Page 1: Dc Power Supply
ODP Series Linear Programmable DC Power Supply User Manual ■ ODP3032 ■ ODP3052 WWW.OWON.COM WWW.OWON.COM.HK WWW.OWON.COM.CN... - Page 2 The information in this manual was correct at the time of printing. However, OWON will continue to improve products and reserves the rights to changes specification at any time without notice.
- Page 3 Please contact the nearest Lilliput's Sales and Service Offices for services or a complete copy of the warranty statement. For better after-sales service, please visit www.owon.com.hk and register the purchased product online. Excepting the after-sales services provided in this summary or the applicable warranty...
-
Page 4: Table Of Contents
Table of Contents 1. General Safety Requirements..................1 2. Safety Terms and Symbols....................2 3. General Characteristics....................3 4. Quick Start ........................4 4.1 Front/Rear Panel and User Interface .................. 5 4.1.1 Front Panel ............................5 4.1.2 Rear Panel ............................7 4.1.3 User Interface .......................... - Page 5 5.6 System Settings ........................21 5.6.1 Set Language ..........................21 5.6.2 Set Bright............................21 5.6.3 Set Screen Saver Time ........................21 5.6.4 Set System Time..........................22 5.6.5 Buzzer............................22 5.6.6 View System Information......................22 5.6.7 Set as Default..........................22 5.7 Use Built-in Help........................23 6.
-
Page 6: General Safety Requirements
1.General Safety Requirements 1. General Safety Requirements Before any operations, please read the following safety precautions to avoid any possible bodily injury and prevent this product or any other products connected from damage. In order to avoid any contingent danger, this product is only used within the range specified. -
Page 7: Safety Terms And Symbols
2.Safety Terms and Symbols 2. Safety Terms and Symbols Safety Terms Terms in this Manual. The following terms may appear in this manual: Warning: Warning indicates the conditions or practices that could result in injury or loss of life. Caution: Caution indicates the conditions or practices that could result in damage to this product or other property. -
Page 8: General Characteristics
3.General Characteristics 3. General Characteristics OWON ODP Series products are new high-performance programmable linear DC power supplies. The excellent features of this series include up to 100 output groups with configurable timer, high-resolution LCD display, extremely clean ripple and noise,... -
Page 9: Quick Start
4.Quick Start 4. Quick Start This chapter will deal with the following topics mainly: Front/Rear Panel Overview User Interface Overview How to Implement General Inspection How to Implement Power-On Check How to Implement Output Inspection Instruction of the four Working Mode Instruction of the System Menu Operation... -
Page 10: Front/Rear Panel And User Interface
⑯ ⑩ ⑮ ⑬ ⑪ ⑭ ⑫ Figure 4-1 Front panel overview (take ODP3032 for instance) ① LCD Display the user interface ② Numeric keys Parameter input, include the numeric keys, decimal point and area backspace key. Select menu or change the parameter ③... - Page 11 4.Quick Start ⑩ Channel 2 control Blue Volt/CV key: Set the output voltage of Channel 2 area Blue Curr/CC key: Set the output current of Channel 2 Blue ON/OFF key: Enable/disable the output of Channel 2 ⑪ Output terminals Channel 2 output connectors of Channel 2 ⑫...
-
Page 12: Rear Panel
4.Quick Start 4.1.2 Rear Panel ② ① ③ ④ ⑥ ⑦ ⑤ Figure 4-2 Rear panel overview ① USB Host port Connect as a "host device" with an external USB device, such as connect a USB disk to the instrument. ②... - Page 13 4.Quick Start ① ② ③ ④ ⑤ ⑥ ⑩ ⑦ Channel 1 ⑧ ⑨ Channel 2 (same layout as Channel 1) Figure 4-3 User interface in Independent mode ① Output status of Cannel 1 ② Specified time and left time of current output when the timing output of Channel 1 is on ③...
- Page 14 4.Quick Start ② ① ③ ④ ⑫ ⑤ ⑥ ⑦ ⑪ ⑧ ⑨ ⑩ Figure 4-4 User interface in Parallel/Series mode ① Maximum ratings of voltage and current ② Channel status ③ Output mode of timing output (Sequence / Loop) ④...
