- Page 1 Questions? See us on the World Wide Web at www.dewalt.com INSTRUCTION MANUAL DW744XP-XE HEAVY-DUTY 254 MM (10") JOB SITE TABLE SAW...
-
Page 2: Safety Instructions
14. Disconnect tool . Definitions: Safety Guidelines Shut off power and wait for the tool to come to a complete standstill before leaving it unattended. Unplug the The definitions below describe the level of severity for each signal word. Please read the manual and pay tool when not in use, before servicing or changing accessories. -
Page 3: Package Contents
In spite of the application of the relevant safety regulations and the implementation of safety devices, certain residual risks cannot be avoided. These are: – Impairment of hearing. – Risk of accidents caused by the uncovered parts of the rotating sawblade. –... -
Page 4: Assembly And Adjustment
• Before replacing the top cover of the mains plug ensure that the cable restraint (3) is holding the outer sheath of the cable firmly and that the leads are correctly fixed at the terminal screws. WARNING: Never use a light socket. Never connect the live (L) or neutral (N) wires to the earth pin marked E or For 115 V units with a power rating exceeding 1500 W, we recommend to fit a plug to BS4343 standard. - Page 5 Parallel Adjustment (fig. A2, D) For optimum performance, the blade must be parallel to the mitre slots. This adjustment has been made at the factory. To re-adjust: 1. Place the unit in upright position. 2. Using a 10 mm socket wrench, slacken the bracket fasteners (25) slightly (fig.
- Page 6 WARNING: The mounting surface must have a 350 x 500 mm opening to allow dust to escape. Rail lock adjustment (fig. A1, J) The rail lock has been factory-set. If you need to re-adjust, proceed as follows: 1. Lock the lock lever (12) by pushing it down (fig. A1). 2.
-
Page 7: Basic Saw Cuts
BASIC SAW CUTS WARNING: • Connect a suitable dust extraction device during all sawing Ripping (fig. A1, A2, M1, M2) operations. • Whenever possible, connect a dust extraction device WARNING: Sharp edges. designed in accordance with the relevant regulations 1. Set the blade to 0°. regarding dust emission. -
Page 8: Specifications
Unwanted Tools and the Environment Specifications Take your tool to an authorized DEWALT repair agent where it will DW744XP-XE bedisposed of in an environmentally safe way. Voltage 220-240 Service Information Motor power (input) 2000 Motor power (output) 1300 Please have the following information available for all service calls:... - Page 12 20 Fletcher Road, Mooroolbark, VIC 3138 Australia (03 8720 5100) • 5 Te Apunga Place, Mt Wellington, New Zealand (0800 339258) (AUG08) Part No. 662700-00 DW744XP-XE Copyright © 2008 D WALT The following are trademarks for one or more D WALT power tools: the yellow and black color scheme;...
