JBL EON15-G2 Specifications

Technical Manual
JBL EON15-G2

SPECIFICATIONS

ACOUSTIC & ELECTRICAL SPECIFICATIONS:
• Power Capacity:
• Frequency Range:
• Sensitivity:
• Crossover Frequency:
SYSTEM COMPONENTS:
• Low Frequency
Transducer:
• DC Resistance:
• High Frequency
Transducer:
• DC Resistance:
• Input 1 Sensitivity:
PACKAGE
Cord, AC
Line 120V
425-00000-00
Use 321101-001
JBL Incorporated, 8500 Balboa Boulevard, P.O. Box 2200, Northridge, California 91329 U.S.A.
300 Watts @ Low Frequency
Driver Impedance.
100 Watts @ High Frequency
Driver Impedance
39 Hz – 18 kHz (± 10dB)
129 dB SPL, 1 Watt @ 1 Meter
1.5 kHz
Integral Frame with one 15" (380 mm)
Driver, Dual Neodymium Magnet, 2"
Differential-Drive Voice Coil
1.4 ohm ±10%
JBL 2418H-1 1" (Throat Dia.)
Compression Driver with 1.75 Dia.
Titanium Diaphragm. Ferro-fluid Cooled.
3.7 ohm ±10%
-44 dBu to -22 dBu for Rated Output
(Mic/Line Switch in Mic Position)
-12 dBu to +20 dBu for Rated Output
(Mic/Line Switch in Line Position)
Warranty 59660
Owners Manual
981-00059-00
Filler
991-00050-00
SLV, W/MIC
CUTOUTEON 15'S
Bag
32259-001
Bottom Tray
991-00051-00
Carton
990-00213-00
SYSTEM COMPONENTS:
• Input 2 & 3 Sensitivity:
• Output Level:
• Audio Connectors:
AURAL SWEEP TEST SPECIFICATIONS:
A. System Aural Sweep Test:
B. L.F. Aural Sweep Test:
C. H.F. Aural Sweep Test:
PHYSICAL SPECIFICATIONS:
• Enclosure Dimensions:
• Shipping Weight:
WARRANTY INFORMATION:
• Refer to Warranty Statement packed with each product.
WIRING DIAGRAM
Speaker, High Freq
2418H-1
Diaph Repl
D8R2418-1
WHT
BLUE
(SEE SCHEMATIC PAGES)
(CONT'D)
-18 dBu to +20 dBu for Rated Output
+20 dBu (peak), Loop/Mix Switch in
MIX position.
Input 1: XLR/F Balanced
Input 2 & 3: 1/4" Phone, Balanced
(TRS)
200mv input RMS, pot at 1/2, tone
flat.
4.0V Input, 20 Hz to 4 kHz
1.0V Input, 200 Hz to 1200 Hz
686mm x 430mm x 444mm D
(27.0 x 17.0 x 17.5 in. D)
46 lbs. (21 kg.)
EON15-G2LF
Cone Repl
C2REON15P-2
RED
BLK
Amplifier Assy
339555-001
06-11
