4. Remove the bulb by pulling it straight
out.
5. Insert a new bulb in the socket.
6. Reassemble the socket and the lens
part.
7. Connect the bulb electrical connector.
8. Reinstall the light assembly to the
body of the vehicle.
5 Door
Wagon
OFD067024/OFD067040
G220300BFD
Rear combination light bulb
replacement
5 Door
(1) Stop and tail light or tail light
(2) Rear turn signal light
(3) Back-up light
(4) Rear fog light (if equipped) or stop
light
Wagon
(1) Tail light
(2) Rear turn signal light
(3) Back-up light
(4) Stop light
Maintenance
5 Door
Wagon
1. Open the tailgate.
2. Loosen the light assembly retaining
screws with a cross-tip screwdriver.
3. Remove the rear combination light
assembly from the body of the vehicle.
OFD067025
OFD067041
7 65
