1020
1220
1 Specifications
2 About Your Thermostat
3 Installation
4 System Testing
Warning
Attention
Read all instructions before proceeding.
This thermostat requires 24 Volt AC Power or two (2) properly installed
"AA" Alkaline batteries for proper operation. When connecting 24 Volt
AC Power the batteries may be installed as a backup.
For use only as described in this manual. Any other use
will void warranty.
1 Specifications
This thermostat is compatible with:
• Single stage heat / cool conventional and heat pump systems
• Conventional systems up to 2 heat / 2 cool (1220 only)
• Single compressor heat pump systems with an auxiliary heat stage (1220 only)
• 250 – 750 millivolt heat only systems
Electrical and control specifications:
• Electrical Rating: 24 Volt AC
• 1 amp maximum load per terminal
• AC Power: 18 – 30 Volts AC
• DC Power: 3.0 Volt DC (2 "AA" Alkaline Batteries Included)
• Control Range: 45° – 90° F (7° – 32° C)
• Temperature Accuracy: +/- 1° F (+/- .5° C)
Terminations
• 1020 – Rc, Rh, O, B, Y1, W1, G, C
• 1220 – Rc, Rh, O, B, Y1, Y2, E/W1, G, W2, C
Single Stage Heat / Cool
Conventional and Heat Pump
Up to 2 Heat / 2 Cool
Conventional and Heat Pump
Model number is located on back of thermostat
5 Setting User Options
6 Operating Your Thermostat
7 Additional Operation Features
8 Thermostat Maintenance
Turn off power to the heating or cooling
equipment before installation.
For installation by experienced service
technicians only.
®
Detailed
Installer Guide
1020W-100-01
Advertisement
Table of Contents
Related Manuals for Braeburn 1020
Summary of Contents for Braeburn 1020
- Page 1 ® Detailed Non-Programmable Installer Guide Thermostats Single Stage Heat / Cool 1020 Conventional and Heat Pump Up to 2 Heat / 2 Cool 1220 Conventional and Heat Pump Model number is located on back of thermostat 1 Specifications 5 Setting User Options...
-
Page 2: About Your Thermostat
2 About Your Thermostat Room Temperature ... Displays the current room temperature Reset Button ..... R esets thermostat back to factory defaults Low Battery Indicator ..Indicates when the batteries need to be replaced System Switch .... S elects system preference Quick Reference Instructions ...... S tored in slot at top of thermostat Fan Indicator ....Indicates when the system fan is running System Status Indicator . .. D isplays information about the status of the system Arrow Buttons .... - Page 3 Install your new Braeburn thermostat in 5 basic steps: 1 Install the Sub-Base 2 Provide Power 3 Connect Your Wires 4 Set Installer Switches 5 Attach Thermostat to Sub-Base Install the Sub-Base: • Remove the sub-base from the body of the thermostat. • Mount the sub-base as shown below: Drill 3/16” pilot holes in your desired location. Use supplied anchors for drywall or plaster. NOTE: After sub-base installation, you may insert the quick reference card into the slot on the top of the base.
- Page 4 Connect Your Wires Wiring Terminations Terminal Function Description Rc Input 24 Volt AC Cooling Transformer (Dual Transformer Systems Only) Rh Input Power Connection (24 Volt AC Heating Transformer or Millivolt Power Source) O Output Reversing Valve (Cool Active) B Output Reversing Valve (Heat Active) Y1 Output Compressor Relay G Output Fan Control W1 Output Conventional Heat Relay C Input 24 Volt AC Transformer Common Additional Terminations (1220 only) Terminal Function Description...
