Table of Contents

Advertisement

Quick Links

O O W W N N E E R R ' ' S S M M A A N N U U A A L L
O O p p e e r r a a t t i i o o n n
M M a a i i n n t t e e n n a a n n c c e e
S S p p e e c c i i f f i i c c a a t t i i o o n n s s
All information in this Owner's Manual is current at the time of publica-
tion. However, HYUNDAI reserves the right to make changes at any time
so that our policy of continual product improvement may be carried out.
This manual applies to all models of this vehicle and includes descrip-
tions and explanations of optional as well as standard equipment.
As a result, you may find material in this manual that does not apply to
your specific vehicle.
Please note that some models are equipped with Right-Hand Drive
(RHD). The explanations and illustrations for some operations in RHD
models are opposite of those written in this manual.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the i30 2018 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hyundai i30 2018

Summary of Contents for Hyundai i30 2018

  • Page 1 S S p p e e c c i i f f i i c c a a t t i i o o n n s s All information in this Owner's Manual is current at the time of publica- tion. However, HYUNDAI reserves the right to make changes at any time so that our policy of continual product improvement may be carried out.
  • Page 2 CAUTION: MODIFICATIONS TO YOUR HYUNDAI Your HYUNDAI should not be modified in any way. Such modifications may adversely affect the performance, safety or durability of your HYUNDAI and may, in addition, violate condi- tions of the limited warranties covering the vehicle. Certain modifications may also be in vio- lation of regulations established by the Department of Transportation and other government agencies in your country.
  • Page 3 SAFETY AND VEHICLE DAMAGE WARNING This manual includes information titled as DANGER, WARNING, CAUTION and NOTICE. These titles indicate the following: DANGER CAUTION DANGER indicates a hazardous situa- CAUTION indicates a hazardous situa- tion which, if not avoided, will result tion which, if not avoided, could result in death or serious injury.
  • Page 4 Your Owner’s Manual will introduce you to the features and operation of your new HYUNDAI. To become familiar with your new HYUNDAI, so that you can fully enjoy it, read this Owner’s Manual carefully before driving your new vehicle. This manual contains important safety information and instructions intended to familiarize you with your vehicle’s con- trols and safety features so you can safely operate your vehicle.
  • Page 5 Introduction S S A A F F E E T T Y Y M M E E S S S S A A G G E E S S H H O O W W T T O O U U S S E E T T H H I I S S M M A A N N U U A A L L We want to help you get the greatest Your safety, and the safety of others, Throughout this manual DANGER,...
  • Page 6 (We recommend that you power and may cause damage to consult an authorized HYUNDAI the engine. dealer for details.) Your new vehicle is designed to WARNING...
  • Page 7 - MMT (Magnanese, Mn) fuel additive gasoline, we recommend that you 1. Gasohol containing more than - Ferrocene (iron-based) fuel additive ask an authorized HYUNDAI dealer. 10% ethanol. - Other metallic-based fuel additives 2. Gasoline or gasohol containing Octane rating of leaded gasoline is methanol.
  • Page 8 (Oxygen Content 2.7% weight) may reduce vehicle performance and Fuel Additives produce vapor lock or hard starting. HYUNDAI recommends that you use unleaded gasoline which has an CAUTION octane rating of RON (Research Octane Number) 95 / AKI (Anti...
  • Page 9 HYUNDAI end of life vehicles in sions regulations. accordance with the European Union • Do not race the engine.

  • Page 11: Table Of Contents

    Your vehicle at a glance Safety system of your vehicle Convenient features of your vehicle Multimedia System TABLE OF CONTENTS Driving your vehicle What to do in an emergency Maintenance Specifications & Consumer information Index...

  • Page 12: Your Vehicle At A Glance

    Your vehicle at a glance Exterior overview (I) ..........1-2 Exterior overview (II) ..........1-3 Interior overview............1-4 Instrument panel overview (I)......1-5 Instrument panel overview (II)......1-6 Engine compartment ..........1-7...
  • Page 13 Your vehicle at a glance E E X X T T E E R R I I O O R R O O V V E E R R V V I I E E W W ( ( I I ) ) ■...
  • Page 14 E E X X T T E E R R I I O O R R O O V V E E R R V V I I E E W W ( ( I I I I ) ) ■...
  • Page 15 Your vehicle at a glance I I N N T T E E R R I I O O R R O O V V E E R R V V I I E E W W 1. Inside door handle ......3-12 2.
  • Page 16 I I N N S S T T R R U U M M E E N N T T P P A A N N E E L L O O V V E E R R V V I I E E W W ( ( I I ) ) 1.
  • Page 17 Your vehicle at a glance I I N N S S T T R R U U M M E E N N T T P P A A N N E E L L O O V V E E R R V V I I E E W W ( ( I I I I ) ) 1.
  • Page 18 E E N N G G I I N N E E C C O O M M P P A A R R T T M M E E N N T T 1. Engine coolant reservoir/ Engine coolant cap ......7-22 2.

  • Page 19: Safety System Of Your Vehicle

    Safety system of your vehicle This chapter provides you with important information about how to protect yourself and your passengers. It explains how to properly use your seats and seat belts, and how your air bags work. Additionally, this chapter explains how to properly restrain infants and children in your vehicle. Important safety precautions ......2-2 Child restraint system (CRS) ......2-34 Always wear your seat belt ..........2-2...

  • Page 20: Always Wear Your Seat Belt

    Safety system of your vehicle I I M M P P O O R R T T A A N N T T S S A A F F E E T T Y Y P P R R E E C C A A U U T T I I O O N N S S Restrain all children Driver distraction You will find many safety precautions...

  • Page 21: Control Your Speed

    Keep your vehicle in safe condi- • NEVER let the use of a mobile device distract you from driving. You have a tion responsibility to your passengers and Having a tire blowout or a mechanical others on the road to always drive failure can be extremely hazardous.

  • Page 22: Seat

    Safety system of your vehicle S S E E A A T T S S ■ Driver’s side ■ Passenger's side Front seat (1) Forward and backward (2) Seatback angle (3) Seat cushion height* (4) Seat cushion length* ■ Manual adjustment (5) Lumbar support* (6) Seat warmer* (7) Headrest...

  • Page 23: Safety Precautions

    Safety precautions Air bags (Continued) You can take steps to reduce the risk Adjusting the seats so that you are sit- • Hold the steering wheel by the of being injured by an inflating air ting in a safe, comfortable position rim with hands at the 9 o’clock bag.

  • Page 24: Front Seats

    Safety system of your vehicle Seat belts Front seats (Continued) Always fasten your seat belt before The front seat can be adjusted by • Do not route the seat belt starting any trip. using the control lever (or knob) or across your neck, across sharp switches located on the outside of the At all times, passengers should sit...
  • Page 25 Manual adjustment (Continued) CAUTION • Do not allow anything to inter- To prevent injury: fere with the normal position and proper locking of the seat- • Do not adjust your seat while back. wearing your seat belt. • Do not place a cigarette lighter Moving the seat cushion for- on the floor or seat.
  • Page 26 Safety system of your vehicle Reclining seatback Seat belts must be snug against your hips and chest to work properly. Sitting in a reclined position when When the seatback is reclined, the the vehicle is in motion can be dan- shoulder belt cannot do its job gerous.
  • Page 27 Power adjustment WARNING NEVER allow children in the vehicle unattended. The power seats are operable when the engine is turned off. NOTICE OPDEN037004 OPDEN037070 To prevent damage to the seats: Seat cushion height (if equipped) Lumbar support (if equipped) • Always stop adjusting the seats To change the height of the seat The lumbar support can be adjusted when the seat has been adjust-...
  • Page 28 Safety system of your vehicle Reclining seatback Sitting in a reclined position when the vehicle is in motion can be dan- gerous. Even when buckled up, the protections of your restraint system (seat belts and air bags) is greatly reduced by reclining your seatback. WARNING NEVER ride with a reclined seat- OPDEN037005...
  • Page 29 Seat belts must be snug against your hips and chest to work properly. When the seatback is reclined, the shoulder belt cannot do its job because it will not be snug against your chest. Instead, it will be in front of you.

  • Page 30: Rear Seats

    Safety system of your vehicle Seatback pocket (if equipped) Rear seats Folding the rear seat The rear seatbacks can be folded to facilitate carrying long items or to increase the luggage capacity of the vehicle. WARNING • Never allow passengers to sit on top of the folded down OPDEN037008 seatback while the vehicle is...
  • Page 31 Safety system of your vehicle OPDEN037020 OPDEN037018 OPDEN037019 To fold down the rear seatback: 3.Locate the seatbelt toward the out- board position before folding down 1. Set the front seatback to the upright the seatback to avoid the seatbelt position and if necessary, slide the system interfering with the seat- front seat forward.
  • Page 32 Safety system of your vehicle WARNING WARNING When returning the rear seat- Do not place objects in the rear back from a folded to an upright seats, since they cannot be position, hold the seatback and properly secured and may hit return it slowly.
  • Page 33 Armrest (if equipped) Carrying long/narrow cargo CAUTION (if equipped) • Be careful when loading cargo through the rear passenger seats to prevent damage to the vehicle interior. • When cargo is loaded through the rear passenger seats, ensure the cargo is properly secured to prevent it from moving while driving.

  • Page 34: Headrest

    Safety system of your vehicle Headrest NOTICE (Continued) The vehicle’s front and rear seats have • To prevent damage, NEVER hit or adjustable headrests. The headrests pull on the headrests. provide comfort for passengers, but more importantly they are designed to CAUTION help protect passengers from whiplash and other neck and spinal injuries dur-...
  • Page 35 Front seat headrests OPDEN037010 OPDEN037009 Adjusting the height up and down Forward and rearward adjustment OPDE036068 To raise the headrest: The headrest may be adjusted for- The driver’s and front passenger’s ward to 3 different positions by 1. Pull it up to the desired position seats are equipped with adjustable pulling the headrest forward to the (1).
  • Page 36 Safety system of your vehicle 3. Press the headrest release button ■ Type A (3) while pulling the headrest up (4). WARNING NEVER allow anyone to travel in a seat with the headrest removed. OPDEN037011 ■ Type B OLF034015 NOTICE If you recline the seatback towards the front with the headrest and seat cushion raised, the headrest...
  • Page 37 Rear seat headrests 4. Recline the seatback (4) using the ■ Type A seatback angle knob or switch (3). WARNING Always make sure the headrest locks into position after rein- stalling and adjusting it properly. OPDEN037012 ■ Type B OPDE036069 The rear seats are equipped with headrests in all the seating positions for the passenger’s safety and com-...

  • Page 38: Seat Warmer

    Safety system of your vehicle Seat warmers (Continued) Front seat warmers (if equipped) • People taking medication that Seat warmers are provided to warm can cause drowsiness or the seats during cold weather. sleepiness. WARNING WARNING The seat warmers can cause a SERIOUS BURN, even at low NEVER place anything on the temperatures and especially if...
  • Page 39 • Each time you push the switch, the temperature setting of the seat is changed as follows : → HIGH ( LOW ( MIDDLE ( • When pressing the switch for more than 1.5 seconds with the seat warmer operating, the seat warmer will turn OFF.

  • Page 40: Seat Belt Safety Precautions

    Safety system of your vehicle S S E E A A T T B B E E L L T T S S This section describes how to use the (Continued) WARNING seat belts properly. It also describes • Do not wear the shoulder belt some of the things not to do when Seat belts must be used by ALL under your arm or behind your...

  • Page 41: Seat Belt Warning Light

    Seat belt warning light If you start to drive without the seat (Continued) belt fastened or you unfasten the Seat belt warning • No modifications or additions seat belt when you drive under should be made by the user ■ Instrument cluster 20km/h, the corresponding warning which will either prevent the light will continue to illuminate until...
  • Page 42 Safety system of your vehicle If you start to drive without the seat Information belt fastened or you unfasten the • You can find the front passenger’s seat belt when you drive under seat belt warning light on the center 20km/h, the corresponding warning fascia panel.

  • Page 43: Seat Belt Restraint System

    Seat belt restraint system If the rear seat belt is fastened, the warning light will turn off immediately. Lap/shoulder belt If the rear seat belt is disconnected when you drive over the 20km/h, the corresponding seat belt warning light will blink and warning chime will sound for 35 seconds.
  • Page 44 Safety system of your vehicle If there is a sudden stop or impact, (Continued) the belt will lock into position. It will • Position one arm under the also lock if you try to lean forward too shoulder belt and the other over quickly.
  • Page 45 Rear center seatbelt Front seat ■ (3-point rear center seat belt) OPD036025 ODH033057 To adjust the height of the seat belt To release your seat belt: anchor, lower or raise the height Press the release button (1) in the OPDEN037073 adjuster into an appropriate position.
  • Page 46 Safety system of your vehicle Pre-tensioner seat belt WARNING Always have the metal tab (A) inserted into the buckle (A'). Information If you are not able to pull out the safe- ty belt from the retractor, firmly pull the belt out and release it. After release, you will be able to pull the belt OPDE036071 out smoothly.
  • Page 47 NEVER inspect, service, repair Therefore, we recommend the or replace the pre-tensioners system to be serviced by an yourself. This must be done by authorized HYUNDAI dealer. an authorized HYUNDAI dealer. • Do not hit the seat belt assem- blies. 2-29...
  • Page 48 OPDE037069 pre-tensioner seat belts and/or SRS control module be inspected by an The Pre-Tensioner Seat Belt System authorized HYUNDAI dealer as consists mainly of the following com- soon as possible. ponents. Their locations are shown in the illustration above:...

  • Page 49: Additional Seat Belt Safety Precautions

    Additional seat belt safety pre- Seat belt use and children WARNING cautions Infant and small children Seat belt use during pregnancy Most countries have Child Restraint ALWAYS properly restrain System laws which require children to infants and small children in a The seat belt should always be used travel in approved Child Restraint Child Restraint System appropri-...
  • Page 50 Safety system of your vehicle Small children are best protected Larger children WARNING from injury in an accident when prop- Children under age 13 and who are erly restrained in the rear seat by a too large for a booster seat should •...

  • Page 51: Care Of Seat Belts

    Seat belt use and injured people Care of seat belts The more the seat back is reclined, the greater the chance for the pas- A seat belt should be used when an Seat belt systems should never be senger's hips to slide under the lap injured person is being transported.
  • Page 52 The laws governing the age or dent. This should be done even if no height/weight restrictions at which WARNING damage is visible. We recommend that seat belts can be used instead of you consult an authorized HYUNDAI Child Restraint System differs Always properly restrain children dealer.

  • Page 53: Child Restraint System (Crs)

    Child accident. Restraint System. • After an accident, we recom- mend a HYUNDAI dealer to check the Child Restraint System, seat belts, ISOFIX anchorages and top-tether anchorages. 2-35...
  • Page 54 Safety system of your vehicle All children under the age of one year must always ride in a rearward-facing Child Restraint System. There are dif- ferent types of rearward-facing Child Restraint Systems: infant-only Child Restraint Systems can only be used rearward-facing.

  • Page 55: Installing A Child Restraint System (Crs)

    Installing a Child Restraint Booster seats After selecting a proper Child Restraint System for your child and checking System (CRS) A booster seat is a Child Restraint that the Child Restraint System fits System designed to improve the fit of properly on the seating position, there the vehicle’s seat belt system.
  • Page 56 Safety system of your vehicle ISOFIX anchorage and top-teth- When installing a Child Restraint System, adjust the vehicle seat and er anchorage (ISOFIX anchorage seatback (up and down, forward and system) for children rearward) so that your child fits in The ISOFIX system holds a Child the Child Restraint System in a con- Restraint System during driving and in...
  • Page 57 Securing a Child Restraint WARNING System with the “ISOFIX ISOFIX Anchorage Position Indicator Anchorage System” Take the following precautions To install an i-Size or ISOFIX-compat- when using the ISOFIX system: ible Child Restraint System in either of • Read and follow all installation the rear outboard seating positions: instructions provided with 1.
  • Page 58 Safety system of your vehicle Securing a Child Restraint WARNING System seat with “Top-tether Anchorage” system Take the following precautions when installing the top-tether: • Read and follow all installation instructions provided with your Child Restraint System. • NEVER attach more than one Child Restraint System to a single ISOFIX...
  • Page 59 Suitability of each seating position for ISOFIX Child Restraint Systems according to ECE regulations Vehicle ISOFIX positions Size Mass Group Fixture 2nd row Class Front Passenger Left Hand Center Right Hand ISO/L1 Carrycot ISO/L2 0- : UP TO 10KG ISO/R1 ISO/R1 0+ : UP TO 13KG ISO/R2...
  • Page 60 Safety system of your vehicle Securing a Child Restraint System with a lap/shoulder belt When not using the ISOFIX system, all Child Restraint Systems must be secured to a rear seat with the lap part of a lap/shoulder belt. ODH033063 OLMB033046 2.
  • Page 61 Suitability of each seating position for "universal" category belted Child Restraint Systems according to ECE regulations Seating Position Front Passenger Second Row Mass Group Airbag Airbag Outboard Center Outboard activated deactivated Left (3 POINT BELT) Right Group 0 up to 10kg (0-9months) Group 0 + up to 13kg...
  • Page 62 Safety system of your vehicle i-Size Child Restraint Systems according to ECE regulations Seating Position Second Row Mass Group Passenger Front Outboard Outboard Left Center Right i-size Child Restraint Systems i-U : Suitable for i-Size "universal" Child Restraint Systems forward and rearward-facing i-UF : Suitable for forward-facing i-Size "universal"...
  • Page 63 A A I I R R B B A A G G - - S S U U P P P P L L E E M M E E N N T T A A L L R R E E S S T T R R A A I I N N T T S S Y Y S S T T E E M M 1.
  • Page 64 Safety system of your vehicle The vehicles are equipped with a WARNING Supplemental Air Bag System for the driver’s seat and front passenger’s AIR BAG SAFETY PRECAUTIONS seats. ALWAYS use seat belts Child Restraint Systems - every trip, every The front air bags are designed to time, everyone! Even with air bags, you can be seriously injured or supplement the three-point seat killed in a collision if you are improperly belted or not wearing your...

