INSTALLATION
AND
OPERATING
INSTRUCTIONS
Save these
instructions
for future use
Note: Please read these instructions
thoroughly before attempting to install
this unit.
Model
9100
Manual #7715
REV 111204
ATTENTION INSTALLER: Leave this manual with appliance
© 2004 HEARTLAND APPLIANCES INC.
WARNING: Improper installation, adjustment, alteration, service or
maintenance can cause injury or property damage. Refer to this
manual. For assistance or additional information, consult a qualified
installer, service agency, manufacturer (dealer) or the gas supplier.
Note : This appliance can only be installed in the state of
Massachusetts by a Massachusetts licensed plumber or gasfitter.
The oven door thermometer does not sense temperature. It is for
aesthestics only and is nonfunctional.
These symbols on the nameplate mean the product has been
design certified by American Gas Association Laboratories and
Canadian Gas Association Laboratories.
MODEL 9100/7100
GAS RANGE
Bus. (519) 650-5501 Fax (519) 650-3773
Model
7100
1050 Fountain St. N.
Cambridge, Ontario, Canada N3H 4R7
Toll Free Phone 1-800-361-1517
Toll Free Fax 1-800-327-5609
®
C
US
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Heartland Appliances 7100
Summary of Contents for Heartland Appliances 7100
- Page 1 Note: Please read these instructions thoroughly before attempting to install this unit. Model 9100 MODEL 9100/7100 Manual #7715 REV 111204 ATTENTION INSTALLER: Leave this manual with appliance © 2004 HEARTLAND APPLIANCES INC. Model 7100 WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage.
- Page 2 Gas Models 9100/7100 ENTIRE PRODUCT – LIMITED ONE YEAR WARRANTY HEARTLAND warrants the replacement or repair of all parts, including gas components of this Cookstove which prove to be defective in material or workmanship, with the exception of the painted or porcelain enamel finish or plated surfaces, for one year from the date of original purchase.
-
Page 3: For Your Safety
* Do not attempt to extinguish a grease fire with water. Cover grease fires with a pot lid or baking soda. * Avoid the use of aerosol containers near the range. * Never place pans, cookie sheets or roasters directly on the oven bottom -use the rack in its lowest position. -
Page 5: Table Of Contents
TABLE OF CONTENTS 1. Assembly and Installation ... 2 2. Assembly of Range Base ... 2 3. Assembly of Range Body to Base ... 3 4. Assembly of Exhaust Hood to Range ...4 5. Positioning the Range ... 4 6. Installation Clearances ... 5 7. -
Page 6: Assembly And Installation
1. Unpackage the base sections, legs and hardware package which are located in a carton fastened to the skid at rear of the range (it would be a good idea to check for any damage that may have occurred during shipping). -
Page 7: Assembly Of Range Body To Base
2. In order not to damage the nickel trim or enamel finish, lift the range from the front and the rear . The person at the front can first remove the oven door and use the oven opening for a hand hold. The rear of the oven body at the bottom can be used to lift from the back. -
Page 8: Assembly Of Exhaust Hood To Range
4. Put both hands on the trim and carefully push the range into place, make sure floor is clear of all debris. Don't forget to plug in the main power cord and the exhaust hood power cable before the range is in its final position. -
Page 9: Installation Clearances
Installation Clearances If the range must stand beside a refrigerator, it is important for proper air circulation, that there be at least 5" of space between the two appliances. Do not install range closer than 1/2" from adjacent surfaces. To eliminate the risk of burns or fire by reaching over heated surface units, installation of cabinet storage space above the surface units should be avoided. -
Page 10: Electrical And Gas Installation
Exhaust Hood Electrical Connection After your exhaust hood has been installed the very last thing to do is to connect the special plug to the range. The female receptacle for the exhaust hood is located at the rear of the stove by the main power (male) receptacle (See page 8 for receptacle locations and figure 5 for receptacle illustration). -
Page 11: Exhaust Hood
Exhaust Hood Your range is equipped with a two speed range hood that may be either vented directly to the outside, or may be installed ventless. A set of exhaust filters are included with your hood. The filters should be cleaned periodically in soapy water. -
Page 12: Installation Of Ducting
Remove air deflector (used for ventless operation only). Cut appropriate-sized hole through the wall directly behind the range hood outlet (see Figure 6 ,page 7), making sure no wall studs are cut. Push range into position. From outside of the house, measure distance from the siding to the range outlet. Cut duct pipe that length, plus 1" (25mm) for overlap into outlet. -
Page 13: Venting Safety Guidelines
Gas Line Installation The Model 7100 / 9100 can be operated on either natural gas or liquid propane (LP) and are set for natural gas OR propane (LP) gas at the factory. Be sure your range is correctly installed by a qualified serviceman or installer for the type of gas on which it is to be used. -
Page 14: Important Safety Instructions
5. User servicing—do not repair or replace any part of the appliance unless specifically recommended in the manual. All other servicing should be referred to a qualified technician. 6. Storage in or on appliance—flammable materials should not be stored in an oven, near surface units or in range cabinet. -
Page 15: Features
D) Gas Burner Controls - allow an infinite selection of cooking temperatures, 4 controls on model 9100 and 6 controls on model 7100. All models feature "auto-reignition", which means if for any reason the flame goes out, it automatically begins to spark to re-ignite the burner! -
Page 16: Oven Features
H) Broiler - Broiler drawer located under the oven, glides open for easy access, for all your broiling needs. I) More Storage - (model 7100 only) lift and open the cast door to gain access to more storage area. J) Cabinet Door - the minute minder, exhaust fan control and overhead light switch are concealed behind the cabinet door. -
Page 17: Control Panel Layout
