Everpure Insurice PF Single – i2000 Installation And Operation Manual

Description

Everpure Insurice PF Series Water Filter Systems (Figures 1-3) are identical to standard
Insurice systems except that the PF Series systems include a 20" sediment prefilter housing
pre-installed and assembled onto the inlet header/manifold assembly. Insurice PF systems
are designed for use in installations with dirtier, cloudier source water and incorporate the
same Everpure Insurice 1⁄2 micron Quick-Change precoat filter cartridges (I2000, I2000
& I4000 ) which remove potentially harmful particulates and chlorine taste and odor from the
2
water while introducing an advanced scale inhibitor. – As tested by Everpure
The replaceable prefilter cartridge element removes larger dirt and rust particles and extends
the life of the sub-micron carbon filters. Thus, ice quality and ice machine performance are
improved while machine downtime, maintenance and energy costs are substantially reduced.

selecting A Mounting locAtion

1. Give consideration to the weight of the unit when operating (filled with water). Operating
weights of the Insurice PF Systems are:
• Single System - 19 lbs. (8.62 kg.)
• Twin System - 35 lbs. (15.9 kg)
• Triple System - 45 lbs. (20.4 kg)
2. The location should allow for:
• M inimum clearance of 2
replacement.
• Adequate space for "in" and "out" water line connections.
• B e near a drain for flushing.

operAting specificAtions*

combined Model name
Insurice PF Single – i2000
Insurice PF Single – i2000
2
Insurice PF Twin – i2000
Insurice PF Twin – i2000
2
Insurice PF Triple – i2000
Insurice PF Triple – i2000
2
Insurice PF Single – i4000
Insurice PF Single – i4000
2
Insurice PF Twin – i4000
Insurice PF Twin – i4000
2
Insurice PF Triple – i4000
Insurice PF Triple – i4000
2
* For individual cartridge specifications, refer to cartridge literature.
temperature: 35-100°F (2-38°C)
pressure: 10 - 125 psi (0.7 - 8.6 bar), non-shock
For cold water use only.
Manufactured by Everpure
⁄ " under the cartridge(s) so it can be lowered for removal and
1
2
replacement
flow rate
cartridge
i2000 1.67 gpm (6.3 Lpm)
i2000 1.67 gpm (6.3 Lpm)
2
i2000 3.3 gpm (12.6 Lpm)
i2000 3.3 gpm (12.6 Lpm)
2
i2000 5.0 gpm (18.9 Lpm)
i2000 5.0 gpm (18.9 Lpm)
2
i4000 1.67 gpm (6.3 Lpm)
i4000 1.67 gpm (6.3 Lpm)
2
i4000 3.3 gpm (12.6 Lpm)
i4000 3.3 gpm (12.6 Lpm)
2
i4000 5.0 gpm (18.9 Lpm)
i4000 5.0 gpm (18.9 Lpm)
2
Installation and Operation Guide
, I4000
2
capacity
9,000 gal (34,050 L)
9,000 gal (34,050 L)
18,000 gal (68,100 L)
18,000 gal (68,100 L)
27,000 gal (102,150 L)
27,000 gal (102,150 L)
12,000 gal (45,400 L)
12,000 gal (45,400 L)
24,000 gal (90,800 L)
24,000 gal (90,800 L)
36,000 gal (136,200 L)
36,000 gal (136,200 L)
Insurice PF Filter Systems
Figure 1 – Insurice PF Single System
Figure 2 – Insurice PF Twin System
Figure 3 – Insurice PF Triple System
EV3119-03 Rev A MR08