  • Page 65: Where Are The Air Bags

    Where are the air bags? Passenger’s front air bag ■ WARNING Driver’s and passenger’s front air bags To reduce the risk of serious injury or death from inflating front Driver’s front air bag ■ air bags, take the following pre- cautions: •...
  • Page 66 Safety system of your vehicle (Continued) • No objects (such as crash pad cover, cellular phone holder, cup holder, perfume or stickers) should be placed over or near the air bag modules on the steering wheel, instrument panel, windshield glass, and the front passenger's panel above the glove box.
  • Page 67 ) will illuminate and stay set to the OFF position. on for 60 seconds. • We recommend that an author- ized HYUNDAI dealer inspect Information the passenger’s front air bag ON/OFF switch and the SRS air The passenger’s front air bag ON/OFF...
  • Page 68 Safety system of your vehicle Side air bags The side air bags are designed to (Continued) deploy during certain side impact col- • Hold the steering wheel at the 9 lisions, depending on the crash sever- o’clock and 3 o’clock positions, ity, angle, speed and point of impact.
  • Page 69 If the seat or seat cover is designed to deploy in all side impact damaged, we recommend that or rollover situations. the system be serviced by an authorized HYUNDAI dealer. WARNING To reduce the risk of serious injury or death from an inflating OPD036045...

  • Page 70: How Does The Air Bags System Operate

    Safety system of your vehicle How does the air bags system (8) SRS control module (SRSCM)/ (Continued) Rollover sensor operate? • Properly secure Child Restraint (9) Front impact sensors System as far away from the (10) Side pressure sensors door as possible. (11) Passenger’s front air bag •...
  • Page 71 Generally, air bags We recommend that an author- are designed to inflate based upon ized HYUNDAI dealer inspect the the severity of a collision and its direc- SRS as soon as possible if any tion. These two factors determine of these conditions occur.
  • Page 72 Safety system of your vehicle • Air bag deployment depends on a • To help provide protection, the air You can take steps to reduce the risk number of factors including vehicle bags must inflate rapidly. The speed of being injured by an inflating air speed, angles of impact and the of air bag inflation is a consequence bag.
  • Page 73 Driver’s front air bag (1) Driver’s front air bag (2) Driver’s front air bag (3) ■ ■ ■ OLMB033056 Passenger’s front air bag ■ OLMB033054 OLMB033055 When the SRSCM detects a suffi- Upon deployment, tear seams mold- ciently severe impact to the front of ed directly into the pad covers will the vehicle, it will automatically separate under pressure from the...

  • Page 74: What To Expect After An Air Bag Inflates

    Air bag We recommend that an author- attention if the symptoms persist. inflation will not prevent the driver ized HYUNDAI dealer replace from seeing out of the windshield or the air bag immediately after being able to steer. Curtain air bags deployment.

  • Page 75: Why Didn't My Air Bag Go Off In A Collision

    WARNING repairs are conducted by an • Do not hit or allow any objects to authorized HYUNDAI dealer. impact the locations where air NEVER use a rearward facing bags or sensors are installed. Child Restraint on a seat pro-...
  • Page 76 Safety system of your vehicle 1. SRS control module 2. Front impact sensor 3. Side pressure sensor (front)* 4. Side impact sensor (rear)* * : if equipped OPDEN037046/OPDEN037047/OPDEN037048/OPD036049/OPD036050 2-58...
  • Page 77 Air bag inflation conditions Although the driver’s and front pas- senger’s air bags are designed to inflate in frontal collisions, they also may inflate in other types of colli- sions if the front impact sensors detect a sufficient impact. Side and curtain air bags are designed to inflate in side impact collisions, but they may inflate in other collisions if...
  • Page 78 Safety system of your vehicle Air bag non-inflation conditions OPD036055 OPD036056 Front air bags are not designed to Front air bags may not inflate in side OPD036054 inflate in rear collisions, because impact collisions, because occupants In certain low-speed collisions the air occupants are moved backward by move in the direction of the collision, bags may not deploy.
  • Page 79 OTL035069 OPD036057 OTL035068 In an angled collision, the force of Just before impact, drivers often Front air bags may not inflate in impact may direct the occupants in a brake heavily. Such heavy braking rollover accidents because front air direction where the air bags would lowers the front portion of the vehicle bag deployment would not provide not be able to provide any additional...

  • Page 80: Srs Care

    HYUNDAI dealer. impact is concentrated and the colli- by an authorized HYUNDAI dealer. • sion energy is absorbed by the vehi- If components of the air bag Improper handling of the SRS system cle structure.

  • Page 81: Additional Safety Precautions

    Additional safety precautions Adding equipment to or modify- Air bag warning labels ing your air bag equipped vehicle Passengers should not move out of If you modify your vehicle by changing or change seats while the vehicle is your vehicle's frame, bumper system, moving.

  • Page 82: Convenient Features Of Your Vehicle

    Convenient features of your vehicle Accessing your vehicle .........3-3 Panorama sunroof ..........3-32 Remote key ...............3-3 Sunshade................3-33 Smart key ................3-6 Sliding the sunroof ............3-33 Immobilizer system ............3-10 Tilting the sunroof ............3-34 Closing the sunroof ............3-34 Door locks .............3-11 Resetting the sunroof............3-35 Operating door locks from outside the vehicle ..3-11 Sunroof open warning...........3-36 Operating door locks from inside the vehicle ..3-12...
  • Page 83 Lighting..............3-79 Climate control additional features....3-118 Exterior lights ..............3-79 Cluster ionizer..............3-118 Static bending light............3-86 Automatic ventilation ...........3-118 Welcome system..............3-87 Sunroof inside air recirculation.........3-118 Interior lights..............3-88 Storage compartment........3-119 Wipers and washers ..........3-91 Center console storage ..........3-119 Windshield wipers ............3-91 Glove box ................3-119 Windshield washers ............3-93 Sunglass holder .............3-120 Rear window wiper and washer switch.....3-94...

  • Page 84: Remote Key

    4. When the doors are locked, the indi- will lock automatically after 30 sec- cator light on the central door Your HYUNDAI uses a remote key, onds unless a door is opened. lock/unlock switch will be illuminated. which you can use to lock or unlock...
  • Page 85 To fold the key, fold the key manually ommended that you contact an while pressing the release button. authorized HYUNDAI dealer. If the remote key is in close proximity NOTICE to your mobile phone, the signal could be blocked by your mobile phone’s...
  • Page 86 HYUNDAI Avoid placing the remote key and dealer. your mobile phone in the same loca- tion and always try to maintain an...

  • Page 87: Smart Key

    OPDE046044 OPD046005 • The Engine Start/Stop button is in To lock : Your HYUNDAI uses a Smart Key, ACC or ON position. which you can use to lock or unlock 1. Close all doors, engine hood and • Any door except the tailgate is a door (and tailgate) and even start tailgate.
  • Page 88 Unlocking Information Information • The door handle button will only • The Tailgate Unlock button (3) will operate when the smart key is with- only unlock the tailgate. It will not in 0.7~1 m (28~40 in.) from the out- release the latch and open the tail- side door handle.
  • Page 89 Start/Stop button in chapter 5. is recommended that you should immediately take the vehicle and remaining key to your authorized NOTICE HYUNDAI dealer or tow the vehicle, To prevent damaging the smart if necessary. key: • Keep the smart key away from water or any liquid and fire.
  • Page 90 Battery Type: CR2032 ommended that you contact an To replace the battery: NOTICE authorized HYUNDAI dealer. 1. Remove the mechanical key. Keep the smart key away from If the smart key is in close proximity to 2. Use a slim tool to pry open the...

  • Page 91: Immobilizer System

    The immobilizer system protects your ing correctly, it is recommended that your vehicle inoperable. vehicle from theft. If an improperly you contact an authorized HYUNDAI coded key (or other device) is used, dealer. WARNING the engine’s fuel system is disabled.

  • Page 92: Operating Door Locks From Outside The Vehicle

    D D O O O O R R L L O O C C K K S S Operating door locks from Remote key Smart key outside the vehicle Mechanical key ■ Remote key ■ Smart key OPD046005 OPDE046413 Door Lock Door Unlock To lock the doors, press the Door Lock button (1) on the remote key.

  • Page 93: Operating Door Locks From Inside The Vehicle

    Convenient features of your vehicle To unlock the doors, press the button Information on the outside door handle while car- If the electrical power to door lock rying the smart key with you or press switch is not operating (ex. dead car the door unlock button on the smart battery) and the tailgate is closed, you key.

  • Page 94: Central Door Lock Switch

    With the central door Rear door Information lock/unlock switch If the inner door handle is pulled The indicator light on the switch blinks once when the door is locked, the for approximately one minute when a door will unlock. door is unlocked or the tailgate is opened. If the inner door handle is pulled once more, the door will open.

  • Page 95: Auto Door Lock/Unlock Features

    Convenient features of your vehicle Auto door lock/unlock features (Continued) WARNING Impact sensing door unlock Children might operate features system (if equipped) Opening a door when something of the vehicle that could injure is approaching may cause dam- them, or they could encounter All doors will be automatically age or injury.

  • Page 96: Child-Protector Rear Door Locks

    Child-protector rear door locks To lock the child safety lock, insert a key (or screwdriver) (1) into the hole and turn it to the lock position. To allow a rear door to be opened from inside the vehicle, unlock the child safety lock.
  • Page 97 Convenient features of your vehicle T T H H E E F F T T - - A A L L A A R R M M S S Y Y S S T T E E M M This system helps to protect your Once the security system is set, open- vehicle and valuables.

  • Page 98: Driver Position Memory System

    (1 or 2). The system will beep we recommend that you have the once, then the driver’s seat posi- system checked by an authorized tion, outside rearview mirror and HYUNDAI dealer. instrument panel illumination will automatically adjust to the stored Storing memory positions position.

  • Page 99: Easy Access Function

    Convenient features of your vehicle Easy access function Information CAUTION (if equipped) • While recalling the "1" memory The system will move the driver's Driver should be cautious when position, pressing the SET or 1 but- seat automatically as follows: using this function to assure no ton temporarily stops the adjust- injury to passenger or child on...

  • Page 100: Electric Power Steering (Eps)

    Also, the steering effort becomes or operate. Take your vehicle to This happens as the system per- heavier as the vehicle’s speed an authorized HYUNDAI dealer forms the EPS system diagnostics. increases and becomes lighter as and have the system checked as When the diagnostics are complet- the vehicle’s speed decreases for...

  • Page 101: Tilt Steering / Telescopic Steering

    Convenient features of your vehicle Tilt steering / Telescopic steering (Continued) • When the vehicle is stationary, if Adjust the steering wheel so it points you turn the steering wheel all the toward your chest, not toward your way to the left or right continuously, face.

  • Page 102: Heated Steering Wheel

    Heated steering wheel Horn Information (if equipped) The heated steering wheel will turn off automatically approximately 30 min- utes after the heated steering wheel is turned on. When the engine is turned off during the engine and the heated steering wheel is on, the timer function of heat- ed steering wheel will be reset.

  • Page 103: Inside Rearview Mirror

    Convenient features of your vehicle M M I I R R R R O O R R S S Inside rearview mirror Electric Chromic Mirror (ECM) WARNING The electric rearview mirror automati- Before you start driving, adjust the cally controls the glare from the head- rearview mirror to the center on the NEVER adjust the mirror while lamp of the vehicle behind you in...

  • Page 104: Outside Rearview Mirror

    Outside rearview mirror WARNING • The right outside rearview mir- ror is convex. In some coun- tries, the left outside rearview mirror is also convex. Objects seen in the mirror are closer than they appear. • Use your interior rearview mirror or turn your head and look to determine the actual OAD045010...
  • Page 105 Convenient features of your vehicle Adjusting the rearview mirrors NOTICE NOTICE • Do not scrape ice off the mirror • The mirrors stop moving when face; this may damage the sur- they reach the maximum adjust- face of the glass. ing angles, but the motor contin- ues to operate while the switch •...
  • Page 106 Folding the outside rearview NOTICE mirror The electric type outside rearview mirror operates even though the ignition switch is in the OFF posi- tion. However, to prevent unnec- essary battery discharge, do not adjust the mirrors longer than necessary while the engine is not running.

  • Page 107: Reverse Parking Aid Function

    Convenient features of your vehicle Reverse parking aid function The position of the outside rearview mirror switch (1) determines whether (if equipped) or not the mirrors will move: Left/Right : When either the L (Left) or R (Right) switch is select- ed, both outside rearview mirrors will move.

  • Page 108: Power Windows

    W W I I N N D D O O W W S S Power windows (1) Driver’s door power window switch (2) Front passenger’s door power window switch (3) Rear door (left) power window switch (4) Rear door (right) power window switch (5) Window opening and closing (6) Automatic power window...
  • Page 109 Convenient features of your vehicle Window opening and closing The ignition switch must be in the ON Information position to be able to raise or lower • In cold and wet climates, power win- the windows. Each door has a Power dows may not work properly due to Window switch to control that door's freezing conditions.
  • Page 110 If the power windows do not operate properly after resetting, it is recom- mended that the system be checked by an authorized HYUNDAI dealer. OLF044032 If a window senses any obstacle while it is closing automatically, it will...

  • Page 111: Power Window Lock Switch

    Convenient features of your vehicle Power window lock switch Information WARNING The automatic reverse feature is only Do not allow children to play active when the “Auto Up” feature is with the power windows. Keep used by fully pulling up the switch to the driver’s door power window the second detent.

  • Page 112: Remote Window Closing Function

    Remote window closing Information WARNING function (if equipped) • The remote window closing function • NEVER leave the keys in your may abruptly stop, when you move vehicle with unsupervised away from your vehicle during the children, when the engine is operation.

  • Page 113: Panorama Sunroof

    Convenient features of your vehicle P P A A N N O O R R A A M M A A S S U U N N R R O O O O F F ( ( I I F F E E Q Q U U I I P P P P E E D D ) ) If your vehicle is equipped with a Information WARNING...

  • Page 114: Sunshade

    Sunshade Sliding the sunroof When the sunshade is opened If you pull the sunroof control lever When the sunshade is closed backward, the sunroof glass will slide all the way open. To stop the sunroof movement at any point, pull or push the sunroof control lever momentarily.

  • Page 115: Tilting The Sunroof

    Convenient features of your vehicle Tilting the sunroof Closing the sunroof Automatic reverse (if equipped) ■ Sunroof glass ■ Sunroof glass with sunshade OPD046054 OPD046055 ODH043039 If the sunroof senses any obstacle When the sunshade is closed To close sunroof glass while it is closing automatically, it will If you push the sunroof control lever Push the sunroof control lever for-...

  • Page 116: Resetting The Sunroof

    For more details, contact an author- - The sunroof control lever is not freezing or when the sunroof is ized HYUNDAI dealer. operating correctly covered with snow or ice, other- wise the motor could be dam- Information aged.

  • Page 117: Sunroof Open Warning

    Convenient features of your vehicle Sunroof open warning (if equipped) OPD046116 • If the driver turns off the engine when the sunroof is not fully closed, the warning chime will sound for approx- imately 3 seconds and the sunroof open warning will appear on the LCD display.

  • Page 118: Hood

    E E X X T T E E R R I I O O R R F F E E A A T T U U R R E E S S Hood Opening the hood OPDEN047028 OPD046030 3. Go to the front of the vehicle, raise 5.

  • Page 119: Tailgate

    Convenient features of your vehicle Closing the hood Tailgate WARNING 1. Before closing the hood, check the Opening the tailgate following: • Before closing hood, Make sure the vehicle is in P (Park) • All filler caps in engine compart- ensure all obstructions are and set the parking brake.
  • Page 120 Closing the tailgate Information WARNING To prevent damage to the tailgate lift cylinders and the attached hardware, always close the tailgate before driv- ing. NOTICE In cold and wet climates, tailgate lock and tailgate mechanisms may not work properly due to freezing conditions.

  • Page 121: Fuel Filler Door

    Convenient features of your vehicle Fuel filler door WARNING Opening the fuel filler door • NEVER allow anyone to occu- Open py the luggage compartment of the vehicle at any time. If the tailgate is partially or totally Close latched and the person is unable to get out, serious injury or death could occur due to lack of ventilation, exhaust...
  • Page 122 Closing the fuel filler door (Continued) (Continued) 1. To install the fuel tank cap, turn it • Before touching the fuel noz- Static electricity discharge can clockwise until it “clicks” one time. zle, you should eliminate the ignite fuel vapors causing a 2.
  • Page 123 • Use only approved portable the risk of fire and burns. HYUNDAI cap or the equivalent plastic fuel containers designed Always remove the fuel cap specified for your vehicle. An to carry and store gasoline.
  • Page 124 I I N N S S T T R R U U M M E E N N T T C C L L U U S S T T E E R R 1. Variable LED tachometer 2. Speedometer 3.