-
Page 5: Heat Pump Systems
Conventional Systems (cont.) 2 HEAT / 2 COOL Single or Dual Transformer (1220 Only) Set System Type to CONV 24 Volt AC Power (heating transformer) [note 2] 24 Volt AC Power (cooling transformer) [note 2] Heat Relay Stage 1 Heat Relay Stage 2 Compressor Relay Stage 1 Compressor Relay Stage 2 [note 4] Fan Relay 24 Volt AC Transformer Common [note 1, 3] NOTES - Conventional Systems [1] If batteries are installed the 24 Volt AC common connection is optional [2] Remove factory installed jumper for dual transformer systems [3] In dual transformer systems, transformer common must come from cooling transformer [4] Connect Y2 only if a second cooling compressor is being used Provide disconnect and overload protection as required. - Page 6 Heat Pump Systems (cont.) NOTES - Heat Pump Systems [1] If batteries are installed the 24 Volt AC common connection is optional. [2] Select O for cool active or B for heat active. [3] Install a field supplied jumper between the W2 and E terminals if there is no separate emergency heat relay installed. Provide disconnect and overload protection as required. Set Installer Switches Factory Setting Switch Default Options Comments CONV Select for conventional systems CONV / HP CONV HP Select for heat pump systems Select for fahrenheit temperature scale F / C Select for celsius temperature scale HG Select for gas heat...
-
Page 7: System Testing
4 System Testing Warning Read Before Testing • Do not short (or jumper) across terminals on the gas valve or at the heating or cooling system control board to test the thermostat installa- tion. This could damage the thermostat and void the warranty. • Do not select the COOL mode of operation if the outside temperature is below 50º F (10º C). This could possibly damage the controlled cool- ing system and may cause personal injury. • This thermostat includes an automatic compressor protection feature to avoid potential damage to the compressor from short cycling. When testing the system, make sure to take this delay into account. NOTE: The compressor delay can be bypassed by pressing the reset button on the front of the thermostat. All user settings will be returned to factory default. -
Page 8: Operating Your Thermostat
Table of User Options User Factory Setting Options Default Options Comments 0.5, 1.0 1 1st stage Select a 1st stage temperature or 2.0 differential differential of .5˚, 1˚ or 2˚F (.25˚, 5˚ or 2˚C) 1.0, 2.0, 2 2nd stage Select a 2nd stage temperature 3.0, 4.0, differential differential of 1˚, 2˚, 3˚, 4˚, 5˚ or 6˚F 5.0 or 6.0 (.5˚, 1˚, 1.5˚, 2˚, 2.5˚ or 3˚C) (1220 Only) Detailed Explanation of User Options: Temperature Differential (User Option 1 and 2) The differential setting is the temperature control range that your thermostat... -
Page 9: Additional Operation Features
Temperature Adjustment Press the or button to adjust the current set point temperature. Status Indicators Status indicators appear in the display to let you know if your system is heating, cooling or off. HEAT ON Indicates your heating system is running. COOL ON Indicates your cooling system is running. Additional Status Indicators (Model 1220 Only): Indicates that the auxiliary stage of heating is running (Multi-Stage Systems only). EMER Indicates that the emergency heating system is running (Heat Pump Systems only). Resetting the Thermostat This thermostat provides you with a reset button that will erase all of your user settings and programming. To reset the thermostat, use a small object such as a tooth pick or paper- clip and gently press the button located inside the small hole on the front of the thermostat housing labeled “reset”. 7 Additional Operation Features Compressor Protection This thermostat includes an automatic compressor protection delay to avoid potential damage to your system from short cycling. This feature activates a short delay after turning off the system compressor. -
Page 10: Limited Warranty
3. Make sure to correctly position the (+) and (-) symbols. 4. Gently push thermostat body back onto base. Thermostat Cleaning Never spray any liquid directly on the thermostat. Using a soft damp cloth wipe the outer body of the thermostat. Never use any abrasive cleansers to clean your thermostat. For troubleshooting tips, visit braeburnonline.com. Store this manual for future reference Limited Warranty When installed by a professional contractor, this product is backed by a 5 year limited warranty. Limitations apply. For limitations, terms and conditions, you may obtain a full copy of this warranty: YEAR · Visit us online: www.braeburnonline.com/warranty · Phone us: 866.268.5599 LIMITED WARRANT Y · Write us: Braeburn Systems LLC 2215 Cornell Avenue Montgomery IL 60538 ® Braeburn Systems LLC 2215 Cornell Avenue • Montgomery, IL 60538 Technical Assistance: www.braeburnonline.com Call us toll-free: 866-268-5599 (U.S.) 630-844-1968 (Outside the U.S.) ©2012 Braeburn Systems LLC • All Rights Reserved • Made in China Patents Pending • 1020W-100-001...
