Gazelle POWER PLUS Assembly Instructions

HYDRAULICS INSTALLATION
PARTS
hydraulics pin
left
right
TO INSTALL YOUR HYDRAULICS
a.
b.
Fasten mounting brackets Mount left hydraulic to left swing arm using
to the outside edges of the (1) spring, (1) M12 washer, (2) rubber pads,
left and right foot tubes using (1) M12 washer (1) M8 washer, (1) nut, and
(2) hex bolts, (2) washers and (1) nut cap.
(2) nylon nuts. Tighten bolts
Note: the bottom of
with wrenches provided.
the hydraulic must
have the pin facing
the swing arm.
c.
Mount right hydraulic
to right swing arm using
mounting
bracket (1) spring,
foot tube
nut
(1) M12 washer,
washer
(2) rubber pads,
left
(1) M12 washer,
swing
arm (1) M8 washer,
(1) nut and
left side
(1) nut cap.
shown
M8 x 70mm
hex bolts
Note: the bottom of
Repeat on right side. the hydraulic must
have the pin facing
the swing arm.
d.
Pull left hydraulic down to allow pin to pass
through resistance hole in mounting bracket. For
ease of assembly, raise foot platform slightly so
pin can reach mounting bracket.
e.
Lock clip onto hydraulic pin.
Repeat Steps d and e on
right side.
platform tube
clip
pin
mounting bracket
©2003, ©2004 and ©2005 Fitness Quest
(after complete unit is assembled)
fastener pack
M8 x 70mm hex bolts,
mounting brackets
washers and nylon nuts
washers (4)
12mm
washers (2)
8mm
closed end
wrenches
rubber pad (4)
RESISTANCE LEVELS
NOTE: There are 4 levels of resistance on the
unit. Begin exercising at Level 1 (zero resistance)
and slowly advance to the next level when the
rubber
current level becomes too easy. The levels
pad
washer
(M12)
washer (M12)
increase as you move the pin towards you to
washer
(M8) the next position.
nut
cap
spring
nut
left
swing
arm
inside
of unit
L
outside
Level
of unit
2
pin
If you do not wish to use the hydraulics,
remove the clips and move the hydraulics into
the zero resistance slot. Replace both clips.
foot
platform
clip in zero resistance
foot
Inc. All rights reserved. Gazelle Power Plus is a trademark of Fitness Quest
® ®
TM
We recommend having someone
available to help you. Due to the
size and weight of some of the
pieces, assembly is easier and safer
if there are two people.
springs
nut caps
clips

ASSEMBLY INSTRUCTIONS

nuts
Occasionally our products contain components that are pre-lubricated at the factory. We recommend that you protect
flooring, or anything else the parts may contact, with newspaper or cloth.
Tools Required for Assembly: Phillips Screwdriver
To familiarize yourself
with the parts, lay them
out on the floor as
shown. Cables should
lay on top of the frames
(be careful you do not
tangle cables with
swing arms).
Zero
Resistance
left frame
Level 1
water bottle
Level
Level
4
3
a. Base Frame Assembly
First, remove the 6, M8 x 25mm bolts and
spring washers on the left and right base
frames marked L and R with the arrows
toward the front.
Second, use 4 of the M8 x 25mm bolts,
2 on each end, to attach the cross tube to
the top of the base frame.
remove 6
M8 x 25mm
bolts from
left base
M10 x 95mm
hex bolts
Inc.
Wrenches (provided)
handlebars
axle tube
left right
left right
swing arm swing arm
and holder base base
frame frame
cross tube
electronics
Third, attach the frame plates to each side
of the base frames using (4) M10 x 95mm
hex bolts and spring washers from the
fastener pack. These bolts also secure the
base frame to the cross tube. Tighten bolts.
remove 6
M8 x 25mm
bolts from
replace 2
right base
M8 x 25mm
bolts to attach
front
cross tube
replace 2
M8 x 25mm
bolts to attach
cross tube
frame plate
cross tube
right base frame
frame plate
left base frame
poly bag
frame plates
large
washers
end caps
fastener pack
M6 x 40mm Phillips bolt (4)
right frame
(attaches end caps to frame)
M10 x 95mm hex bolt (4)
M8 x 25mm hex bolt (2),
and spring washer
spring washer and washer
(attaches frame plate &
(attaches axle tube to frame)
cross tube to base frame)
wrench (2)
b. Lying Out Swing Arms
Move the left and right swing arms to the
center of the frame assembly as shown. Make
sure the cables lay on the top of all pieces.
M10 x 95mm
hex bolts
left
frame
left right
swing arm swing arm
1/20/05
right
frame