  • Page 125: Instrument Cluster Control

    Convenient features of your vehicle Instrument cluster control Gauges and meters WARNING Instrument panel illumination Speedometer Never adjust the instrument ■ km/h ■ MPH, km/h cluster while driving. This could result in loss of control and lead to an accident that may cause death, serious injury, or vehicle damage.
  • Page 126 Variable LED tachometer Engine coolant temperature gauge OPDEN047154 The yellow and red LEDs show the OPDEN047104 range of recommended engine opera- The tachometer indicates the approx- OPDEN047106 tion speed. As the engine oil temper- imate number of engine revolutions ature warms up, the recommended This gauge indicates the tempera- per minute (rpm).
  • Page 127 Convenient features of your vehicle Fuel gauge WARNING WARNING Never remove the coolant cap Running out of fuel can expose when the engine is hot. The vehicle occupants to danger. engine coolant is under pressure You must stop and obtain addi- and could cause severe burns.
  • Page 128 Outside temperature gauge Distance to empty - Automatic climate control system : While pressing the OFF button, press the AUTO button for 3 sec- onds or more. The temperature unit on both the clus- ter LCD display and the climate con- trol screen will change.

  • Page 129: Manual Transmission Shift Indicator

    Convenient features of your vehicle Manual transmission shift When the system is not working prop- Information erly, the indicator is not displayed. indicator • If the vehicle is not on level ground or the battery power has been inter- Information rupted, the distance to empty func- tion may not operate correctly.

  • Page 130: Warning And Indicator Lights

    In this case, we recommend that is applied. you have the vehicle inspected by • When the parking brake is applied. an authorized HYUNDAI dealer. • When the brake fluid level in the reservoir is low. - If the warning light illuminates...
  • Page 131 In this case, we recommend that the parking brake released, it you have the vehicle inspected by indicates that the brake fluid an authorized HYUNDAI dealer. Dual-diagonal braking system level is low. Your vehicle is equipped with dual- In this case, we recommend diagonal braking systems.
  • Page 132 In this case, we recommend you have the vehicle inspected by an authorized When both ABS and Parking HYUNDAI dealer as soon as possible. Brake & Brake Fluid Warning Lights are on, the brake system will not work normally and you...
  • Page 133 In this case, we recommend that ON position. charging system. you have the vehicle inspected by an authorized HYUNDAI dealer as - It illuminates for approximately 3 If there is a malfunction with either soon as possible. seconds and then goes off.
  • Page 134 3. Start the engine again. If the have the vehicle inspected by an warning light stays on after the authorized HYUNDAI dealer as engine is started, turn the soon as possible. engine off immediately. In this...
  • Page 135 - LED head lamp malfunction you have the vehicle inspected by - It illuminates for approximately 3 - Smart high beam malfunction an authorized HYUNDAI dealer as seconds and then goes off. (if equipped) soon as possible. • When one or more of your tires are...
  • Page 136 For more details, refer to the “ISG you have the vehicle inspected by For more details, refer to “Electronic (Idle Stop and Go) system” in chap- an authorized HYUNDAI dealer. Stability Control (ESC)” in chapter 5. ter 5. This indicator light blinks:...
  • Page 137 ON position. smart key in the vehicle with the an authorized HYUNDAI dealer. Engine Start/Stop button in the - At this time, you can start the ACC or ON position.
  • Page 138 • If your vehicle detects oncoming or HYUNDAI dealer. preceding vehicles, the Smart High Beam system will switch the high Low Beam Indicator beam to low beam automatically.
  • Page 139 In this case, we recommend that you Cruise SET Indicator have the vehicle inspected by an an Light (if equipped) authorized HYUNDAI dealer. This warning light blinks: When there is a malfunction with a This indicator light illuminates: LED headlamp related part.
  • Page 140 ECO Mode Indicator CUSTOM Mode REV (Rev Matching) Light Indicator Light Indicator Light This indicator light illuminates: This indicator light illuminates: This indicator light illuminates: [White] When Rev Matching is turned • When you select "CUMSTOM" • When you select "ECO" mode as on in NORMAL mode.
  • Page 141 HYUNDAI dealer. an authorized HYUNDAI dealer. authorized HYUNDAI dealer. For more details, refer to "Lane For more details, refer to "Lane...

  • Page 142: Lcd Display Messages

    Icy Road Warning Light LCD display messages Check Steering Wheel Lock (if equipped) System (for smart key system) Low Key Battery This warning message is displayed if (for smart key system) the steering wheel does not lock nor- This warning message is displayed if mally while the Engine Start/Stop but- the battery of the smart key is dis- This warning light is to warn the driver...
  • Page 143 Start/Stop button again. light or message displayed on If the warning message appears the instrument cluster. each time you press the Engine Start/Stop button, we recommend that you have your vehicle inspected by an authorized HYUNDAI dealer. 3-62...
  • Page 144 Lights mode Wiper mode Low Pressure (if equipped) ■ Front ■ Rear OPDE046120 OPDE046125/OPDE046126 OPDEN047202 This indicator displays which exterior This indicator displays which wiper This warning message is displayed if light is selected using the lighting speed is selected using the wiper the tire pressure is low.
  • Page 145 Convenient features of your vehicle Turn on FUSE SWITCH Heated Steering Wheel turned Engine has overheated off (if equipped) (if equipped) This message is displayed if you turn This warning message is displayed off the heated steering wheel. when the engine coolant tempera- ture is above 120°C (248°F).
  • Page 146 (AEB) system. We recommend that recommend that you have the vehicle headlamps. We recommend that you you have the vehicle inspected by an inspected by an authorized HYUNDAI have the vehicle inspected by an authorized HYUNDAI dealer. dealer. authorized HYUNDAI dealer.
  • Page 147 We recommend that you have the To use the Electronic Limited Slip vehicle inspected by an authorized Differential, equip the vehicle with HYUNDAI dealer. the same tires on front and rear. more details, refer For more details, refer to “Electronic...

  • Page 148: Lcd Display Control

    L L C C D D D D I I S S P P L L A A Y Y LCD display control The LCD display modes can be changed by using the control buttons. : MODE button for changing modes : MOVE switch...

  • Page 149: Lcd Display Modes

    Convenient features of your vehicle LCD display modes Modes Symbol Explanation This mode displays driving information such as the tripmeter, fuel economy, etc. Trip Computer For more details, refer to "Trip Computer" in this chapter. Turn By Turn (TBT) This mode displays the state of the navigation. This mode displays the state of : - Oil Temperature, Torque, Turbo Boost - Lap Timer...
  • Page 150 Settings available after engag- Quick guide (Help, if equipped) Trip computer mode ing parking brake This mode provides quick guides for the systems in the User Settings mode. Select an item, press and hold the OK button. For more details about each sys- tem, refer to this Owner’s Manual.
  • Page 151 Convenient features of your vehicle Turn By Turn (TBT) mode Assist mode OPDEN047195/OPDEN047196 Lap timer OPDEN047192 OPDEN047173L (1) Total time This mode displays the state of the Gauges (2) Best lap navigation. This mode displays information relat- (3) Current lap ed to your engine such as engine oil temperature (1), current torque (2) and boost pressure (3) along with an...
  • Page 152 The saved laps can be reset when the current lap is reset. To start a new lap press the OKAY button when the current lap is reset. OPDEN047174L OPDEN047194 To reset (c): LKAS/LDWS/DAA Press and hold the OK button for This mode displays the state of the more than 1 second on the steering Cruise Control, Lane Departure...
  • Page 153 Convenient features of your vehicle Warning message mode User settings mode In this mode, you can change the settings of the instrument cluster, doors, lamps, etc. 1. Driving Assist 2. Door 3. Lights 4. Sound 5. Convenience 6. Service Interval OPDEN047193 7.
  • Page 154 • Driver Attention Alert • Speed Limit Information Function - On Key Out: All doors will be auto- matically unlocked when the igni- - Off/Normal/Early To activate or deactivate the Speed tion key is removed from the igni- Limit Information Function. To adjust the sensitivity of the Driver tion switch.
  • Page 155 Convenient features of your vehicle 3. Lights 4. Sound • Wireless Charging System • One Touch Turn Signal • Park Assist System Volume To activate or deactivate the wireless charging system in the front seat. - Off: The one touch turn signal func- - Softer/Louder tion will be deactivated.
  • Page 156 - Off: The average fuel economy will • Torque unit To use the service interval menu, con- not reset automatically whenever sult an authorized HYUNDAI dealer. To select the torques unit. (Nm/lb·ft) refueling. If the service interval is activated and - After Ignition: When the engine has •...

  • Page 157: Trip Computer

    Convenient features of your vehicle T T R R I I P P C C O O M M P P U U T T E E R R Trip modes The trip computer is a microcomput- er-controlled driver information sys- tem that displays information related Fuel Economy to driving.
  • Page 158 Fuel economy Accumulated Info display Automatic reset To automatically reset the average fuel economy after refueling, select the "Auto Reset" mode in the User Settings menu on the LCD display. - After Ignition: The average fuel economy will reset automatically whenever it has passed 4 hours after turning OFF the engine.
  • Page 159 Convenient features of your vehicle The accumulated driving information Digital Speedometer will continue to be counted while the engine is still running (for example, when the vehicle is in traffic or stopped at a stop light). Information The vehicle must be driven for a min- imum of 300 meters (0.19 miles) since the last ignition key cycle before the average fuel economy will be recalcu-...

  • Page 160: Exterior Lights

    L L I I G G H H T T I I N N G G Exterior lights NOTICE Lighting control • Do not cover or spill anything on the sensor (1) located on the instrument panel. • Do not clean the sensor using a window cleaner, the cleanser may leave a light film which could interfere with sensor oper-...
  • Page 161 Convenient features of your vehicle High beam operation OAE046469L OAE046467L Position lamp position ( Headlamp position ( ) OAE046453L The position lamp, license plate lamp The headlamp, position lamp, license To turn on the high beam headlamp, and instrument panel lamp are turned plate lamp and instrument panel lamp push the lever away from you.
  • Page 162 Smart high beam (if equipped) Operating condition 1.Place the light switch in the AUTO position. 2.Turn on the high beam by pushing the lever away from you. The smart high beam ( ) indica- tor will illuminate. 3.The Smart High Beam will turn on when vehicle speed is above 45km/h (25mph).
  • Page 163 When the front window is cov- (15 mph). will illuminate. ered with foreign matter such We recommend that you take your as ice, dust, fog, or is dam- vehicle to an authorized HYUNDAI aged. dealer and have the system checked. (Continued) 3-82...
  • Page 164 • At times, the Smart High • When there is a traffic light, authorized HYUNDAI dealer and Beam system may not work reflecting sign, flashing sign have the system checked. properly, always check the or mirror.
  • Page 165 Convenient features of your vehicle Turn signals and lane change Rear fog lamp One-touch turn signal function signals To activate a one-touch turn signal function, move the turn signal lever slightly and then release it. The lane change signals will blink 3, 5 or 7 times.
  • Page 166 Battery saver function Headlamp delay function NOTICE The purpose of this feature is to pre- If you place the ignition switch to the If the driver gets out of the vehicle vent the battery from being dis- ACC or OFF position with the head- through other doors (except dri- charged.

  • Page 167: Static Bending Light

    2. The position light switch is in the the system be inspected by an • Vehicle speed is between 10 km/h ON position. authorized HYUNDAI dealer. Do (6 mph) to 90 km/h (56 mph) and 3. The engine is turned off. not attempt to inspect or steering wheel angle is turned replace the wiring yourself.

  • Page 168: Welcome System

    Welcome system (if equipped) Interior lamp Door handle lamp (if equipped) When all the doors (and tailgate) are When the interior lamp switch is in Welcome light (if equipped) closed and locked, the door handle the DOOR position and all doors (and lamp will come on for about 15 sec- tailgate) are closed and locked, the onds if any of the below is performed.

  • Page 169: Interior Lights

    Convenient features of your vehicle Interior lights Front lamps Front room lamp NOTICE • Press the button to turn ON the Do not use the interior lights for room lamp for the front/rear seats. extended periods when the engine is turned off otherwise the battery •...
  • Page 170 Rear lamps Luggage compartment lamp NOTICE ■ Type A Do not leave the lamp switches on for an extended period of time when the engine is turned off. OAD045407 ■ Type B OPDEN047042 The luggage compartment lamp comes on when the tailgate is opened.
  • Page 171 Convenient features of your vehicle Vanity mirror lamp (if equipped) Puddle lamp (if equipped) Escort light When the ignition switch is in the OFF position and the driver's door is opened, the puddle lamp will come on for 30 seconds. If the driver's door is closed within the 30 seconds, the puddle lamp will turn off after 15 sec- onds.

  • Page 172: Windshield Wipers

    W W I I P P E E R R S S A A N N D D W W A A S S H H E E R R S S Windshield wipers ■ Front windshield wiper/washer Operates as follows when the igni- A : Wiper speed control (front) tion switch is turned ON.
  • Page 173 Convenient features of your vehicle AUTO (Automatic) control NOTICE WARNING (if equipped) • When washing the vehicle, set the To avoid personal injury from the wiper switch in the O position to windshield wipers, when the stop the auto wiper operation. The engine is running and the wind- wiper may operate and be damaged shield wiper switch is placed in...

  • Page 174: Windshield Washers

    Windshield washers Front windshield wiper service WARNING position When the outside temperature is below freezing, ALWAYS warm the windshield using the defroster to prevent the washer fluid from freezing on the windshield and obscuring your vision which could result in an accident and serious injury or death.

  • Page 175: Rear Window Wiper And Washer Switch

    Convenient features of your vehicle Rear window wiper and washer Auto rear wiper (if equipped) switch (if equipped) The rear wiper will operate while the vehicle is in reverse with the front wiper ON by selecting the function on the LCD display. Go to ‘User Settings →...

  • Page 176: Rear View Camera

    D D R R I I V V E E R R A A S S S S I I S S T T S S Y Y S S T T E E M M Rear view camera (if equipped) This is a supplemental system that WARNING shows behind the vehicle through...

  • Page 177: Rear Parking Assist System

    Convenient features of your vehicle Rear parking assist system NOTICE WARNING (if equipped) • Do not spray the camera or its • surrounding area directly with a ALWAYS look around your vehi- high pressure washer. Shock cle to make sure there are not applied from high pressure any objects or obstacles before water may cause the device to...
  • Page 178 • If the audible warning does not sound or if the buzzer sounds intermit- tently when shifting into R (Reverse) position, this may indicate a mal- function with the Parking Assist System. If this occurs, we recommend that you have your vehicle checked by an authorized HYUNDAI dealer as soon as possible. 3-97...
  • Page 179 Convenient features of your vehicle To turn off the Rear Parking Non-operational conditions of Detecting range may decrease when: Assist System (if equipped) Parking Assist System • Outside air temperature is extreme- ly hot or cold. The Rear Parking Assist System may not operate normally when: •...
  • Page 180 Rear parking assist system pre- The following objects may not be • Do not spray the sensors or its sur- rounding area directly with a high recognized by the sensor: cautions pressure washer. Shock applied • Sharp or slim objects such as •...

  • Page 181: Parking Assist System

    Convenient features of your vehicle Parking assist system Operation of the Parking Assist This system is a supplemental sys- tem that senses objects within the (if equipped) System range and location of the sensors, it ■ Front sensor cannot detect objects in other areas where sensors are not installed.
  • Page 182 • The indicator may differ from the illustration depending on objects or sensors status. If the indicator blinks, we recommend that the system be checked by an authorized HYUNDAI dealer. • If the audible warning does not sound or if the buzzer sounds inter- mittently when shifting into R (Reverse) position, this may indicate a malfunction with the Parking Assist System.
  • Page 183 Convenient features of your vehicle Non-operational conditions of Parking assist system precau- Detecting range may decrease when: Parking Assist System tions • Outside temperature extremely hot or cold. Parking Assist System may not • The parking assist system may not operate normally when: sound consistently depending on the •...
  • Page 184 A A U U T T O O M M A A T T I I C C C C L L I I M M A A T T E E C C O O N N T T R R O O L L S S Y Y S S T T E E M M ( ( I I F F E E Q Q U U I I P P P P E E D D ) ) 1.

  • Page 185: Automatic Heating And Air Conditioning

    Convenient features of your vehicle Automatic heating and air con- To turn the automatic operation off, select any button of the following: ditioning - Mode selection button The Automatic Climate Control System is controlled by setting the - Front windshield defroster button desired temperature.

  • Page 186: Manual Heating And Air Conditioning

    Manual heating and air condi- 4.Set the air intake control to the out- side (fresh) air position. tioning 5.Set the fan speed control to the The heating and cooling system can be desired speed. controlled manually by pushing buttons other than the AUTO button. In this 6.If air conditioning is desired, turn case, the system works sequentially the air conditioning system on.
  • Page 187 Convenient features of your vehicle Mode selection Defrost-Level (A, D) Most of the air flow is directed to the windshield. Face-Level (B, D) Air flow is directed toward the upper body and face. Additionally, each outlet can be controlled to direct the air discharged from the outlet.
  • Page 188 Temperature control OPDE046352 OPDEN047309 Defrost-Level (A) Instrument panel vents OPD046315 The outlet vents can be opened ( Most of the air flow is directed to the The temperature will increase by or closed ( ) separately using the windshield with a small amount of air turning the knob to the right.

