Braeburn 1200NC Detailed User Manual

Non-programmable thermostats, single stage heat/cool conventional and heat pump, up to 2 heat/1 cool conventional and heat pump
Hide thumbs Also See for 1200NC:

Advertisement

Table of Contents

See also: Instruction Manual , User Manual
Enlarged version
Non-Programmable
Thermostats
Single Stage Heat / Cool
1000NC
Conventional and Heat Pump
Up to 2 Heat / 1 Cool
1200NC
Conventional and Heat Pump
Model number is located on back of thermostat
1 Specifications
2 About Your Thermostat
3 Installation
4 System Testing
Warning
Turn off power to the heating or cooling
equipment before installation.
Attention
For installation by experienced service
technicians only. Follow applicable codes.
Read all instructions before proceeding.
This thermostat requires 24 Volt AC Power or two (2) properly installed
"AA" Alkaline batteries for proper operation. When connecting 24 Volt
AC Power the batteries may be installed as a backup.
For use only as described in this manual. Any other use
will void warranty.
1 Specifications
This thermostat is compatible with:
Electrical and control specifications:
Terminations
®
Detailed
User Guide
5 Setting User Options
6 Operating Your Thermostat
7 Additional Operation Features
8 Thermostat Maintenance
1000NCW-100-12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1200NC and is the answer not in the manual?

Questions and answers

How do you change the battery?
April 25, 2025

How to change the battery

0

Related Manuals for Braeburn 1200NC

Summary of Contents for Braeburn 1200NC

  • Page 1 User Guide Single Stage Heat / Cool 1000NC Conventional and Heat Pump Up to 2 Heat / 1 Cool 1200NC Conventional and Heat Pump Model number is located on back of thermostat 1 Specifications 5 Setting User Options 2 About Your Thermostat...

  • Page 2: About Your Thermostat

    2 About Your Thermostat Room Temperature Arrow Buttons System Switch Backlight Button Low Battery Indicator System Status Indicator Reset Button Fan Switch Battery Compartment 3 Installation Warning Disconnect power before beginning installation. Thermostat Location...
  • Page 3 Install your new Braeburn thermostat in 5 basic steps: Install the Sub-Base: Drill 3/16” pilot holes in your desired location. Use supplied anchors for drywall or plaster. Provide Power 24VAC Power Terminal (C) For 24 Volt AC power For primary or back-up power...

  • Page 4: Connect Your Wires

    Connect Your Wires Wiring Terminations Terminal Function Description Additional Terminations (1200NC only) Terminal Function Description Conventional Systems Typical Wiring Configurations NOTE: The “Installer Switch” option will be configured in the next step. Heat Only or Millivolt Set Installer Switch to NORM...

  • Page 5: Heat Pump Systems

    1 HEAT / 1 COOL - No Auxiliary Heat Set Installer Switch to HP O or B [note 2] [note 1] 2 HEAT / 1 COOL - Including Auxiliary Heat (1200NC only) Set Installer Switch to HP O or B [note 2] [note 3]...

  • Page 6: Attach Thermostat To Sub-Base

    Heat Pump Systems (cont.) NOTES - Heat Pump Systems W2 and E Provide disconnect and overload protection as required. Set Installer Switches Factory Setting Switch Default Options Comments NOTE: The reset button should be pressed after making any changes to the installer switches.

  • Page 7: System Testing

    4 System Testing Warning Read Before Testing NOTE: The compressor delay can be bypassed by pressing the reset button on the front of the thermostat. All user settings will be returned to factory default. SYSTEM SYSTEM SYSTEM SYSTEM 5 Setting User Options Advanced User Options To access the User Options menu, hold down both the buttons...

  • Page 8: Operating Your Thermostat

    HEAT Additional Switch Position (Model 1200NC Only): EMER NOTE: If your model 1200NC was set to a con- ventional system (NORM) then you will not have the EMER (emergency heat) option and “NO AUX SET” will flash in the display if EMER is selected with the system switch.

  • Page 9: Additional Operation Features

    Temperature Adjustment Status Indicators HEAT COOL Additional Status Indicators (Model 1200NC Only): Resetting the Thermostat 7 Additional Operation Features Compressor Protection 8 Thermostat Maintenance Changing the Batteries If batteries are installed and they become low, a low battery indicator will appear in the display.

  • Page 10: Limited Warranty

    NOTE: We recommend replacing the thermostat batteries annually or if the thermostat will be unattended for an extended period of time. Thermostat Cleaning For troubleshooting tips, visit braeburnonline.com Store this manual for future reference. Limited Warranty ® 1000NCW-100-12...

This manual is also suitable for:

1000nc
