Device Information � Note: Photo Select Start...
Connecting your TV Press s , r v or w to select the photo you want Set the following items as desired� to copy from the USB storage device or DLNA Clock : Press v or w to select Off , Digital Clock , CERTIFIED™...
Connecting your TV Using the USB HDD function Press v or w to select Yes and press OK � The formatting confirmation window will appear. Notes: Press v or w to select Yes and press OK � • You cannot watch one channel while recording Registration will start�...
Page 74
Connecting your TV To record DTV programmes (One Touch Date: Select the date for programmed recording� Recording) Start Time: You can easily record the programme currently being Select the time to start recording� viewed� End Time: Press ● REC � Select the time to end recording�...
Page 75
Connecting your TV To check a schedule Press s or r on the Programme Timer screen to check the schedule� To edit a schedule Press s or r on the Programme Timer screen to select the title whose schedule you want to edit and press OK Press v or w to select a day tab or Personal Mode The Set Timer screen will appear�...
Connecting your TV To protect or unprotect a recorded programme Press v or w to select the Personal Mode to which Protecting a programme prevents it from being you want to register the title and press OK � accidentally deleted� The title will be registered to the selected Personal Select the title of the programme you want to protect and Mode �...
Connecting your TV Press s or r to select One Touch Recording Press s or r to select Device List and press OK � Time � The Device List screen will appear� Recording Setup Device List One Touch Recording Time Programme End Time Connected Device Name...
Connecting your TV The recorded Recording Information list will appear� • When End Padding Time is set for the first programmed recording ( - page 77), depending on how (yellow) icon will appear next to unread far the scheduling times overlap, the End Padding Recording Information�...
Page 79
Connecting your TV Motion Detection Function Personal Identification accuracy can be enhanced by registering your face under various lighting • Motion detection may be affected by the surrounding environments� environment, such as the brightness of the room� In - Whether or not you are wearing glasses� If you wear addition, very slight, small or momentary movement glasses, we recommend that you register your face may be undetected�...
Connecting your TV Note: Facial Recognition If the Camera Sensor Mode is in Energy After registering faces beforehand for each Personal Saving mode, this feature will be greyed out. Mode , the Welcome Window will be displayed when the camera detects a corresponding face� The Personal Name Press s or r to select Time until Standby and corresponding to the detected face will be displayed in the press s or r to adjust the time in step of 5 min up to...
Page 81
Connecting your TV Edit Name My Face You can edit the name of your Personal Mode. Press s or Are you sure you want to register? r to select Edit Name and press OK � Edit the desired name by using the software keyboard ( - page 61)� The maximum number of characters is 25�...
• Charging the mobile phone from the TV. Interoperability with MHL devices of other manufacturers • Two-way remote operation between the TV and the is not guaranteed� Toshiba does not provide any guarantee, mobile phone� therefore, against operational failure such as that described below when an MHL source is connected to the TV�...
Reference section No REGZA-LINK operation Troubleshooting • The REGZA-LINK feature is available for Toshiba REGZA-LINK compatible devices� Before calling a service technician, please check the following • Make sure HDMI cables with the HDMI logo are used. table for a possible cause of the symptom and some solutions�...
Reference section MHL operation • Try to reconnect MHL cable. • Tune the TV's AC power off and on again. • Tune the MHL device power off and on again. • During the TV on mode, connect MHL device for the TV�...
Page 85
Reference section Media Media File Video/Audio codec USB DMS Note Player Format Extension Movie MPEG-2 PS �mpg Video) MPEG-1 Video <USB> �mpeg Maximum number of files: 2000 per folder Video) MPEG-2 Video <DMS> H�264 (MPEG-4 AVC) Maximum number of files: 2000 per folder Audio) MPEG-1 Layer1 MPEG-1 Layer2 *) Some files may not be played.
Page 86
Reference section Media Media File Video/Audio codec USB DMS Note Player Format Extension Music �mp3 Audio) MPEG-1 Audio <USB> Layer-3 Maximum number of files: 2000 per folder MPEG-2 Audio Layer-3 <DMS> MPEG-2�5 Audio Layer-3 Maximum number of files: 2000 per folder �mp4 Audio) AAC *) Some files may not be played.
Page 87
Reference section Signal Class Table C mode RF Frequency [MHz] RF Frequency [MHz] RF Frequency [MHz] 48�25 687�25 252�25 55�25 695�25 259�25 62�25 703�25 266�25 175�25 711�25 273�25 182�25 719�25 280�25 189�25 727�25 287�25 196�25 735�25 294�25 203�25 743�25 303�25 210�25 751�25 311�25...
Page 88
Reference section 3D signal formats Aspect Pixel Clock Resolution V. Frequency H. Frequency 3D Structure ratio Frequency Side by Side (Full) 720 × 480p 16:9 59�940/60�000 Hz 31�469/31�500 kHz 27�000/27�027 MHz Side by Side (Half) Top and Bottom Side by Side (Full) 720 ×...
1080i (50/60 Hz) Integrated Digital LCD TV (These signal formats are converted to match the number of pixels of the LCD panel�) Model 55WL800AZ Colour system (analogue TV system) PAL, SECAM, NTSC 3�58/4�43 Power source AC 220 V-240 , 50 Hz...