  • Page 189: Automatic Climate Control System

    Convenient features of your vehicle Air intake control Adjusting the driver and passenger side temperature individually Press the “SYNC” button again to adjust the driver and passenger side temperature individually. The button indicator will turn off. Temperature conversion If the battery has been discharged or disconnected, the temperature mode display will reset to Centigrade.
  • Page 190 Fan speed control Recirculated air position (continued) With the recirculated air In addition, prolonged use of the air position selected, air conditioning with the recirculated air from the passenger com- position selected will result in exces- partment will be drawn sively dry air in the passenger com- through the heating sys- partment.
  • Page 191 Convenient features of your vehicle Air conditioning OFF mode System operation Ventilation 1. Set the mode to the position. 2. Set the air intake control to the outside (fresh) air position. 3. Set the temperature control to the desired position. 4.
  • Page 192 Air conditioning Operation Tips NOTICE • To keep dust or unpleasant fumes HYUNDAI Air Conditioning Systems • The refrigerant system should from entering the vehicle through are filled with R-134a or R-1234yf only be serviced by trained and the ventilation system, temporarily refrigerant.
  • Page 193 Convenient features of your vehicle • If you operate the air conditioner Air conditioning system operation NOTICE excessively, the difference between tips • When using the air conditioning the temperature of the outside air • If the vehicle has been parked in system, monitor the temperature and that of the windshield could direct sunlight during hot weather,...
  • Page 194 HYUNDAI dealer. trol air filter be replaced by an author- only be serviced by trained and ized HYUNDAI dealer according to the certified technicians. It is impor- maintenance schedule. If the vehicle is tant that the correct type and...
  • Page 195 Convenient features of your vehicle Air Conditioning refrigerant Each symbols and specification on air conditioning refrigerant label label means as below: ■ Example • Type A 1. Classification of refrigerant 2. Amount of refrigerant 3. Classification of Compressor lubri- cant You can find out which air conditioning refrigerant is applied to your vehicle on the label located inside of the hood.
  • Page 196 W W I I N N D D S S H H I I E E L L D D D D E E F F R R O O S S T T I I N N G G A A N N D D D D E E F F O O G G G G I I N N G G Automatic climate control •...

  • Page 197: Defroster

    Convenient features of your vehicle To defrost outside windshield Defroster If the position is selected, lower fan speed is controlled to higher fan NOTICE speed. To prevent damage to the conduc- tors bonded to the inside surface of the rear window, never use sharp instruments or window cleaners containing abrasives to clean the window.

  • Page 198: Auto Defogging System

    Rear window defroster Auto defogging system Information (if equipped) • If there is heavy accumulation of Auto defogging reduces the possibili- snow on the rear window, brush it off ty of fogging up the inside of the wind- before operating the rear defroster. shield by automatically sensing the •...

  • Page 199: Cluster Ionizer

    Convenient features of your vehicle C C L L I I M M A A T T E E C C O O N N T T R R O O L L A A D D D D I I T T I I O O N N A A L L F F E E A A T T U U R R E E S S Cluster ionizer (if equipped) Sunroof inside air recirculation Information...

  • Page 200: Center Console Storage

    S S T T O O R R A A G G E E C C O O M M P P A A R R T T M M E E N N T T Center console storage Glove box WARNING Never store cigarette lighters, propane cylinders, or other...

  • Page 201: Sunglass Holder

    Convenient features of your vehicle Sunglass holder To close: Push back into position. Make sure the sunglass holder is closed while driving. WARNING • Do not keep objects except sunglasses inside the sun- glass holder. Such objects can be thrown from the holder in the event of a sudden stop or OPD046334 an accident, possibly injuring...

  • Page 202: Ashtray

    I I N N T T E E R R I I O O R R F F E E A A T T U U R R E E S S Ashtray (if equipped) Cup holder Rear (if equipped) Front OPDEN047336 OPDE046419...

  • Page 203: Sunvisor

    Convenient features of your vehicle Sunvisor WARNING WARNING • Keep cans or bottles out of Avoid abrupt starting and direct sun light and do not put braking when the cup holder them in a hot vehicle. It may is in use to prevent spilling explode.

  • Page 204: Power Outlet

    Power outlet (if equipped) The devices should draw less than WARNING 180 W(Watt) with the engine running. ■ Front For your safety, do not block your WARNING view when using the sunvisor. Avoid electrical shocks. Do not NOTICE place your fingers or foreign objects (pin, etc.) into a power Do not put several tickets in the outlet or touch the power outlet...

  • Page 205: Cigarette Lighter

    • Close the cover when not in use. into its socket. When the element is tem and cause system malfunc- (Continued) heated, the lighter will pop out to the tion. “ready” position. We recommend that you use parts for replacement from an authorized HYUNDAI dealer. 3-124...

  • Page 206: Wireless Cellular Phone Charging System

    If not, the wireless charg- There is a wireless cellular phone ing process may be interrupted. Only a genuine HYUNDAI lighter charger inside the front console. should be used in the cigarette 2. The indicator light is orange when The system is available when all lighter socket.

  • Page 207: Clock

    Convenient features of your vehicle (Continued) Clock If your phone is not charging: - Slightly change the position of the • Locate your cell phone well in the WARNING cellular phone on the charging pad. middle of the wireless cellular phone charging system.

  • Page 208: Clothes Hanger

    Clothes hanger (if equipped) Floor mat anchor(s) WARNING (if equipped) ■ Type A OPDE046050 ■ Type B OGSB047265L Do not hang other objects such OPD046343 as hangers or hard objects ALWAYS use the Floor Mat Anchors except clothes. Also, do not put to attach the front floor mats to the heavy, sharp...

  • Page 209: Luggage Net (Holder)

    HYUNDAI designed to securely hold the dealer to obtain a luggage net. floor mat in place. To avoid any interference with pedal operation, HYUNDAI recommends that the HYUNDAI floor mat designed for use in your vehicle be installed. 3-128...

  • Page 210: Cargo Area Cover

    Cargo area cover (if equipped) NOTICE Since the cargo area cover may be damaged or deformed, do not put luggage on it when it is being used. WARNING • Do not place objects on the cargo area cover while driv- ing.

  • Page 211: Multimedia System

    Multimedia System Multimedia system ..........4-2 AUX, USB and iPod port ..........4-2 ® Antenna ................4-2 Steering wheel audio controls ........4-3 Bluetooth Wireless Technology hands-free ..4-4 ® Audio / Video / Navigation system (AVN) ....4-4 How vehicle radio works ..........4-4 Audio (With Touch Screen) ........4-8 Feature of Your Audio .............4-9 Radio .................4-14 Media..................4-17...

  • Page 212: Multimedia System

    Multimedia System M M U U L L T T I I M M E E D D I I A A S S Y Y S S T T E E M M Antenna AUX, USB and iPod ® port Information Shark fin antenna...

  • Page 213: Steering Wheel Audio Controls

    Steering wheel audio controls MODE ( ) (3) SEEK/PRESET ( ) (2) (if equipped) If the SEEK/PRESET toggle switch Press the MODE button to select Radio, Disc, or AUX. is moved up or down and held for 0.8 seconds or more, it will function in ■...

  • Page 214: Bluetooth ® Wireless Technology Hands-Free

    Multimedia System Bluetooth Wireless Technology How vehicle radio works ® (1) Call / Answer button hands-free (2) Call end button FM reception (3) Microphone • Audio : For detailed information, refer to “AUDIO” in this chapter. • AVN : Detailed information for the Bluetooth ®...
  • Page 215 AM (MW, LW) reception FM radio station This can be due to factors, such as the distance from the radio station, closeness of other strong radio sta- tions or the presence of buildings, bridges or other large obstructions in the area. OJF045309L OJF045310L AM broadcasts can be received at...
  • Page 216 Multimedia System Using a cellular phone or a two- way radio When a cellular phone is used inside the vehicle, noise may be produced from the audio system. This does not mean that something is wrong with the audio equipment. In such a case, use the cellular phone at a place as far as possible from the audio equipment.
  • Page 217 The Bluetooth ® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by HYUNDAI is under license. Other trademarks and trade names are those of their respective owners. A Bluetooth ®...
  • Page 218 Multimedia System A A U U D D I I O O ( ( W W i i t t h h T T o o u u c c h h S S c c r r e e e e n n ) ) Type A Type B ■...

  • Page 219: Feature Of Your Audio

    Feature of Your Audio (1) LCD screen (4) POWER/VOLUME knob • Tap the screen to select a button. • Turn to adjust the volume. Head unit • Press to turn the device on or off. (2) RADIO ■ Type A •...
  • Page 220 Multimedia System (6) MEDIA (8) SETUP ■ Type A • Select USB(iPod ® ), Bluetooth ® (BT) • Access Display, Sound, Date/Time, Audio, AUX or My Music. Bluetooth, System, Screensaver and Display Off settings. • Display the media menu when two or more media are connected or when the [MEDIA] button is (9) TUNE knob...
  • Page 221 Steering wheel remote control (4) UP/DOWN • Pressing and holding the button (more than 1.0 seconds) • Press the button in radio mode to search Presets. - If not in Bluetooth ® Handsfree mode or receiving a phone call, • Press and hold the button in radio the most recently Dialled Call mode to search frequencies.
  • Page 222 Multimedia System (Continued) WARNING WARNING • Please refrain from use if the • Driving while distracted can Do not stare at the screen screen is blank or no sound result in a loss of vehicle con- while driving. Staring at the can be heard as these signs trol that may lead to an acci- screen for prolonged periods...
  • Page 223 (Continued) (Continued) NOTICE • Turn on the car engine before • Do not place beverages close to • Operating the device while driv- using this device. Do not oper- the audio system. Spilling bever- ing could lead to accidents due ate the audio system for long ages may lead to system mal- to a lack of attention to external...

  • Page 224: Radio

    Multimedia System Information on status icons Radio Switching between FM and AM • Press the [RADIO] button on the Icons showing audio status are shown audio system to switch between in the upper-right corner of the screen. FM/AM (with RDS) FM and AM.
  • Page 225 DAB/FM (with DAB) Presets Switching between DAB/FM and AM • Press the [RADIO] button on the Save up to 40 frequently used stations. audio system to switch between To listen to a preset, select the DAB/FM and AM. desired station list. •...
  • Page 226 Multimedia System FM/AM (without RDS) Presets Switching between FM and AM • Press the [RADIO] button on the Save up to 40 frequently used stations. audio system to switch between To listen to a preset, select the FM and AM. desired station list.

  • Page 227: Media

    Media Presets Range of supported compressed file types Save up to 40 frequently used stations. Information 1. Bitrate range (Kbps) - Using MP3 To listen to a preset, select the desired station list. Supported audio formats Press and hold the desired slot from 1 through 40.
  • Page 228 Multimedia System 2. Sampling frequency (Hz) 4. Character display range (Unicode) Information • Filenames: Up to 64 English char- - Using the USB Devices acters (64 Korean characters) • Starting the vehicle while a USB • Foldernames: Up to 32 English device is connected can damage the characters (32 Korean characters) device.
  • Page 229 (Continued) (Continued) (Continued) • Some USB devices are not recog- • Use of USB accessories, including • Operation is guaranteed only for nized due to compatibility issues. charge and heat though the USB I/F, standard (Metal Cover Type) USB can lead to reduced product per- Memory drives.
  • Page 230 Multimedia System (6) Pause Pause or play music. (7) Playback progress Select to skip to the desired location. Playback • Press the [MEDIA] button, and Selecting songs from a list select [USB]. Select [List] to see a list of songs •...
  • Page 231 Menu (4) Save: Save the selected file(s) Information - Select the files you want to save, Select [Menu], and select the desired The repeat folder function is available and select [Save]. This saves the function. only when songs are playing from the selected files to My Music.
  • Page 232 Multimedia System (Continued) (Continued) Information • There may be noise if the audio sys- • The search and song play order in - Using the iPod ® Devices tem is used with an iPod ® or AUX the iPod ® device may be different •...
  • Page 233 iPod ® (6) Pause Repeat play Pause or play music. Select [Repeat] to enable or disable ‘Repeat category’, ‘Repeat current song’ play. (7) Playback progress • Repeat category: Repeat all Select to skip to the desired location. songs in the current category. •...
  • Page 234 Multimedia System When other music programs are Playing iPod files Information running • Select [iPod files] to play songs - Using Bluetooth ® (BT) Audio saved on your iPod ® • Bluetooth ® Audio mode can only be If there are no songs saved on your used if a Bluetooth ®...
  • Page 235 ® Bluetooth (BT) Audio NOTICE Information • Bluetooth ® Handsfree is a fea- • Some cell phone models may not ture that enables drivers to prac- support particular functions. tice safe driving. Connecting the • Bluetooth ® audio volume is synced audio system with...
  • Page 236 Multimedia System My Music Information The repeat play function is engaged, depending on the operation of the con- nected Bluetooth ® device. Shuffle play Select [Shuffle] to enable or disable ‘Shuffle’, ‘Shuffle category’ play. • Shuffle: Songs are played in random order.
  • Page 237 (6) Pause Shuffle play Pause or play music. Select [Shuffle] to enable or disable ‘Shuffle’, ‘Shuffle category’ play. (7) Playback progress • Shuffle: Songs are played in random order. Select to skip to the desired location. • Shuffle category: Songs within the current category are played in Playback random order.

  • Page 238: Phone

    Multimedia System Phone (4) Delete: Delete the selected file(s) (Continued) - Select the file to delete, then • When Bluetooth ® is connected and select [Delete] to delete it. Information calls are attempted through a con- nected cell phone from outside the - Using Bluetooth ®...
  • Page 239 Safety precautions Precautions when connecting • Even if your device supports Bluetooth ® , a Bluetooth ® connec- Bluetooth ® devices • The Bluetooth ® Handsfree function tion cannot be established if the helps drivers to drive safely. By • The vehicle supports the following device’s Bluetooth ®...
  • Page 240 Multimedia System Pairing a Bluetooth device • Some Bluetooth ® devices are sub- ® ject to intermittent Bluetooth ® con- ® Information on pairing Bluetooth nection failures. In this case, use devices the following method. • Pairing refers to the process of 1) Turn the Bluetooth ®...
  • Page 241 4-1. For devices that require passkey Information Information entry, a passkey entry screen is • Bluetooth ® standby mode lasts for The 6-digit passkey in the image shown your Bluetooth ® three minutes. If a device is not above is an example. Refer to your device.
  • Page 242 Multimedia System Connecting Bluetooth devices Accepting/rejecting phone calls ® If there are connected devices If there are no connected devices Press the [PHONE] button on the Receiving phone calls with Bluetooth ® audio system ➟ Select [Settings] ➟ connected. Press the [PHONE] button on the Select [Connections] Select...
  • Page 243 Operation during calls Information Information Incoming call with Bluetooth ® con- • When the incoming call screen is • Some Bluetooth ® devices may not nected ➟ Select [Accept]. displayed, audio mode and the set- support the Private function. tings screen cannot be shown. Only •...
  • Page 244 Multimedia System Call history Contacts (2) Add to favourites: Add a down- loaded phone number Press the [PHONE] button on the Press the [PHONE] button on the favourites. audio system ➟ Select [Call history] audio system ➟ Select [Contacts] ➟ (3) Delete: Delete a saved favourites.
  • Page 245 Dial (5) Call Information Press the [PHONE] button on the - Enter and select a phone num- • Only supported contacts format can ber to call. audio system ➟ Select [Dial]. be downloaded and displayed from - Select without entering a phone the Bluetooth device, contacts from number to see the most recent some applications will not be included.

  • Page 246: Setup

    Multimedia System Setup Display Date/Time Press the [SETUP] button on the Press the [SETUP] button on the audio system ➟ Select [Display]. audio system ➟ Select [Date/Time]. • Dimming mode: Adjusts the bright- • Set time: Set the time displayed on ness automatically according to sur- the audio screen.
  • Page 247 System Display Off Information Press the [SETUP] button on the To prevent glare, the screen can be • When paired devices are deleted, audio system ➟ Select [System]. turned off with the audio system in the call history and contacts of the operation.

  • Page 248: Ce For Eu

    Multimedia System D D e e c c l l a a r r a a t t i i o o n n o o f f C C o o n n f f o o r r m m i i t t y y CE for EU 4-38...

  • Page 249: Driving Your Vehicle

    Driving your vehicle Before driving............5-4 Electronic limited slip differential .....5-38 Before entering the vehicle ...........5-4 Warning messages ............5-39 Before starting..............5-4 Drive Mode integrated control system.....5-40 Ignition switch ............5-6 DRIVE MODE button............5-40 Key ignition switch............5-6 N button................5-41 Engine Start/Stop button..........5-9 Vehicle characteristic.............5-43 Manual transmission..........5-14 ISG (Idle Stop and Go) system......5-44 Manual transmission operation ........5-14...
  • Page 250 Lane Keeping Assist System (LKAS)....5-64 Special driving conditions........5-88 LKAS operation..............5-66 Hazardous driving conditions........5-88 Warning light and message ..........5-69 Rocking the vehicle ............5-88 Limitations of the system ..........5-71 Smooth cornering ............5-89 LKAS function change ...........5-72 Driving at night ..............5-89 Driving in the rain ............5-89 Lane Departure Warning System (LDWS)..5-73 Driving in flooded areas..........5-90 LDWS operation...............5-74...
  • Page 251 HYUNDAI dealer.

  • Page 252: Before Entering The Vehicle

    Driving your vehicle B B E E F F O O R R E E D D R R I I V V I I N N G G Before entering the vehicle Before starting WARNING • Be sure all windows, outside mir- •...
  • Page 253 (Continued) WARNING You are much more likely to have NEVER drink or take drugs and a serious accident if you drink or drive. take drugs and drive. If you are drinking or taking drugs, don't Drinking or taking drugs and drive.

  • Page 254: Key Ignition Switch/

    Driving your vehicle I I G G N N I I T T I I O O N N S S W W I I T T C C H H Key ignition switch (if equipped) (Continued) WARNING This will result in the engine To reduce the risk of SERIOUS turning off and loss of power START...
  • Page 255 Key ignition switch positions Switch Action Notes Position To turn the ignition switch to the LOCK position, push the key in at the ACC position and turn the key towards the LOCK position. The ignition key can be removed in the LOCK position. LOCK The steering wheel locks to protect the vehicle from theft.
  • Page 256 Driving your vehicle Starting the engine 1. Make sure the parking brake is NOTICE applied. To prevent damage to the vehicle: WARNING 2. Make sure the shift lever is in neu- • Do not hold the ignition key in tral. the START position for more •...

