Rocker 1 =
To switch the right and the left halogen lamp on and off
Rocker 2 =
To switch both halogen lamps in the front and both
halogen lamps in the beck on and off
Rocker 3-5 =
To switch the different power levels
Power 1 = low step
Power 2 = medium step
Power 3 = high step
Pushbutton 6 =
After-running 1 = 30 minutes
Pushbutton 7 =
After-running 2 = 60 minutes
LED mains (green)
=
LED fan (red)
=
LED
(yellow)
=
Disinfection lamp (14) and ionizer start operating automatically when the motor is switched on. They
cannot and do not need to be switched on and off separately.
After running:
Please hold the after running rocker depressed for at least 2 seconds in order to be able to assure the
desired after running time.
6. Exchanging halogen reflector lamps (13)
Pull out defect halogen lamps (13) and press new lamps into the socket! Do not pry out defect halogen
lamps using metal parts (e.g. screwdriver or knife) since thereby the hood body could be damaged.
7. Taking out metal filters with Ionizer sheet (7)
Before taking out metal filters, it is imperative to disconnect the device form the mains power supply by
turning off main switch (17)!
When removing the upper filter (7) the following must be regarded:
To also enable cleaning of the ionizer sheet, it is necessary to detach the supply cable from each filter
when removing the filters. To do so just pull cable off (see photographs below).
Supply cable is detached from
the ionizer sheet
Device is ready for operation
Motor is running
Disinfection lamp and ionizer are in operation
(lit up all the time while the motor is running respectively
only when the motor is running)
View after taking out
metal filter
Page 7