-
Page 15: Status Icons
4.Quick Start ① ② ③ ④ ⑤ ⑥ ⑩ ⑦ Negative ⑧ ⑨ Positive (same layout as Negative) Figure 4-5 User interface in Plus-minus mode ① Output status of Negative (same as Positive) ② Specified time and left time of current output when the timing output of Negative is on ③... -
Page 16: General Inspection
4.Quick Start Current working mode is Series Current working mode is Plus-minus The buzzer is on The buzzer is off The system is in Timer Status 4.2 General Inspection After you get a new ODP Series power supply, it is recommended that you should make a check on the instrument according to the following steps: 1. -
Page 17: Power On
4.Quick Start Fuse Voltage ODP3032 ODP3052 AC110V 125 V，F5 A 125 V，F10A AC220V 250 V，F3 A 250 V，F5A To change the input voltage scale of the instrument, do the following steps: (1) Turn off the power button at the front panel and remove the power cord. -
Page 18: Working Mode
0～5A Current ratings The 5V output terminals always output fixed 5V during the instrument is powered on, the max output current is 3A (ODP3032) or 5A (ODP3052). Users could choose the proper mode and output terminals as required. 4.5.2 Connections... -
Page 19: System Menu Operation
4.Quick Start Parallel Series Plus-minus Minus Ground Plus 4.6 System Menu Operation (1) Display the menu Press System key, the System menu is shown on the screen. (2) Choose the menu Press ▲ / ▼ direction key or turn the knob to move around the menu items. Press any one of the ＜... -
Page 20: Front Panel Operation
5.Front Panel Operation 5. Front Panel Operation This chapter will deal with the following topics mainly: How to Turn On/Off the Channel Output Set the Output Voltage/Current Over Voltage/Current Protection Timing Output Save/Recall/ Record Functions System Settings How to Use Built-in Help... -
Page 21: Turn On/Off The Channel Output
5.Front Panel Operation 5.1 Turn On/Off the Channel Output Independent Mode Press the orange ON/OFF key to turn on/off the Channel 1 output. Press the blue ON/OFF key to turn on/off the Channel 2 output. The ON/OFF key is lighted when the corresponding channel is on. Parallel, Series and Plus-minus Mode Press the orange ON/OFF key to turn on/off the channel output. -
Page 22: Over Voltage/Current Protection
5.Front Panel Operation voltage/current will pop up. (2) The operation of input box is the same as Independent mode. In the same way, press the blue Volt/CV or Curr/CC key to set the Positive output voltage/current. Note: If the input value is out of the rated range, the box prompts "ERROR"; you need to input another value within the rated range. -
Page 23: Set O.c.p
5.Front Panel Operation Note: In Plus-minus mode, the O.V.P status of Positive and Negative will remain consistent, you can set either of them. The O.V.P value can be set separately. (3) Use the numeric keys to enter the O.V.P value in current mode and status. The maximum in Independent, Parallel, Plus-minus mode is 31.5V, the maximum in Series mode is 63V. -
Page 24: Timer Range
5.Front Panel Operation voltage, current and output time. This function allows up to 100 groups of timer parameters. In timer status, press the Set key to enter/exit timer setting interface of the current mode. Press the Mode key to switch between the corresponding timer setting interface of the four working mode. -
Page 25: Turn On/Off Timing Output
5.Front Panel Operation (1) In timer status: Independent Mode Press the System key, enter [System → CH1 (CH2) →TimerRng]. Parallel, Series Mode Press the System key, enter [System → TimerRng]. Plus-minus Mode Press the System key, enter [System → Positive →TimerRng]. (2) The timer range setting box pops up. -
Page 26: Recall And Delete System Parameters File
5.Front Panel Operation to add the next character. Press the ＜ key to select the previous character. Press the ← key to delete the selected character. (2) Press the key to store after editing the file name. 5.5.2 Recall and Delete System Parameters File (1) Press the Recall key to enter the function interface (press it again to exit). -
Page 27: Set System Time
5.Front Panel Operation 5.6.4 Set System Time Press the System key and enter [System →Sys Set →SysTime]. Press the ▲ / ▼ key or turn the knob to set the selected value. Press the ＜ / ＞ key to move the cursor. Press key to confirm. -
Page 28: Use Built-In Help
5.Front Panel Operation Use Built-in Help Help function button Press , the catalog will display in the screen. the ▲ / ▼ key or turn the knob to Press choose help topic. ← key to go back to Press to view the details about the topic; press the the catalog Help again Press... -
Page 29: Communication With Pc
6.Communication with PC 6. Communication with PC ODP Series Power Supply supports communications with a PC through USB or COM interface. You can use the ODP communication software to set the parameters, control the output of the power supply, and synchronously display the actual output values on the Power Supply screen. -
Page 30: Troubleshooting
7.Troubleshooting 7. Troubleshooting 1. The instrument is powered on but no Display. Check if the power is connected properly. Check if the Power Switch is in the proper voltage scale. Check if the fuse which is below the AC Power socket is used appropriately and in good condition (the cover can be pried open with a straight screwdriver). -
Page 31: Technical Specifications
Channel 1/Channel 2 Fixed 5V Independent/Parallel 0～30V Voltage Series 0～60V Plus-minus －30V～30V Independent/Series 0～3A DC Output Ratings ODP3032 /Plus-minus Parallel 0～6A Current Independent/Series 0～5A ODP3052 /Plus-minus Parallel 0～10A ≤0.01% + 2mV ≤3mV Line Regulation ≤0.01% + 1mA... - Page 32 480 (Horizontal) × 320 (Vertical) Pixels Display Colors 65536 colors, TFT screen Power Supply 110 Vac ± 10%, 220 Vac ± 10%; AC input 50/60Hz 110V 125 V，F5A ODP3032 220V 250 V，F3A Fuse 110V 125 V，F10A ODP3052 220V 250 V，F5A Environment Working temperature: 0 ℃～40 ℃...
-
Page 33: Appendix
9.Appendix 9. Appendix 9.1 Appendix A: Enclosure Standard Accessories: A power cord that fits the standard of the destination country A USB data cable A CD (PC link application software) A User Manual 9.2 Appendix B: General Care and Cleaning General Care Do not store or leave the instrument where the liquid crystal display will be exposed to direct sunlight for long periods of time.
