Maintenance and Consumables
Use this mode if printing is faint or contains foreign substances. This method of cleaning consumes the least amount of
ink.
It takes about five minutes to complete.
• Head Cleaning B
Use this mode if no ink is ejected at all, or if Head Cleaning A does not solve the problem.
It takes about six minutes to complete.
Important
• Do not remove the Maintenance Cartridge or ink tanks during either Head Cleaning A or Head Cleaning B.
Ink may leak or an error may occur.
• If printing does not improve even if you execute Head Cleaning B, try repeating Head Cleaning B once or
twice. If this still does not improve printing, the Printhead may have reached the end of its useful life. Con-
tact your Canon dealer for assistance.
Note
• Nozzles are periodically checked to ensure they are clear. Configure the settings on the Control Panel menu
in Nozzle Check. (See "Menu Settings.")
Perform cleaning as follows.
1.
On the Tab Selection screen of the Control Panel, press ◀ or ▶ to select the Settings/Adj. tab (
11
2.
Press the OK button.
The Set./Adj. Menu is displayed.
3.
Press ▲ or ▼ to select Maintenance, and then press the OK button.
4.
Press ▲ or ▼ to select Head Cleaning, and then press the OK button.
5.
Press ▲ or ▼ to select Head Cleaning A or Head Cleaning B, and then press the OK button.
Head cleaning is now executed.
982
6.
Print a test pattern to check the nozzles, and determine whether cleaning has cleared the nozzles. (See "Checking
for Nozzle Clogging.")

Replacing the Printhead

When to replace the Printhead
This printer is equipped with two printheads.
Replacing the Printhead
> Printheads >
Note
• If the Tab Selection screen is not displayed, press the Menu button.
→P.980
→P.914
).
