- Page 1 Veritas User Guide Quick Reference Guide THANK YOU FOR VOTING TEXECOM THANK YOU FOR VOTING TEXECOM USER GUIDE Security Control Panels Issue 2 INS167...
-
Page 2: Keypad Lock
Overview Premier Series User Guide 1. Overview Introduction Users of the alarm system will be assigned a unique 4, 5 or 6 digit User code. User codes are used to arm and disarm the system. Some User codes can also access additional options such as, system tests and omitting zones. -
Page 3: Zone Faults During Arming
Premier Series User Guide Overview LED Indicators Five LED indicators have been provided to indicate the status of the system. Status Meaning Power AC mains is present on the control panel Flashing AC Mains is not present, the control panel is running on the standby battery Service The system requires attention, contact your installer The system does NOT require attention... -
Page 4: Operating The Alarm System
Operating the Alarm System Premier Series User Guide 2. Operating the Alarm System To FULL Arm the System The system is FULL Armed when ALL zones are ON (not omitted). !" Your Installer may have programmed the system so that it can be set by just pressing , if this is the case then there is no need to enter the User code below. -
Page 5: To Arm Individual Areas
Premier Series User Guide Operating the Alarm System To ARM Individual Areas If the system has been split up into separate areas of protection i.e. Area 1 = House, Area 2 = Garage, Area 3 = Shed etc. These areas can be individually selected for FULL or PART arming as required. -
Page 6: To Cancel The Exit Mode
Operating the Alarm System Premier Series User Guide To DISARM the System When Not in Entry 1. Enter a valid User code ,,,, 2. Press To CANCEL the Exit Mode Once the exit mode has been started you should leave the premises immediately, however, if for some reason you decide not to leave, the exit mode must be cancelled. -
Page 7: User Reset
Premier Series User Guide Operating the Alarm System To RESET After an Alarm USER Reset Once the alarm has been silenced (see page 6 for details), the system will need to be reset. !" If the system has been programmed, to be reset by an Engineer, pressing will not return the display to normal, if this is the case see ENGINEER Reset for details. -
Page 8: To Omit Zones
Operating the Alarm System Premier Series User Guide To OMIT Zones It is possible to exclude (omit) individual zones when arming i.e. if a zone is ‘in fault’. Users with access to this function can only omit zones that have been programmed as ‘Omittable’. !"... - Page 9 Premier Series User Guide Operating the Alarm System To CHANGE Your User Code Users with access to this option can change their own User codes. User codes are unique to each user and can be 4, 5 or 6 digits long. !"...
-
Page 10: Quick Reference Guide
Quick Reference Guide Premier Series User Guide 4. Quick Reference Guide Operation Description Action To Full Arm the System Enter a valid User code ,,,, Press Yes (or press Chime to arm silently) To Part Arm the System Enter a valid User code ,,,, Press Part ! , (... -
Page 11: Installation Details
Premier Series User Guide Installation Details 5. Installation Details Areas Exit Entry Entry Bell Bell Abort Description Time Time 1 Time 2 Delay Duration Time Sec. Sec. Sec. Min. Min. Sec. Sec. Sec. Sec. Min. Min. Sec. Sec. Sec. Sec. Min. -
Page 12: Service Record
Comments Engineer Emergency Telephone Numbers For 24 Hour Call Out For Anti-Code Reset Control Panel Details ❏ ❏ ❏ ❏ ❏ Model Premier 24 Premier 48 Premier 88 Premier 168 Premier 640 Location © TEXECOM LTD. 2000 - 2005 INS221-2...