  • Page 257: Engine Start/Stop Button

    Engine Start/Stop button WARNING WARNING (if equipped) • To turn the engine off in an NEVER press the Engine Start/ emergency: Stop button while the vehicle is in motion except in an emer- Press and hold the Engine gency. This will result in the Start/Stop button for more than engine turning off and loss of two seconds OR Rapidly press...
  • Page 258 Driving your vehicle Engine Stop/Start button positions Button Position Action Notes To turn off the engine, stop the vehicle and If the steering wheel is not locked properly then press the Engine Start/Stop button. when you open the driver's door, the warning chime will sound.
  • Page 259 Button Position Action Notes Press the Engine Start/Stop button while it Do not leave the Engine Start/Stop button in is in the ACC position without depressing the ON position when the engine is not run- the clutch pedal. ning to prevent the battery from discharging. The warning lights can be checked before the engine is started.
  • Page 260 Driving your vehicle Starting the engine Information Information • The engine will start by pressing the • Do not wait for the engine to warm WARNING Engine Start/Stop button, only when up while the vehicle remains station- the smart key is in the vehicle. ary.
  • Page 261 Turning off the engine NOTICE 1. Stop the vehicle and depress the To prevent damage to the vehicle: clutch and brake pedals at the Do not press the Engine Start/ same time. Stop button for more than 10 sec- 2. With the clutch and brake pedals onds except when the stop lamp depressed, put the shift lever in fuse is blown.

  • Page 262: Manual Transmission Operation

    Driving your vehicle M M A A N N U U A A L L T T R R A A N N S S M M I I S S S S I I O O N N Manual transmission operation To shift to R (Reverse), make sure the vehicle has completely stopped, The manual transmission has 6 for-...
  • Page 263 Using the clutch Downshifting NOTICE clutch pedal should Downshift when you must slow down To prevent unnecessary wear or depressed all the way to the floor in heavy traffic or drive up a steep damage to the clutch: before: hill, to prevent engine load. •...
  • Page 264 Driving your vehicle Good driving practices • Exercise extreme caution when NOTICE driving on a slippery surface. Be • Never take the vehicle out of gear To prevent damage to the engine, especially careful when braking, and coast down a hill. This is clutch and transmission: accelerating or shifting gears.

  • Page 265: Rev Matching

    In a collision, an unbelted improves gear shift response. occupant is significantly more • HYUNDAI recommends you likely to be seriously injured follow all posted speed limits. Information or killed than a properly belt- ed occupant.
  • Page 266 Driving your vehicle Rev Matching activation ■ DRIVE MODE button ■ REV indicator OPDEN057494 OPDEN047447 2. Select Drive Mode. OPDEN047435 DRIVE MODE button 1. Press REV button (ON/OFF) Use Rev Matching in normal driving conditions in below modes. • Press the REV button to turn on the system.
  • Page 267 Rev Matching operation ■ N button ■ REV indicator Engine speed is automatically syn- chronized with the next selected gear. The accelerator pedal does not have to be depressed to speed up the engine rpm. • Clutch depressed with the gear engaged At once, engine speed automatically decreases right after the clutch is...
  • Page 268 Driving your vehicle Warning message OPDEN047443 Beware of engine damage when shifting while in high RPM If transmission input rpm is too high (over rev limit) due to shifting, a warning message will appear and a warning chime will sound. 5-20...

  • Page 269: Prerequisite For Activation

    L L A A U U N N C C H H C C O O N N T T R R O O L L Launch control activation The Launch Control system controls the vehicle to reduce wheel spin or To activate Launch Control: slip on a hard acceleration from a standing start.
  • Page 270 Driving your vehicle 7. A smooth, quick release of the CAUTION clutch, while maintaining full depression of the accelerator • The Launch Control system is pedal will initiate launching of the intended for use at a closed vehicle. Do not rapidly drop the race track and not intended clutch pedal as it may damage for use on public roads.

  • Page 271: Power Brakes

    B B R R A A K K I I N N G G S S Y Y S S T T E E M M Power brakes (Continued) WARNING Your vehicle has power-assisted • Wet brakes may impair the brakes that adjust automatically Take the following precautions: vehicle's ability to safely slow...

  • Page 272: Disc Brakes Wear Indicator

    To avoid costly brake repairs, do worn-out. We recommend that not continue to drive with worn the vehicle be checked by an brake pads. authorized HYUNDAI dealer. • If the vehicle has continuous Information vibration or shudder in the Always replace brake pads as com- steering wheel while braking, we plete front or rear axle sets.

  • Page 273: Parking Brake

    NEVER allow anyone who is recommend that the system be unfamiliar with the vehicle to To reduce the risk of SERIOUS checked by an authorized HYUNDAI touch the parking brake. If the INJURY or DEATH, do not oper- parking brake is released dealer.

  • Page 274: Anti-Lock Brake System (Abs)

    Driving your vehicle Anti-lock Brake System (ABS) Check Parking (Continued) Brake Warning Light • Only release the parking brake by placing the ignition WARNING when you are seated inside the switch to the ON posi- vehicle with your foot firmly on tion (do not start the An Anti-Lock Braking System the brake pedal.
  • Page 275 ABS. We ABS will not prevent a skid that recommend that you contact an results from sudden changes in authorized HYUNDAI dealer as soon direction, such as trying to take a as possible. corner too fast or making a sudden lane change.

  • Page 276: Electronic Stability Control (Esc)

    ABS is malfunctioning. injury or death, we recommend going. ESC applies braking pressure Have the battery recharged before that you contact your HYUNDAI to any one of the vehicle's brakes driving the vehicle. dealer as soon as possible.
  • Page 277 ESC operation Deactivating / Activating ESC When operating When the ESC is in operation, the ESC ON condition ESC indicator light blinks: When the ignition switch is • When you apply your brakes under in the ON position, the ESC conditions which may lock the and the ESC OFF indicator lights illu- wheels, you may hear sounds from...

  • Page 278: Esc Off Button

    Driving your vehicle In the following situations, it may be WARNING better to activate ESC SPORT or deactivate ESC (ESC OFF): • If you deactivate ESC, ESC no • When using snow chains longer stabilizes the vehicle. • Driving in deep snow There is an increased risk of skidding and an accident.
  • Page 279 ESC system. When this tires and wheels are the same warning light illuminates we recom- size. Never drive the vehicle with mend that the vehicle be checked by different sized wheels and tires an authorized HYUNDAI dealer as installed. soon as possible. 5-31...
  • Page 280 Driving your vehicle Drive mode selection NOTICE WARNING When the ESC is on, the character- To prevent damage to the trans- istic of ESC varies according to Don't use ESC SPORT mode or mission: which drive mode is selected by ESC OFF while using a minis- •...

  • Page 281: Vehicle Stability Management

    Vehicle Stability Management CUSTOM mode You may select the drive mode you The Vehicle Stability Management prefer from the Audio or AVN screen. (VSM) is a function of the Electronic Stability Control (ESC) system. It • Select CUSTOM mode by pressing helps ensure the vehicle stays stable the N button on the steering wheel.
  • Page 282 ( ) is on or blinks. vehicle be checked by an • Vehicle speed is approximately authorized HYUNDAI dealer as above 20 km/h (12 mph) when the soon as possible. vehicle is braking on rough roads. NOTICE...

  • Page 283: Hill-Start Assist Control (Hac)

    Hill-Start Assist Control (HAC) Emergency Stop Signal (ESS) The hazard warning flasher turns OFF: (if equipped) The Hill-Start Assist Control (HAC) • When the vehicle drives at a low helps prevent the vehicle from rolling The Emergency Stop Signal system speed for a certain period of time.

  • Page 284: Good Braking Practices

    LOCK/OFF posi- do so and we recommend that you tion. call an authorized HYUNDAI dealer for assistance. Vehicles parked with the park- DO NOT drive with your foot resting ing brake not applied or not on the brake pedal.
  • Page 285 OPDEN047433 Check ECS If the ECS warning message comes on, you may have a problem with the ECS system. We recommend that you have the system checked by an authorized HYUNDAI dealer. 5-37...

  • Page 286: Electronic Limited Slip Differential

    Driving your vehicle E E L L E E C C T T R R O O N N I I C C L L I I M M I I T T E E D D S S L L I I P P D D I I F F F F E E R R E E N N T T I I A A L L ( ( I I F F E E Q Q U U I I P P P P E E D D ) ) Drive mode selection Electronic Limited Slip Differential CUSTOM mode...

  • Page 287: Warning Messages

    Electronic Limited Slip Differential, Electronic Limited Slip Differential porarily disable e-LSD. Wait until the equip the vehicle with the same tires system. We recommend that you vehicle cools down. on the front. have the system checked by an authorized HYUNDAI dealer 5-39...
  • Page 288 Driving your vehicle D D R R I I V V E E M M O O D D E E I I N N T T E E G G R R A A T T E E D D C C O O N N T T R R O O L L S S Y Y S S T T E E M M DRIVE MODE button ECO mode The mode changes, whenever the...

  • Page 289: N Button

    Limitation of ECO mode opera- SPORT mode N button tion: SPORT mode manages If the following conditions occur while the driving dynamics by ECO mode is operating, the system automatically adjusting the operation is limited even though steering effort, the engine there is no change in ECO indicator.
  • Page 290 Driving your vehicle N mode CUSTOM mode The mode changes, whenever the N button is pressed. N mode selects the proper In CUSTOM mode, the driving mode among driver can select the drive N Custom mode N mode ■ ■ SPORT and SPORT+ for mode for each component each components that will...

  • Page 291: Vehicle Characteristic

    Vehicle characteristic The characteristic of each components varies according to which drive mode is selected by pressing the DRIVE MODE or N button on the steering wheel. DRIVE MODE Button N Button Component ECO mode NORMAL mode SPORT mode N mode CUSTOM mode NORMAL / SPORT / Engine...

  • Page 292: To Activate The Isg System

    ) illuminates in yellow function with the ISG system. on the instrument cluster. • When the above indicator remains illuminated on the instrument clus- ter, we recommend that you have the ISG system checked by an authorized HYUNDAI dealer. 5-44...
  • Page 293 Auto stop In auto stop mode, when the driver opens the hood, the ISG system will To stop the engine in idle stop mode be deactivated. When the system is deactivated: OTLE055036 The message, "Auto Stop deactivat- ed. Start manually", appears on the LCD display with a beep sound.
  • Page 294 Driving your vehicle Auto start The engine is automatically restart- ed in the following situations. To restart the engine in the auto - The fan speed of the manual cli- stop mode mate control system is set above • Depress the clutch pedal with the the 3rd position, with the air condi- gear in N (Neutral).

  • Page 295: To Deactivate The Isg System

    The followings occur, when there is LCD display. an authorized HYUNDAI dealer. a malfunction with the ISG system: • Press the ISG OFF button again to • You can turn off the ISG OFF but- •...

  • Page 296: The Battery Sensor Deactivation

    Prerequisites to reactivate the NOTICE tion battery sensor • Use only the genuine HYUNDAI Keep the engine in the OFF status ISG battery for replacement. If for 4 hours, and attempt to restart the not, the ISG system may not nor- engine 3 to 4 times for the battery- mally operate.

  • Page 297: Autonomous Emergency Braking (Aeb)

    ON when the AEB is acti- ring. AEB does not stop the vated, we recommend that you have vehicle completely and is not the system checked by an authorized a collision avoidance system. HYUNDAI dealer. 5-49...
  • Page 298 Driving your vehicle Prerequisite for activation • The driver can select the initial warn- - Normal: ing activation time on the LCD dis- When this condition is selected, The AEB gets ready to be activated, play. initial Forward Collision when the AEB is selected on the Go to the 'User Settings →...

  • Page 299: Aeb Warning Message And System Control

    AEB warning message and Forward Warning (1 warning) WARNING system control The AEB produces warning mes- • Completely stop the vehicle sages and warning alarms in accor- on a safe location before dance with the collision risk levels, operating the switch on the such as abrupt stopping of the vehi- steering wheel to activate/ cle in front, insufficient braking dis-...
  • Page 300 Driving your vehicle Collision Warning (2 warning) Emergency braking Brake operation warning) • In an urgent situation, the braking system enters into the ready status for prompt reaction against the dri- ver's depressing the brake pedal. • The AEB provides additional brak- ing power for optimum braking per- formance, when...

  • Page 301: Aeb Sensor

    Have the vehicle adversely affect the sensing perform- conditions may affect the oper- inspected authorized ance of the camera. ation of the AEB system. HYUNDAI dealer. WARNING Never deliberately drive danger- ously to activate the system. 5-53...

  • Page 302: Warning Message And Warning Light

    We recommend that you have the sys- play. tem checked by an authorized Remove any dirt, snow, or debris and HYUNDAI dealer when: clean the camera sensor cover • The windshield glass is replaced. before operating the AEB system. The system will operate normally •...
  • Page 303 The AEB system HYUNDAI dealer. brake pedal to avoid a colli- may not activate and the sion. • The AEB warning message may...

  • Page 304: Limitations Of The System

    Driving your vehicle Limitations of the system • There is interference by electro- WARNING magnetic waves The Autonomous Emergency Braking • The camera sensor recognition is (AEB) system is designed to monitor • The AEB system operates only limited the vehicle ahead on the roadway to detect vehicles in front of the through camera recognition to warn •...
  • Page 305 • The windshield glass is fogged up; a clear view of the road is obstruct- • The vehicle in front is driving errat- ically • The vehicle is on unpaved or uneven rough surfaces, or road with sudden gradient changes. •...
  • Page 306 Driving your vehicle OPDE056102 OAE056103 OAE056109 - Driving on a slope - Changing lanes When driving in stop-and-go traffic, and a stopped vehicle in front of you The performance of the AEB decreas- When a vehicle changes lanes in merges out of the lane, the AEB sys- es while driving upward or downward front of you, the AEB system may not tem may not immediately detect the...
  • Page 307 Information WARNING In some instances, the AEB system • Do not use the Autonomous may be cancelled when subjected to Emergency Braking system electromagnetic interference. when towing vehicle. Application of the AEB sys- while towing adversely affect the safety of your vehicle or the towing vehicle.
  • Page 308 HYUNDAI dealer when: mation. The SLIF also utilizes the navigation • The windshield glass is replaced. Therefore, the SLIF may not information to display the speed limit •...

  • Page 309: System Setting And Activation

    System setting and activation System activation Display • The SLIF displays the speed limit System setting ■ No reliable speed limit information information and displays the over- • The driver can activate the SLIF by taking restriction, when your vehi- selecting 'User Settings →...

  • Page 310: Warning Message

    The SLIF does not operate, until objects removed. Check the windshield glass around the camera area. If the prob- lem persists after removing the objects, we recommend that you have the system checked by an authorized HYUNDAI dealer. 5-62...

  • Page 311: Limitations Of The System

    We recommend that you have the system checked by an authorized • The road signs do not correspond When front visibility is poor HYUNDAI dealer. to the standard, etc. • The weather is bad, such as rain- ing, snowing, and fogging.

  • Page 312: Lane Keeping Assist System Lkas)/

    If you disassemble the camera and assemble it again, we recommend that you take your WARNING vehicle to an authorized HYUNDAI OPDEN057048 dealer and have the system The Lane Keeping Assist System Take the following precautions checked for calibration.
  • Page 313 • Do not place objects on the HYUNDAI dealer and have the may not assist steering or the dashboard that reflects light system checked for calibra- hands off alarm may not work such as mirrors, white paper, tion.

  • Page 314: Lkas Operation

    Driving your vehicle LKAS operation LKAS activation The color of indicator will change depending on the condition of LKAS. - White : Sensor does not detect lane markers or vehicle speed is under 60 km/h (40mph). - Green : Sensor detects lane mark- ers and the system is able to control vehicle steering.
  • Page 315 • If your vehicle speed exceeds 60 Lane line undetected Lane line detected ■ ■ WARNING km/h (40 mph) and the LKAS but- ton is ON, the system is enabled. If Lane Keeping Assist your vehicle departs from the pro- System is a system to prevent jected lane in front of you, the the driver from leaving the lane.
  • Page 316 Driving your vehicle ■ Left lane marker ■ Right lane marker WARNING The warning message may appear late according to road conditions. Therefore, always have your hands on the steering wheel while driving. OPDEN057056/OPDEN057057 OAEE056129L A visual warning appears on the Keep hands on steering wheel cluster LCD display.

  • Page 317: Warning Light And Message

    Warning light and message WARNING Check LKAS • The driver is responsible for accurate steering. • Turn off the system and drive the vehicle in below situa- tions. - In bad weather - In bad road condition - When the steering wheel OPDEN057130 needs to be controlled by the Grasp not detected.
  • Page 318 If the problem is not solved, we rec- mph). ommend that the system be checked • The vehicle makes sharp lane by an authorized HYUNDAI dealer. changes. • The vehicle brakes suddenly. • Only one lane marker is detected. • The lane is very wide or narrow.

  • Page 319: Limitations Of The System

    Limitations of the system • The lane marker is very thick or When external condition is inter- thin. vened The LKAS may operate prematurely • The lanes ahead are not visible • The brightness outside changes even if the vehicle does not depart due to rain, snow, water on the suddenly such as when entering or from the intended lane, OR, the...

  • Page 320: Lkas Function Change

    Driving your vehicle LKAS function change Standard LKA • The adverse road conditions cause excessive vehicle vibrations while The Standard LKA mode guides the The driver can change LKAS to Lane driving. driver to help keep the vehicle within Departure Warning System (LDWS) •...
  • Page 321 The LDWS does not control HYUNDAI dealer and have the the vehicle to change lanes or system checked for calibra- to stay in the current lane. OPDEN057048 tion.