Model 7100 Control Panel Left Rear Burner Control(Medium) Left Front Burner Control (Large) Centre Rear Burner Control (Medium) Centre Front Burner Control (Medium) Right Rear Burner Control(Medium) Right Front Burner Control(Large)) Oven Control The operation of the controls are described in the following pages. -
Page 18: Operation
Lighting the Top Burners Your range is equipped with a spark ignition system that is electrically operated. You need only to push in and turn the knob to any position and the burner will light. When you turn the knob, you will hear a distinct clicking noise. -
Page 19: Oven Cooking
1 minute before trying to light oven again. If you are still not successful see "trouble shooting guide". Range Thermostat The temperature in the oven is transmitted to the thermostat by the sensor tube located at the rear of the oven. -
Page 20: Power Failure Operation
Power Failure Operation If electrical power is interrupted in your area, you can still cook meals on your Heartland gas range .By following these simple directions you will be able to use the burners and oven without the benefit of electricity. -
Page 21: Clock/Timer
Minute minder Bell symbol indicates minute Clock / Timer NOTE: Clock must be set or your timer will not function! Functions: Power on Display is flashing Set time of day Press left button" ". Set time of day with " "... -
Page 22: Care And Cleaning
Avoid abrasive cleaners. If any acid-based food or liquid, such as lemon juice or tomato juice is spilled on the range wipe it at once to prevent staining. -
Page 23: Oven Cleaning
Oven Cleaning Your range must be kept clean and free of accumulations of grease or spillovers which may ignite. This is most important in the oven and broiling compartment. When cleaning the oven, make sure the oven is turned “Off” and oven is cool. For simple spills, clean the oven with a strong solution of detergent, then wipe with a clean damp cloth and dry. -
Page 24: Nickel Trim
(never wet) cloth to protect hands. If light bulb should break, disconnect power to range by unplugging it or removing the fuse from the panel before touching the bulb. Replace the bulb. Use only a 40 watt oven bulb available at your local hardware store or appliance dealer. -
Page 25: Interior Oven Rack Removal
Interior Oven Rack The oven rack is designed with stop-locks so that when placed correctly on the supports, it (a) will stop before coming completely out of the oven, (b) will not tip when placing or removing food. To install, place the rack "feet" on the rack support and push the oven rack backward along the rack support. (see 1 ) Push the oven rack all the way to the back until the oven rack slips off the end of the rack support. -
Page 26: Oven Door Removal
3) The door weighs about 17 lbs (8 kg) , so exercise caution when removing the door. 4) To replace the door reverse this sequence. WARNING! Do not sit, lean, lift or stand on the doors or drawers of this range as possible injuries may result. Make sure the brass catch is securely hinged... -
Page 27: Broiling
Let the pan cool first, then wash the pan and griddle in hot soapy water. Oven Light The oven light switch is located below the nickel band on the right front side on the model 7100 and on the model 9100 right side. Optimum Broiling Area... - Page 28 Storage Drawer To remove storage drawer: 1. Remove oven door. 2. Remove oven bottom. 3. Pull drawer out until it stops. 4. With the aid of a flashlight, locate and remove the drawer stop at the left side of the drawer by removing the two screws.
-
Page 29: Broiler Drawer Removal
Filters Splashback Burner Setup & Adjustment The range was carefully set up and inspected at the factory but some final adjustments may be necessary once the unit is installed. You should check the following: First check to make sure there are no gas leaks. Propane and natural gas have a very distinct smell which is easily detected by the human nose. -
Page 30: Air Shutter Adjustment
These two items must be checked before putting the appliance into operation. (see figure 11) NOTE: Before putting the 7100 /9100 Gas Range into service, be sure that all the setup procedures recommended in this manual have been completed. -
Page 31: Troubleshooting Guide
Check positioning of shrink sleeving on receptacle – should be flush with end of receptacle – trim if necessary Replace module Check ground/earth connection of range chassis and ground/earth lead connection to module lead or through Use smaller sized pots or reduce size of flame. Do not use griddle plate directly over top of grates. -
Page 32: Conversion Kits And Information
Conversion Kits and Information Normally, Model 7100 and 9100 are ordered from the factory preset for either Natural Gas or Propane. However, they can be converted after installation by performing a conversion procedure to the gas components with the appropriate conversion kit. -
Page 33: Products
30" opening! Also available with a self clean oven feature , as model 8210 7100- 48" Gas or propane kitchen range - 6 sealed gas burners, a chef's dream come true! 9100- 30" Gas or propane kitchen range - 4 sealed gas burners, fits in a 30"... - Page 34 7100/9100 PARTS CHART 15 99 15 46 15 92 16 071 15 70 15 56 15 211 737 4 75 45 75 30 63 13 13 021 13 07 111 0 111 5 91 41 11 2 5 11 2 01...
-
Page 35: Products
Model 7100 / 9100 Gas Range Parts Chart TO ENSURE THE CORRECT COLOR MATCH WHEN ORDERING COLORED PANELS, BOTH THE COLOR AND SERIAL NUMBER MUST BE PROVIDED. 1110 Oven Door Handle Stanchion 1120 Outer Oven Door Panel 1125 Oven Door Thermometer (Non Functional) -
Page 36: Parts Diagram
This appliance can be used with LP/Propane gas and Natural gas. The gas appliance regulator must be set for the gas with which the appliance is used. Surface adjacent to cook top-left (7100) ... 1” (25mm) Surface adjacent to cook top-right (7100) ... 0” (0mm) Surface adjacent to cook top (9100) ... -
Page 37: Parts List
Technical Data 7100 - Voltage 120 v / 60 Hz - Load 3 amps (model 9100) - Load 3 amps (model 7100) NOTE: Service amperage should be calculated by a qualified electrician. The maximum propane/natural gas supply inlet must not exceed 14 inches of water column.
