Dell Inspiron 700m Service Manual page 35

11. Replace the keyboard.
12. Insert the battery into the battery bay, or connect the AC adapter to your computer and an electrical outlet.
13. Turn on the computer.
To confirm the amount of memory installed in the computer, click the Start button, click Help and Support, and then click Computer Information.
Replacing a Modem
CAUTION: Before performing any of the procedures listed below, read and follow the safety instructions in the Product Information Guide.
NOTICE: Read "Before Working Inside Your
1. Ensure that the work surface is flat and clean to prevent scratching the computer cover.
2. Save and close any open files, exit any open programs, and then shut down the computer.
3. Disconnect the computer from the electrical outlet.
4. Wait 10 to 20 seconds and then disconnect any attached devices.
5. Remove the battery, any installed PC Cards or blanks, and devices.
NOTICE: Handle modules by their edges, and do not touch the components on a module. Ground yourself by touching a metal connector on the back of
the computer, and continue to do so periodically during this procedure.
6. Turn the computer over and loosen the two captive screws on the modem cover, and remove the cover.
1 Mini PCI card and modem
cover
2 captive screws (2)
7. If a modem is not already installed, go to step 10.
8. If you are replacing a modem, remove the existing modem:
a. Remove the two M2 x5-mm screws securing the modem to the system board, and set them aside.
b. Pull straight up on the attached pull-tab to lift the modem out of its connector on the system board, and disconnect the modem cable.
Computer" before performing the following procedure.