  • Page 322: Ldws Operation

    Driving your vehicle LDWS operation The color of indicator will (Continued) change depending on the • Do not place objects that condition of LDWS. reflect light on the dashboard - White : Sensor does not detect while driving. lane markers or vehicle •...

  • Page 323: Warning Light And Message

    Warning light and message • If your vehicle speed exceeds 60 ■ Lane marker ■ Lane marker undetected detected km/h (40 mph) and the LDWS but- Check LDWS ton is ON, the system is enabled. If your vehicle departs from the pro- jected lane in front of you, the LDWS operates as follows: ■...

  • Page 324: Limitations Of The System

    LDWS may not warn you if the vehi- mend that you have your vehicle surface, or other factors. cle leaves the intended lane under checked by an authorized HYUNDAI the following circumstances: • The shadow is on the lane marker dealer.
  • Page 325 When front visibility is poor • There is a boundary structure in the roadway such as a concrete • The windshield or the LDWS cam- barrier, guardrail and reflector post era lens is blocked with dirt or that is inadvertently being detected debris.

  • Page 326: System Setting And Activation

    Driving your vehicle D D R R I I V V E E R R A A T T T T E E N N T T I I O O N N A A L L E E R R T T S S Y Y S S T T E E M M ( ( D D A A A A ) ) ( ( I I F F E E Q Q U U I I P P P P E E D D ) ) Display of the driver's attention The Driver Attention Alert (DAA) sys- •...

  • Page 327: Resetting The System

    Take a break Resetting the system • The driver can monitor their driving conditions on the LCD display. • The last break time is set to 00:00 The DAA screen will appear when and the driver's attention level is you select the Assist mode tab set to 5 (very attentive) when the ) on the LCD display if the sys- driver resets the Driver Attention...

  • Page 328: System Standby

    HYUNDAI dealer. - Driving speed remains under 60 gestion by the Driver Attention km/h (40 mph) or over 200 km/h Alert system.
  • Page 329 • The vehicle drives on a curvy again, we recommend that you road. take your vehicle to an author- ized HYUNDAI dealer and have • The vehicle drives on a the system checked for calibra- bumpy road. tion.

  • Page 330: Cruise Control Operation

    Driving your vehicle C C R R U U I I S S E E C C O O N N T T R R O O L L ( ( I I F F E E Q Q U U I I P P P P E E D D ) ) Cruise Control operation (Continued) WARNING...
  • Page 331 NOTICE Information During cruise-speed driving of a • During normal cruise control opera- manual transmission vehicle, do tion, when the SET switch is activat- not shift into neutral without ed or reactivated after applying the depressing the clutch pedal, since brakes, the cruise control will acti- the engine will be overrevved.
  • Page 332 Driving your vehicle To set Cruise Control speed To increase Cruise Control speed OPDEN057119 3. Push the toggle switch down OPDEN057118 (SET-), and release it. The SET OPDEN057120 indicator light will illuminate. 1. Press the button on the steer- • Push the toggle switch up (RES+) ing wheel to turn the system on.
  • Page 333 To decrease Cruise Control To temporarily accelerate with • Push the toggle switch up (RES+) and release it immediately. The speed the Cruise Control ON cruising speed will increase 2.0 Depress the accelerator pedal. When km/h (1.2 mph) each time the tog- you take your foot off the accelerator, gle switch is operated in this man- the vehicle will return to the previ-...
  • Page 334 Driving your vehicle Cruise Control will be canceled To resume preset Cruising • Decreasing the vehicle speed to less than approximately 30 km/h when: speed (20 mph). • The ESC (Electronic Stability Control) is operating. Information Each of the above actions will cancel Cruise Control operation (the SET indicator light in the instrument clus- ter will go off), but only pressing the...
  • Page 335 To turn Cruise Control off OPDEN057115 • Press button (the indicator light will go off). 5-87...

  • Page 336: Hazardous Driving Conditions

    Driving your vehicle S S P P E E C C I I A A L L D D R R I I V V I I N N G G C C O O N N D D I I T T I I O O N N S S Hazardous driving conditions Rocking the vehicle WARNING...

  • Page 337: Smooth Cornering

    Smooth cornering Driving in the rain Information Avoid braking or gear changing in Rain and wet roads can make driving The ESC system (if equipped) must be corners, especially when roads are dangerous. Here are a few things to turned OFF before rocking the vehi- wet.

  • Page 338: Driving In Flooded Areas

    Driving your vehicle Driving in flooded areas Fuel, engine coolant and engine • If you believe your brakes may be wet, apply them lightly while driv- Avoid driving through flooded areas ing until normal braking operation Driving at higher speeds on the high- unless you are sure the water is no returns.

  • Page 339: Winter Driving

    W W I I N N T T E E R R D D R R I I V V I I N N G G Snow or icy conditions Snow tires The severe weather conditions of winter quickly wear out tires and You need to keep sufficient distance cause other problems.
  • Page 340 If recommendations. tire chains must be used, use gen- uine HYUNDAI parts and install the tire chain after reviewing the instruc- Information tions provided with the tire chains.
  • Page 341 Chain Installation behind the vehicle (if available). Information Always place the vehicle in P (Park), • Install tire chains on the front tires. apply the parking brake and turn off It should be noted that installing tire the engine before installing snow chains on the tires will provide a chains.

  • Page 342: Winter Precautions

    It is the only type of pension, body and wheels. HYUNDAI dealer or in a service sta- coolant that should be used because tion. • Use SAE "S" class or wire it helps prevent corrosion in the cool- chains.
  • Page 343 HYUNDAI dealer, and most vehicle When there is the risk that your park- To prevent locks from freezing accessory outlets.
  • Page 344 Ask an equipment and/or drive improp- maximum laden mass of the vehicle authorized HYUNDAI dealer for fur- erly, you can lose control of the may be exceeded by not more than ther details before towing.

  • Page 345: If You Decide To Pull A Trailer

    • When towing a trailer, be sure to What is the maximum safe weight of The tongue load is an important consult an authorized HYUNDAI a trailer? It should never weigh more weight to measure because it affects dealer for further information on...
  • Page 346 Driving your vehicle Reference weight and distance when towing a trailer (for Europe) WARNING Item Theta 2.0 T-GDI Take the following precautions: With brake system 1600 (3527) • Never load a trailer with more Maximum trailer weight weight in the rear than in the kg (Ibs.) Without brake system 700 (1543)

  • Page 347: Trailer Towing Equipment

    Use behind the rear tires. only a frame-mounted hitch that does not attach to the bumper. • A HYUNDAI trailer hitch accessory is available at an authorized HYUNDAI dealer. 5-99...

  • Page 348: Driving With A Trailer

    Driving your vehicle Trailer brakes Driving with a trailer Distance If your trailer is equipped with a brak- Stay at least twice as far behind the Towing a trailer requires a certain ing system, make sure it conforms to vehicle ahead as you would when amount of experience.
  • Page 349 The green Consult an authorized HYUNDAI arrows on your instrument panel will dealer for assistance. flash whenever you signal a turn or lane change.
  • Page 350 Driving your vehicle (Continued) Parking on hills NOTICE • When towing a trailer, your vehi- Generally, if you have a trailer To prevent engine and/or trans- cle speed may be much slower attached to your vehicle, you should mission overheating: than the general flow of traffic, not park your vehicle on a hill.

  • Page 351: Maintenance When Towing A Trailer

    Ready to leave after parking on Maintenance when towing a 7. Move the shift lever to 1st gear when the vehicle is parked on a a hill trailer uphill grade and in R (Reverse) on 1. With the shift lever in neutral, Your vehicle will need service more a downhill.
  • Page 352 Driving your vehicle NOTICE To prevent vehicle damage: • Due to higher load during trailer usage, overheating might occur on hot days or during uphill driv- ing. If the coolant gauge indi- cates over-heating, switch off the air conditioner and stop the vehicle in a safe area to cool down the engine.

  • Page 353: Vehicle Weight

    V V E E H H I I C C L L E E W W E E I I G G H H T T GAW (Gross Axle Weight) Overloading Two labels on your driver’s door sill show how much weight your vehicle This is the total weight placed on was designed to carry: the Tire and WARNING...

  • Page 354: What To Do In An Emergency

    What to do in an emergency Hazard warning flasher ........6-2 If you have a flat tire (with tire mobility kit) - Type A ..............6-23 In case of an emergency while driving ....6-2 Introduction ..............6-23 If the engine stalls while driving ........6-2 Notes on the safe use of the Tire Mobility Kit..6-24 If the engine stalls at a crossroad or crossing ..6-2 Components of the Tire Mobility Kit ......6-25...

  • Page 355: If The Engine Stalls While Driving

    OPD066001 ized HYUNDAI dealer. The hazard warning flasher serves as a warning to other drivers to exer- If the engine stalls at a cross-...

  • Page 356: If You Have A Flat Tire While Driving

    I I F F T T H H E E E E N N G G I I N N E E W W I I L L L L N N O O T T S S T T A A R R T T If you have a flat tire while •...

  • Page 357: If The Engine Turns Over Normally But Doesn't Start

    HYUNDAI dealer for assistance. service technician or towing service Keep batteries out of do it for you.

  • Page 358: Jump Starting

    Jump starting procedure NOTICE (Continued) 1. Position the vehicles close enough • When lifting a plastic-cased To prevent damage to your vehi- that the jumper cables will reach, battery, excessive pressure cle: but do not allow the vehicles to on the case may cause battery •...
  • Page 359 5. Connect the other end of the apparent, have your vehicle checked jumper cable to the red, positive by an authorized HYUNDAI dealer. (+) battery/jumper terminal of the assisting vehicle (2). 6. Connect the second jumper cable...
  • Page 360 If the fan is not running, we recommend that you call an cap, using a thick towel, and turn the engine off. authorized HYUNDAI dealer for continue turning counterclock- assistance. wise to remove it.

  • Page 361: Check Tire Pressure

    7. Proceed with caution, keeping alert for further signs of overheat- OPD066009 ing. If overheating happens again, we recommend that you call an authorized HYUNDAI dealer for OPDEN047205 assistance. • You can check the tire pressure in the Assist mode on the cluster.

  • Page 362: Tire Pressure Monitoring System

    Tire pressure monitoring sys- • The displayed tire pressure values As an added safety feature, your may differ from those measured vehicle has been equipped with a tire with a tire pressure gauge. pressure monitoring system (TPMS) that illuminates a low tire pressure •...

  • Page 363: Low Tire Pressure Telltale

    If any of the below happens, we indicate when the system is not recommend that the system be operating properly. The TPMS mal- checked by an authorized HYUNDAI function indicator is combined with dealer. the low tire pressure telltale. When...
  • Page 364 If either telltale illuminates, immedi- NOTICE WARNING ately reduce your speed, avoid hard The spare tire is not equipped with cornering and anticipate increased Low pressure damage a tire pressure sensor. stopping distances. You should stop and check your tires as soon as pos- Significantly low tire pressure sible.

  • Page 365: Tpms (Tire Pressure Monitoring System) Malfunction Indicator

    NEVER use a puncture-repair- tions, government and public We recommend that the system be ing agent to repair and/or inflate offices, broadcasting stations, checked by an authorized HYUNDAI military installations, airports, a low pressure tire. The tire dealer. or transmitting towers, etc. This...
  • Page 366 If you drive the vehicle for about 10 You may not be able identify a tire WARNING minutes at speeds above 25 km/h with low pressure by simply looking after replacing the low pressure tire at it. Always use a good quality tire •...
  • Page 367 • If you use the wheels on the market, use a TPMS sensor approved by a HYUNDAI deal- er. If your vehicle is not equipped with a TPMS sensor or TPMS does not work prop-...

  • Page 368: Jack And Tools

    I I F F Y Y O O U U H H A A V V E E A A F F L L A A T T T T I I R R E E ( ( W W I I T T H H S S P P A A R R E E T T I I R R E E , , I I F F E E Q Q U U I I P P P P E E D D ) ) Jack and tools WARNING Changing a tire can be danger-...

  • Page 369: Changing Tires

    What to do in an emergency Changing tires (Continued) • ALWAYS place the jack on the WARNING designated jacking positions on the vehicle and NEVER on A vehicle can slip or roll off of a the bumpers or any other part jack causing serious injury or of the vehicle for jacking sup- death to you or those nearby.
  • Page 370 Follow these steps to change your vehicle's tire: 1. Park on a level, firm surface. 2. Move the shift lever into neutral, apply the parking brake, and place the ignition switch in the LOCK/ OFF position. 3. Press the hazard warning flasher button.
  • Page 371 What to do in an emergency 9. Loosen the lug nuts with the wheel lug nut wrench and remove them with your fingers. Remove the wheel from the studs and lay it flat on the ground out of the way. Remove any dirt or debris from the studs, mounting surfaces, and Front...
  • Page 372 13. Use the wheel lug nut wrench to recommend that you consult an tires, secure the flat tire and return tighten the lug nuts in the order authorized HYUNDAI dealer for the jack and tools to their proper stor- shown. Double-check each lug assistance.
  • Page 373 What to do in an emergency Use of compact spare tires When driving with the compact spare NOTICE (if equipped) tire mounted to your vehicle: When the original tire and wheel • Check the tire pressure after Compact spare tires are designed for are repaired and reinstalled on the installing the compact spare tire.

  • Page 374: Jack Label

    Jack label CAUTION ■ Example To prevent damaging the com- pact spare tire and your vehicle: • Drive slowly enough for the road conditions to avoid all hazards, such as a potholes or debris. • Avoid driving over obstacles. The compact spare tire diame- OHYK065011 ter is smaller than the diame- The actual Jack label in the vehicle may differ from the illustration.

  • Page 375: Ec Declaration Of Conformity For Jack

    What to do in an emergency EC Declaration of conformity for Jack JACKDOC14F 6-22...

  • Page 376: Introduction

    The tire may loose completely. authorized HYUNDAI dealer. air pressure at any time after Air pressure loss in the tire may inflating with the Tire Mobility Kit.

  • Page 377: Notes On The Safe Use Of The Tire Mobility Kit

    Tire Mobility Kit, we water. However, never give anything recommend that you contact an to an unconscious person and seek authorized HYUNDAI dealer. medical attention immediately. • Do not use the Tire Mobility Kit if a • Long time exposure to the sealant...

  • Page 378: Components Of The Tire Mobility Kit

    Components of the Tire Mobility Kit Connectors, cable and connection hose are stored in the compressor housing. Strictly follow specified sequence, otherwise the sealant may escape under high pressure. WARNING Expired sealant Do not use the Tire sealant after the sealant has expired (i.e. pasted the expiration date on the sealant container).

  • Page 379: Using The Tire Mobility Kit

    What to do in an emergency Using the Tire Mobility Kit CAUTION OIGH067042 OPDEN067015 2. Connect the filling hose (3) to the 4. Unscrew the valve cap from the sealant bottle (2) in the direction of valve of the defective wheel and OPD066013 (A) and connect the sealant bottle screw the filling hose (3) of the...
  • Page 380 Be careful not to overinflate the CAUTION tire and stay away from the tire when filling it. Securely install the sealant fill- ing hose to the valve. If not, CAUTION sealant may flow backward, possibly clogging the filling Tire pressure hose.

  • Page 381: Checking The Tire Inflation Pressure

    What to do in an emergency Distributing the sealant Checking the tire inflation pressure 1. After driving approximately 7~10 km (4~6 miles or about 10 min), stop at a safety location. OPDEN067015 3. Connect the other end of the filling OLMF064106 hose (3) directly into the tire valve.
  • Page 382 To get an accurate We recommend that you contact tire reading, the compressor needs to an authorized HYUNDAI dealer if be turned off. Information the tire cannot be made road- worthy with the Tire Mobility Kit.

  • Page 383: Introduction

    The tire may loose completely. authorized HYUNDAI dealer. air pressure at any time after Air pressure loss in the tire may inflating with the Tire Mobility Kit.

  • Page 384: Notes On The Safe Use Of The Tire Mobility Kit

    Tire Mobility Kit, we rinse the mouth and drink plenty of recommend that you contact an water. However, never give anything authorized HYUNDAI dealer. to an unconscious person and seek medical attention immediately. • Do not use the Tire Mobility Kit if a tire is severely damaged by driving •...

  • Page 385: Components Of The Tire Mobility Kit

    What to do in an emergency Components of the Tire Mobility Kit Connectors, cable and connection hose are stored in the compressor housing. Strictly follow specified sequence, otherwise the sealant may escape under high pressure. WARNING Expired sealant Do not use the Tire sealant after the sealant has expired (i.e.

  • Page 386: Using The Tire Mobility Kit

    Using the Tire Mobility Kit CAUTION OPD067014 OPDEN067015 2. Connect the filling hose (3) to the 4. Unscrew the valve cap from the sealant bottle (2) in the direction of valve of the defective wheel and OPD066013 (A) and connect the sealant bottle screw the filling hose (3) of the to the compressor (5) in the direc- sealant bottle onto the valve.
  • Page 387 What to do in an emergency Be careful not to overinflate the CAUTION tire and stay away from the tire when filling it. Securely install the sealant fill- ing hose to the valve. If not, CAUTION sealant may flow backward, possibly clogging the filling Tire pressure hose.

  • Page 388: Towing

    Distributing the sealant Checking the tire inflation pressure 1. After driving approximately 7~10 km (4~6 miles or about 10 min), stop at a safety location. OPDEN067015 3. Connect the other end of the filling OLMF064106 hose (3) directly into the tire valve. 9.
  • Page 389 To get an accurate We recommend that you contact tire reading, the compressor needs to an authorized HYUNDAI dealer if be turned off. the tire cannot be made road- Information worthy with the Tire Mobility Kit.

  • Page 390: Towing Service

    Dollies flatbed equipment. OPD066018 If emergency towing is necessary, we recommend having it done by an authorized HYUNDAI dealer or a commercial tow-truck service. Proper lifting and towing procedures OPD066020 are necessary to prevent damage to the vehicle. The use of wheel dollies or flatbed is recommended.
  • Page 391 What to do in an emergency Removable towing hook Front ■ WARNING If your vehicle is equipped with a rollover sensor, place the igni- tion switch in the LOCK/OFF or ACC position when the vehicle is being towed. The side impact and curtain air bag may deploy if the sensor detects the situa- tion as a rollover.

  • Page 392: Emergency Towing

    • Fasten the towing cable or chain If towing is necessary, we recommend securely to the hook. you have it done by an authorized • Do not jerk the hook. Apply steady HYUNDAI dealer or a commercial tow and even force. truck service. 6-39...
  • Page 393 What to do in an emergency CAUTION To avoid damage to your vehicle and vehicle components when towing: • Always pull straight ahead when using the towing hooks. Do not pull from the side or at a vertical angle. • Do not use the towing hooks to pull a vehicle out of mud, OTL065029...

  • Page 394: Fire Extinguisher

    E E M M E E R R G G E E N N C C Y Y C C O O M M M M O O D D I I T T Y Y ( ( I I F F E E Q Q U U I I P P P P E E D D ) ) First aid kit Your vehicle is equipped with emer- To check the tire pressure, take the...

  • Page 395: Maintenance

    Maintenance Engine compartment ..........7-3 Brake/clutch fluid..........7-25 Checking the brake/clutch fluid level......7-25 Maintenance services ...........7-4 Owner's responsibility............7-4 Washer fluid ............7-26 Owner maintenance precautions ........7-4 Checking the washer fluid level ........7-26 Owner maintenance..........7-5 Parking brake ............7-26 Owner maintenance schedule........7-5 Checking the parking brake .........7-26 Scheduled maintenance services......7-7 Air cleaner ............7-27 Normal Maintenance Schedule (for Europe) .....7-8...

  • Page 396: Rear Combination Lamp

    Tires and wheels ..........7-37 Light bulbs.............7-61 Tire care ................7-38 Headlamp, static bending lamp, position lamp, Recommended cold tire inflation pressures.....7-38 turn signal lamp and daytime running light bulb Check tire inflation pressure........7-39 replacement ..............7-62 Tire rotation ..............7-39 Headlamp aiming (for Europe)........7-62 Wheel alignment and tire balance ......7-40 Side repeater lamp replacement ........7-66 Tire replacement .............7-41...
  • Page 397 E E N N G G I I N N E E C C O O M M P P A A R R T T M M E E N N T T 1. Engine coolant reservoir/ Engine coolant cap 2.

  • Page 398: Owner's Responsibility

    Inadequate, incomplete or insufficient authorized HYUNDAI dealer. dards and receives technical support servicing may result in operational from HYUNDAI in order to provide problems with your vehicle that could you with a high level of service satis- lead to vehicle damage, an accident, faction.

  • Page 399: Owner Maintenance Schedule

    Park your vehicle on level formed by the owner or an authorized Be careful when checking your ground, move the shift lever HYUNDAI dealer at the frequencies engine coolant level when the into neutral, apply the parking indicated to help ensure safe, depend- engine is hot.
  • Page 400 Maintenance While operating your vehicle: At least monthly: At least once a year: • Note any changes in the sound of • Check coolant level in the engine • Clean body and door drain holes. the exhaust or any smell of exhaust coolant reservoir.
  • Page 401 S S C C H H E E D D U U L L E E D D M M A A I I N N T T E E N N A A N N C C E E S S E E R R V V I I C C E E S S Follow Normal Maintenance Schedule if the vehicle is usually operated where none of the following conditions apply.

  • Page 402: Normal Maintenance Schedule (For Europe)

    : If good quality gasolines meet Europe Fuel standards (EN228) or equivalents including fuel additives is not available, one bot- tle of additive is recommended. Additives are available from your authorized HYUNDAI dealer along with information on how to use them. Do not mix other additives.
  • Page 403 If there are some important matters like fuel flow restriction, surging, loss of power, hard starting prob- lem etc, replace the fuel filter immediately regardless of maintenance schedule and consult an authorized HYUNDAI dealer for details.
  • Page 404 Maintenance Normal Maintenance Schedule (for Europe) (Cont.) MAINTENANCE Months INTERVALS Miles x 1,000 MAINTENANCE Km x 1,000 ITEM Brake/clutch fluid Disc brakes and pads Steering gear rack, linkage and boots Driveshaft and boots Tire (pressure & tread wear) Front suspension ball joints Air conditioner refrigerant Air conditioner compressor Climate control air filter...

  • Page 405: Maintenance Under Severe Usage And Low Mileage Conditions (For Europe)

    Maintenance Under Severe Usage and Low Mileage Conditions (for Europe) The following items must be serviced more frequently on cars mainly used under severe and low mileage driving con- ditions. Refer to the chart below for the appropriate maintenance intervals. R : Replace I : Inspect and if necessary, adjust, correct, clean or replace Maintenance...
  • Page 406 Maintenance Maintenance Maintenance item Maintenance intervals Driving condition operation Replace more frequently Climate control air filter C, E, G depending on the condition Manual transmission fluid Every 120,000 km (80,000 miles) C, D, F, G, H, I, J Severe driving conditions A : Repeatedly driving short distance of less than 8 km (5 miles) E : Driving in the heavy dust condition in normal temperature or less than 16 km (10 miles) in freez-...

  • Page 407: Normal Maintenance Schedule (Except Europe)

    : If good quality gasolines meet Europe Fuel standards (EN228) or equivalents including fuel additives is not available, one bot- tle of additive is recommended. Additives are available from your authorized HYUNDAI dealer along with information on how to use them. Do not mix other additives.
  • Page 408 An improper coolant mixture can result in serious malfunction or engine damage. For your convenience, it can be replaced prior to it's interval when you do maintenance of other items. : Inspect for excessive valve noise and/or engine vibration and adjust if necessary. We recommend that the system be checked by an authorized HYUNDAI dealer. 7-14...
  • Page 409 Normal Maintenance Schedule (except Europe) (Cont.) MAINTENANCE Months INTERVALS Miles x 1,000 MAINTENANCE Km x 1,000 ITEM Brake/clutch fluid Disc brakes and pads Steering gear rack, linkage and boots Driveshaft and boots Tire (pressure & tread wear) Front suspension ball joints Air conditioner refrigerant Air conditioner compressor Climate control air filter...

  • Page 410: Maintenance Under Severe Usage And Low Mileage Conditions (Except Europe)

    Maintenance Maintenance Under Severe Usage and Low Mileage Conditions (except Europe) The following items must be serviced more frequently on cars mainly used under severe driving conditions. Refer to the chart below for the appropriate maintenance intervals. R : Replace I : Inspect and if necessary, adjust, correct, clean or replace Maintenance Driving...
  • Page 411 Maintenance Driving Maintenance item Maintenance intervals operation condition Inspect more frequently Driveshaft and boots C, D, E, F, G, H, I, J depending on the condition Replace more frequently Climate control air filter C, E, G depending on the condition C, D, E, F, G, Manual transmission fluid Every 120,000 km (80,000 miles)
  • Page 412 We recommend that the fuel Do not disconnect and inspect LOCK/OFF or ACC position. lines, fuel hoses and connections be spark plugs when the engine is replaced by an authorized HYUNDAI hot. You may burn yourself. dealer. Cooling system Check the cooling system parts,...
  • Page 413 Replace any deteriorat- grease. the HYUNDAI web site. ed or damaged parts immediately. (http://service.hyundai-motor.com) Air conditioning refrigerant/ compressor Check the air conditioning lines and connections for leakage and dam- age.

  • Page 414: Checking The Engine Oil Level

    Maintenance E E N N G G I I N N E E O O I I L L Checking the engine oil level 1. Follow all of the oil manufacturer’s precautions. 2. Be sure the vehicle is on level ground.

  • Page 415: Checking The Engine Oil And Filter

    Wipe off spilled oil and warm water as soon as pos- immediately. sible after handling used oil. We recommend that the engine oil and filter be replaced by an author- ized HYUNDAI dealer. 7-21...

  • Page 416: Engine Coolant

    If the coolant level is low, add enough distilled (deionized) water. Bring the level to MAX (or F (Full)) but do not overfill. If frequent additions are required, we recommend that the system be inspect- ed by an authorized HYUNDAI dealer. 7-22...
  • Page 417 The electric motor for the cooling fan • Do not use a solution that contains (Continued) is controlled by engine coolant tem- more than 60% antifreeze or less Turn the engine off and wait until perature, refrigerant pressure and than 35% antifreeze, which would the engine cools down.

  • Page 418: Changing The Engine Coolant

    Maintenance Changing the engine coolant (Continued) WARNING We recommend that coolant be changed by an authorized HYUNDAI Make sure the coolant cap is dealer according to the Maintenance properly closed after refilling Schedule at the beginning of this coolant. Otherwise the engine chapter.

  • Page 419: Checking The Brake/Clutch Fluid Level

    Checking the brake/clutch If the fluid level is excessively low, WARNING we recommend that the system be fluid level checked by an authorized HYUNDAI Do not allow brake/clutch fluid dealer. to come in contact with your eyes. If brake/clutch fluid comes...

  • Page 420: Washer Fluid

    Do not drink washer fluid and the system be serviced by an author- avoid contact with skin. ized HYUNDAI dealer. Washer fluid is poisonous to Stroke : 5~6 “clicks’’ at a force of humans and animals. 20 kg (44 lbs, 196 N). •...

  • Page 421: Filter Replacement

    A A I I R R C C L L E E A A N N E E R R Filter replacement OPDEN077021 OPDEN077022 1. Loosen the air cleaner cover 2. Pull out the part written PULL (1). OPDEN077018 attaching clips and open the cover. 3.
  • Page 422 • Use HYUNDAI genuine parts. Use of non-genuine parts could damage the air flow sensor. 7-28...

  • Page 423: Climate Control Air Filter

    C C L L I I M M A A T T E E C C O O N N T T R R O O L L A A I I R R F F I I L L T T E E R R Filter inspection Filter replacement If the vehicle is operated in the...

  • Page 424: Wiper Blades

    Maintenance W W I I P P E E R R B B L L A A D D E E S S Blade inspection NOTICE NOTICE Contamination of either the wind- Install a new climate control air filter To prevent damage to the wiper shield or the wiper blades with for- in the correct direction with the blades, arms or other compo-...

  • Page 425: Blade Replacement

    Blade replacement Front windshield wiper service 4. Turn the wipers to any ON position to return the wipers to the bottom positions When the wipers no longer clean resting position. adequately, the blades may be worn or cracked, and require replacement. NOTICE To prevent damage to the wiper arms or other components, do not attempt...
  • Page 426 Maintenance Rear window wiper blade OAD075074L OAD075076L 3. Remove the wiper blade from the OTL075050 wiper arm (5). 1. Raise the wiper arm and pull out 4. Install a new wiper blade assem- the wiper blade assembly. bly in the reverse order of removal. 5.
  • Page 427 • Do not attempt to jump start that the wiper blades be replaced by your vehicle if your battery is Keep batteries out of an authorized HYUNDAI dealer. frozen. reach of children. (Continued) (Continued) 7-33...

  • Page 428: For Best Battery Service

    • When you do not use the vehicle • Keep the battery top clean and dry. for a long time in a low tempera- 1. CMF60L-BCI : The HYUNDAI • Keep the terminals and connec- ture area, disconnect the battery...

  • Page 429: Battery Recharging

    • Wear eye protection when terminal. checking the battery during • Always use a genuine HYUNDAI charging. approved battery when you • The battery must be removed replace the battery. from the vehicle and placed in a well ventilated area.

  • Page 430: Reset Items

    See “Jump • Sunroof the AGM battery be serviced Starting” in chapter 6 for more infor- by an authorized HYUNDAI mation on jump starting procedures. • Trip computer dealer. For charging your • Climate control system...
  • Page 431 T T I I R R E E S S A A N N D D W W H H E E E E L L S S Information - Power Hop (Continued) WARNING • Replace tires that are worn, When fully accelerating the vehicle Tire failure may cause loss of show uneven wear, or are dam-...

  • Page 432: Recommended Cold Tire Inflation Pressures

    Maintenance Tire care Recommended cold tire infla- WARNING tion pressures For proper maintenance, safety, and maximum fuel economy, you must All tire pressures (including the Recommended pressures must always maintain recommended tire spare) should be checked when the be maintained for the best ride, inflation pressures and stay within the tires are cold.

  • Page 433: Check Tire Inflation Pressure

    Tire rotation we recommend it be checked Radial tires may look properly inflat- To equalize tread wear, HYUNDAI by an authorized HYUNDAI ed when they are under-inflated. recommends that the tires be rotated dealer.

  • Page 434: Wheel Alignment And Tire Balance

    Maintenance Wheel alignment and tire bal- ■ 18 inch tire Information ance The outside and inside of the unsym- The wheels on your vehicle were metrical tire is distinguishable. When aligned and balanced carefully at the installing an unsymmetrical tire, be factory to give you the longest tire life sure to install the side marked "out- and best overall performance.

  • Page 435: Tire Replacement

    Regardless of the remaining this vehicle. Using tires and If the tire is worn evenly, a tread wear tread, HYUNDAI recommends wheels other than the recom- indicator will appear as a solid band that tires be replaced after six mended sizes could cause across the tread.

  • Page 436: Wheel Replacement

    Maintenance Compact spare tire replacement Wheel replacement Tire maintenance (if equipped) When replacing the metal wheels for In addition to proper inflation, correct any reason, make sure the new wheel alignment helps to decrease A compact spare tire has a shorter wheels are equivalent to the original tire wear.
  • Page 437 Example tire size designation: Wheel size designation (These numbers are provided as an Wheels are also marked with impor- example only; your tire size designa- tant information that you need if you tor could vary depending on your ever have to replace one. The follow- vehicle.) ing explains what the letters and numbers in the wheel size designa-...
  • Page 438 Maintenance 3. Checking tire life (TIN : Tire 4. Tire ply composition and Tire speed ratings Identification Number) material The chart below lists many of the dif- ferent speed ratings currently being Any tires that are over six years old, The number of layers or plies of rub- used for passenger vehicle tires.
  • Page 439 6. Maximum load rating Tread wear Traction - AA, A, B & C This number indicates the maximum The tread wear grade is a compara- The traction grades, from highest to load in kilograms and pounds that tive rating based on the wear rate of lowest, are AA, A, B and C.

  • Page 440: Low Aspect Ratio Tires

    Or, contact an authorized heat and its ability to dissipate heat The low aspect ratio is to optimize HYUNDAI dealer. when tested under controlled condi- handling and braking. Thus, it may • Inspect the tire condition and...
  • Page 441 If the replacement fuse blows, this indi- cates an electrical problem. Avoid using the system involved and immedi- ately consult an authorized HYUNDAI NOTICE dealer. Do not use a screwdriver or any other metal object to remove...

  • Page 442: Instrument Panel Fuse Replacement

    7. Push in a new fuse of the same rating, and make sure it fits tightly in the clips. If it fits loosely, consult an authorized HYUNDAI dealer. 7-48...

  • Page 443: Engine Compartment Panel Fuse Replacement

    Fuse switch Engine compartment panel Information fuse replacement ■ Blade type fuse OPDEN077032 OPDEN077036 OPDE046119 ■ Cartridge type fuse Always, place the fuse switch to the If the fuse switch is OFF, “Turn on ON position. FUSE SWITCH” message will appear. If you move the switch to the OFF position, some items such as the NOTICE...
  • Page 444 5. Push in a new fuse of the same rating, and make sure it fits tightly in the clips. If it fits loosely, consult an authorized HYUNDAI dealer. NOTICE After checking the fuse panel in the engine compartment, securely...

  • Page 445: Fuse/Relay Panel Description

    Fuse/Relay panel description Driver’s side fuse panel OPDEN077039 Inside the fuse/relay box covers, you can find the fuse/relay label describ- ing fuse/relay names and ratings. Information Not all fuse panel descriptions in this manual may be applicable to your vehicle. It is accurate at the time of printing.
  • Page 446 Maintenance Driver's side fuse Panel Fuse No. Fuse Name Symbol Fuse Rating Circuit Protected Electro Chromic Mirror, MTS E-Call Module, Audio, A/V & Navigation Head Unit, A/C Control Module, A/T Shift Lever Indicator, Console Switch RH, DC-DC Converter, MODULE 5 7.5A MODULE Head Lamp LH/RH, Auto Head Lamp Leveling Device Module,...
  • Page 447 Driver's side fuse Panel Fuse No. Fuse Name Symbol Fuse Rating Circuit Protected Wireless Charger, Vanity Lamp LH/RH, Room Lamp, Overhead Console Lamp, INTERIOR 7.5A Personal Lamp LH/RH, Rain Sensor, Ignition Key Ill. & Door Warning Switch, LAMP Glove Box Lamp, Luggage Lamp, Rain Sensor MEMORY 2 7.5A MTS E-Call Module...
  • Page 448 Maintenance Driver's side fuse Panel Fuse No. Fuse Name Symbol Fuse Rating Circuit Protected START 7.5A Smart Key Control Module, Engine Room Junction Block (RLY.4) CLUSTER 7.5A Instrument Cluster CLUSTER DOOR LOCK Door Lock/Unlock Relay, ICM Relay Box (Dead Lock Relay) SEAT HEATER Front Seat Warmer Control Module FRONT...
  • Page 449 Driver's side fuse Panel Fuse No. Fuse Name Symbol Fuse Rating Circuit Protected REAR WIPER Rear Wiper Relay MIRROR Driver/Passenger Power Outside Mirror, A/C Control Module HEATED POWER POWER Rear Power Outlet #2 OUTLET OUTLET HEATED STEERING 7-55...
  • Page 450 Maintenance Engine compartment fuse panel OPDEN077037 Inside the fuse/relay box covers, you can find the fuse/relay label describ- ing fuse/relay names and ratings. Information Not all fuse panel descriptions in this manual may be applicable to your vehicle. It is accurate at the time of printing.
  • Page 451 Engine compartment fuse panel Relay No. Symbol Relay Name (IG1) RLY. 3 PDM #3 (IG1) Relay RLY. 4 START Relay RLY. 5 E-CVVT Relay E-CVVT (IG2) RLY. 6 PDM #4 (IG2) Relay FUEL RLY. 7 FUEL PUMP Relay PUMP (ACC) RLY.8 PDM #2 (ACC) Relay RLY.
  • Page 452 Maintenance Engine compartment fuse panel Fuse No. Fuse Name Symbol Fuse Rating Circuit Protected MAIN 180A Fuse : F27, F29, F30, F33 MAIN MDPS 1 100A MDPS Unit PCB Block (Fuse : F44, F50, F51, F52, Engine Control Relay) IGPM (Fuse : F30, IPS0, IPS1, IPS2) IGPM (IPS3, IPS4, IPS5, IPS6, IPS7, IPS8) IGPM (Fuse : F3, F4, F5, F7, F8, F9, F12, F17, F18) REAR...
  • Page 453 Engine compartment fuse panel Fuse No. Fuse Name Symbol Fuse Rating Circuit Protected POWER Rear Power Outlet POWER OUTLET 3 OUTLET POWER Front Power Outlet POWER OUTLET 2 OUTLET VACUUM Vacuum Pump VACUUM PUMP 1 PUMP FUEL PUMP FUEL RLY.7 PUMP IGPM (Leak Current Autocut Device, Fuse : F21, F24, F27, F33) BURGLAR...
  • Page 454 Maintenance Engine compartment fuse panel (Battery terminal cover) OPDEN077066 Inside the fuse/relay box cover, you can find the fuse/relay label describ- ing fuse/relay names and ratings. Information Not all fuse panel descriptions in this manual may be applicable to your OPD076065 vehicle;...
  • Page 455 So, you need not ment of the vehicle and burning ommend that the system be checked change your headlamps in a country your fingers or receiving an elec- by an authorized HYUNDAI dealer. with opposite traffic direction. tric shock. 7-61...

  • Page 456: Headlamp, Static Bending Lamp, Position Lamp, Turn Signal Lamp And Daytime Running Light Bulb Replacement

    (Horizontal line passing through daytime running light center of head lamps) on the screen. If the light bulb does not operate, we recommend that you have the vehicle checked by an authorized HYUNDAI dealer. 7-62...
  • Page 457 Aiming point H1 : Height between the head lamp bulb center and ground (Low beam) H2 : Height between the head lamp bulb center and ground (High beam) H3 : Height between the fog lamp bulb center and ground W1 : Distance between the two head lamp bulbs centers (Low beam) W2 : Distance between the two head lamp bulbs centers (High beam) W3 : Distance between the two fog lamp bulbs centers OPDE076081...
  • Page 458 Maintenance Headlamp low beam (LHD side) ■ Based on 10m screen OPDE076082 1. Turn the low beam on without driver aboard. 2. The cut-off line should be projected in the cut-off line shown in the picture. 3. When aiming the low beam, vertical aiming should be adjusted after adjusting the horizontal aiming. 4.
  • Page 459 Headlamp low beam (RHD side) ■ Based on 10m screen OPDE076083 1. Turn the low beam on without driver aboard. 2. The cut-off line should be projected in the cut-off line shown in the picture. 3. When aiming the low beam, vertical aiming should be adjusted after adjusting the horizontal aiming. 4.

  • Page 460: Side Repeater Lamp Replacement

    (1) Stop/Tail lamp 3. Open the lamp assembly retaining recommend that you have the vehicle (2) Turn signal lamp screw covers. checked by an authorized HYUNDAI (3) Backup lamp dealer. 4. Loosen the lamp assembly retain- ing screws with a cross-tip screw- Stop/Tail lamp driver.
  • Page 461 Turn signal lamp OPD076048 OPD076064 OPDEN077072 5. Remove the rear combination 6. Remove the socket from the assem- Backup lamp lamp assembly from the body of bly by turning the socket counter- 1. Turn off the engine. the vehicle. clockwise until the tabs on the socket 2.

  • Page 462: Rear Fog Lamp Replacement

    Maintenance Rear fog lamp replacement 5. Insert a new bulb by inserting it into the socket and rotating it until it locks into place. 6. Install the socket into the housing by aligning the tabs on the socket with the slots in the housing. Push the socket into the housing and turn the socket clockwise.

  • Page 463: High Mounted Stop Lamp Replacement

    HYUNDAI checked by an authorized HYUNDAI dealer. 2. Remove the bulb by pulling it dealer. straight out.
  • Page 464 Maintenance 1. Using a flat-head screwdriver, Map lamp, room lamp, vanity mirror lamp and luggage compartment gently pry the lens from the interi- lamp or light housing. ■ Map lamp ■ Vanity mirror lamp 2. Remove the bulb by pulling it straight out.

  • Page 465: Exterior Care

    A A P P P P E E A A R R A A N N C C E E C C A A R R E E Exterior care Insects, tar, tree sap, bird droppings, WARNING industrial pollution and similar deposits Exterior general caution can damage your vehicle’s finish if not Wet brakes...
  • Page 466 Maintenance Waxing NOTICE A good coat of wax is a barrier • Wiping dust or dirt off the body between your paint and contaminate. with a dry cloth will scratch the Keeping a good coat of wax on your finish. vehicle will help protect it.
  • Page 467 Bright-metal maintenance Aluminum wheel maintenance Thoroughly flush the vehicle under- body and wheel openings with luke- • To remove road tar and insects, The aluminum wheels are coated with warm or cold water once a month, use a tar remover, not a scraper or a clear protective finish.
  • Page 468 Maintenance Corrosion protection High-corrosion areas For all these reasons, it is particularly important to keep your vehicle clean If you live in an area where your vehi- Protecting your vehicle from corro- and free of mud or accumulations of cle is regularly exposed to corrosive sion other materials.

  • Page 469: Interior Care

    Keep paint and trim in good condition Interior care • When cleaning underneath the vehicle, give particular attention to Scratches or chips in the finish Interior general precautions the components under the fenders should be covered with "touch-up" Prevent chemicals such as perfume, and other areas that are hidden paint as soon as possible to reduce cosmetic oil, sun cream, hand cleaner...
  • Page 470 Maintenance Cleaning the upholstery and Leather (if equipped) CAUTION interior trim • Features of seat leather Vinyl (if equipped) - Leather is made from the outer • Wrinkles or abrasions which skin of an animal, which goes Remove dust and loose dirt from appear naturally from usage through a special process to be vinyl with a whisk broom or vacuum...
  • Page 471 Cleaning the lap/shoulder belt • Caring for the leather seats • Cleaning the leather seats webbing - Vacuum the seat periodically to - Remove all contaminations instant- remove dust and sand on the seat. ly. Refer to instructions below for Clean the belt webbing with any mild It will prevent abrasion or damage removal of each contaminant.

  • Page 472: Emission Control System

    Module (ECM); when the engine pollution caused by blow-by gases authorized HYUNDAI dealer in accor- coolant temperature is low during being emitted from the crankcase. dance with the maintenance schedule...

  • Page 473: Battery

    3. Exhaust emission control Engine exhaust gas precautions • Do not operate the engine in con- fined or closed areas (such as system (carbon monoxide) garages) any more than what is • Carbon monoxide can be present The Exhaust Emission Control System necessary to move the vehicle in or with other exhaust fumes.
  • Page 474 All inspections and adjustments must be made by an WARNING Therefore, the following precautions authorized HYUNDAI dealer. must be observed: • Avoid driving with a very low fuel • A hot exhaust system can • Use only UNLEADED FUEL for level.

  • Page 475: Specifications & Consumer Information

    Specifications & Consumer information Dimensions ..............8-2 Engine ..............8-2 Bulb wattage............8-3 Tires and wheels ............8-4 Tire load and speed capacity .......8-5 Air conditioning system ........8-5 Vehicle weight and luggage volume....8-5 Recommended lubricants and capacities ...8-6 Recommended SAE viscosity number ......8-7 Vehicle identification number (VIN)....8-8 Vehicle certification label ........8-8 Tire specification and pressure label ....8-9 Engine number ............8-9...
  • Page 476 Specifications & Consumer information D D I I M M E E N N S S I I O O N N S S Items mm (in) Overall length 4335 (170.67) without outside mirrors 1795 (70.66) Overall width with outside mirrors 2039 (80.27) Overall height 1451 (57.13)*...
  • Page 477 B B U U L L B B W W A A T T T T A A G G E E Light Bulb Bulb Type Wattage Headlamp High Position lamp Front Turn signal lamp Static bending light (SBL) Daytime running light Side repeater lamp Stop/Tail lamp Turn signal lamp...
  • Page 478 Specifications & Consumer information T T I I R R E E S S A A N N D D W W H H E E E E L L S S Inflation Pressure kPa (bar, psi) Wheel Lug Nut Item Tire Size Wheel Size...
  • Page 479 100 ~ 120 (3.52 ~ 4.23) Contact an authorized HYUNDAI dealer for more details. V V E E H H I I C C L L E E W W E E I I G G H H T T A A N N D D L L U U G G G G A A G G E E V V O O L L U U M M E E Luggage Volume l (cu ft.)
  • Page 480 Specifications & Consumer information R R E E C C O O M M M M E E N N D D E E D D L L U U B B R R I I C C A A N N T T S S A A N N D D C C A A P P A A C C I I T T I I E E S S To help achieve proper engine and powertrain performance and durability, use only lubricants of the proper quality.
  • Page 481 Recommended SAE viscosity Engine oil viscosity (thickness) has an effect on fuel economy and cold number weather operating (engine start and engine oil flowability). Lower viscosity engine oils can provide better fuel economy and cold weather performance, however, higher viscosity engine oils are required for satisfactory lubrication CAUTION in hot weather.
  • Page 482 Specifications & Consumer information V V E E H H I I C C L L E E I I D D E E N N T T I I F F I I C C A A T T I I O O N N N N U U M M B B E E R R ( ( V V I I N N ) ) V V E E H H I I C C L L E E C C E E R R T T I I F F I I C C A A T T I I O O N N L L A A B B E E L L ■...
  • Page 483 T T I I R R E E S S P P E E C C I I F F I I C C A A T T I I O O N N A A N N D D E E N N G G I I N N E E N N U U M M B B E E R R A A I I R R C C O O N N D D I I T T I I O O N N E E R R P P R R E E S S S S U U R R E E L L A A B B E E L L...
  • Page 484 The label is located on the underside and other relevant provisions of of the hood. Directive 1995/5/EC. Further information including the manufacturer's declaration of con- formity is available on HYUNDAI web site as follows; http://service.hyundai-motor.com 8-10...

  • Page 485: Index

    Index...
  • Page 486 Index Antenna................4-2 Anti-lock brake system (ABS) ........5-26 Appearance care ............7-71 Air bag warning labels ..........2-63 Exterior care...............7-71 Air bags.................2-45 Interior care..............7-75 Additional safety precautions ........2-63 Armrest .................2-15 Air bag collision sensors ...........2-57 Ashtray................3-121 Air bag inflation conditions........2-59 Audio / Video / Navigation system ........4-4 Air bag non-inflation conditions .......2-60 Auto defogging system..........3-117 Air bag warning labels..........2-63...
  • Page 487 Interior light bulb............7-69 License plate light bulb ..........7-69 Rear combination light bulb ........7-66 Battery................7-33 Rear fog lamp ............7-68 Battery recharging............7-35 Side repeater lamp ............7-66 Battery saver function...........3-85 Static bending lamp ...........7-62 Before driving..............5-4 Bulb wattage ..............8-3 Blade type fuse .............7-49 Button start/stop, see engine start/stop button....5-9 Bluetooth ®...
  • Page 488 Index Installing a child restraint system (CRS)....2-37 ISOFIX anchorage and top-tether anchorage for children ..............2-38 Dashboard illumination, see instrument panel illumination.3-44 Rearward-facing child restraint system .....2-36 Dashboard, see instrument cluster........3-43 Securing a child restraint system seat with Day/night rearview mirror..........3-22 "Top-tether Anchorage"...
  • Page 489 Driver Attention Alert (DAA) system ......5-78 Engine compartment............1-7 Driver position memory system ........3-17 Engine compartment............7-3 Easy access function ..........3-18 Engine compartment panel fuse replacement....7-49 Recalling memory positions ........3-17 Engine coolant ..............7-22 Storing memory positions..........3-17 Engine coolant temperature gauge .......3-45 Engine number..............8-9 Driver's air bag .............2-47 Engine oil..............7-20 Driver's knee air bag.............2-47...
  • Page 490 Index Front seat headrests Adjusting the height up and down......2-17 Forward and rearward adjustment ......2-17 Hazard warning flasher...........6-2 Removal/Reinstall............2-18 Hazardous driving conditions........5-91 Fuel filler door..............3-40 Headlamp delay function..........3-85 Fuel gauge..............3-46 Headlamp leveling device ..........3-86 Fuel requirements ............F-6 Headlamp position............3-80 Do not use methanol............F-8 Headlight bulb replacement..........7-61 Fuel Additives..............F-8 Headrest ................2-16...

  • Page 491: Interior Overview

    If you have a flat tire while driving .......6-3 Instrument panel fuse replacement.......7-48 Ignition switch ..............5-6 Instrument panel overview ..........1-5 Engine Start/Stop button..........5-9 Interior care..............7-75 Key ignition switch............5-6 Interior features Immobilizer system ............3-10 Ashtray..............3-121 Impact sensing door unlock..........3-14 Bottle holder ............3-121 Important safety precautions ..........2-2 Cargo area cover ............3-129 Air bag hazards ............2-2...
  • Page 492 Index Check LDWS.............3-65 Check limited slip differential ........3-66 Check LKAS..............3-65 Jump starting..............6-4 Check smart high beam system .........3-65 Check steering wheel lock system......3-61 Door, Hood, Tailgate open.........3-62 Label Engine has overheated ..........3-64 Air conditioner compressor label ........8-9 Heated Steering Wheel turned off ......3-64 Refrigerant label ............8-10 Key not detected ............3-62 Tire sidewall labeling..........7-42...
  • Page 493 Quick guide help............3-69 Maintenance services...........7-4 Trip computer mode...........3-69 Maintenance under severe usage conditions ..7-11,16 Turn By Turn (TBT) mode ........3-70 Normal maintenance schedule ......7-8, 13 User settings mode.............3-72 Owner maintenance .............7-5 Warning message mode ..........3-72 Scheduled maintenance services .........7-7 Light bulbs..............7-61 Tire maintenance............7-42 Lighting.................3-79 Maintenance services............7-4...
  • Page 494 Index Aux, USB and iPod .............4-2 Power steering ..............3-19 Bluetooth ® Wireless Technology hands-free ....4-4 Power window lock switch...........3-30 Steering wheel audio control ........4-3 Pre-tensioner seat belt...........2-28 Puddle lamp ..............3-90 N button ................5-41 N mode .................5-42 Rear center seat belt .............2-27 Normal maintenance schedule Rear fog lamp ...............3-84 Except Europe............7-13...
  • Page 495 Returning used vehicles ..........F-9 Seat belt use during pregnancy........2-31 Rev matching..............5-17 Seat belt warning light..........2-23 Reverse parking aid function........3-26 When to replace seat belts .........2-34 Rocking the vehicle ............5-91 Seat warmers ...............2-20 Rotation (Tire) ..............7-39 Seats................2-4 Front seat adjustment...........2-6 Front seat warmers.............2-20 Headrest ..............2-16 Safety messages..............F-5 Rear seat adjustment ..........2-12...
  • Page 496 Index Rocking the vehicle ...........5-91 Sunroof inside air recirculation ........3-118 Smooth cornering............5-92 Sunvisor ..............3-122 Speed limit control system ...........5-82 Speed Limit Information Function (SLIF) ....5-60 Speed sensing door lock ..........3-14 Tachometer Speedometer ..............3-44 Variable LED tachometer ..........3-45 SPORT mode ..............5-41 Tailgate .................3-38 Starting difficulties, see engine will not start....6-3 Theft-alarm system ............3-16...
  • Page 497 Tires and wheels specification........8-4 Anti-lock Brake System (ABS) warning light ..3-50 Towing ................6-37 AUTO STOP indicator light ........3-55 Trailer towing ...............5-99 Autonomous Emergency Braking (AEB) warning light ............3-60 Trip computer ...............3-76 Charging system warning light .........3-52 Accumulated Info display..........3-77 Cruise indicator light ..........3-58 Average fuel economy ..........3-77 Cruise SET indicator light .........3-58 Digital speedometer ...........3-78...
  • Page 498 Index N mode indicator light..........3-58 Winter driving...............5-94 Parking brake & brake fluid warning light....3-49 Snow tires ..............5-94 Rear fog indicator light..........3-57 Tire chains..............5-95 REV (Rev Matching) indicator light ......3-59 Winter Precautions............5-97 Seat belt warning light..........3-49 Wiper blades replacement ..........7-30 Smart high beam indicator light ........3-57 Front................7-31 Speed limiter indicator light ........3-58 Rear................7-32...

Table of Contents

Save PDF
