- Page 1 HIFI STEREO MICRO SYSTEM CIRFLEXX UMS 4201 SPCD ENGLISH...
-
Page 2: Table Of Contents
CD mode Basic CD mode functions Special CD mode features Creating a track memory – playing back files and tracks in selected order Timer mode Switch-on timer Sleep timer Information Cleaning the CD unit Technical data Rectifying minor problems GRUNDIG Service... -
Page 3: Set-Up And Safety
SET-UP AND SAFETY ______________________________________________ Please note the following information when setting up the system: The HiFi system is designed for the playback of audio signals. Any other use is expressly prohibited. U M S 4 1 0 0 S T E R E O M I C R O H I F I S Y S T E M If you want to set up the HiFi system on wall shelves or in cupboards, please V O L U M E ensure that the device is adequately ventilated. -
Page 4: Overview
OVERVIEW _______________________________________________________________________ The HiFi system controls Controls on the front General irflexx Switches the HiFi system to and from ON/OFF standby mode. Infrared receiver for remote control sig- nals. Headphone jack for connecting a stereo S T E R E O M I C R O H I F I S Y S T E M headphone set with a jack plug (ø... - Page 5 OVERVIEW __________________________________________________________________________________ s s s 6 Select stored radio 5 a § stations. CD mode In MP3 or CD-DA mode: selects the » « input source. irflexx Starts and interrupts CD playback. In MP3 or CD-DA mode: press briefly to s s s 6 select the next file, album or track.
- Page 6 OVERVIEW __________________________________________________________________________________ Controls on the top General SLEEP For setting the sleep timer. For setting the switch-on timer. INTRO/REPEAT TIMER P R O G R / R A N D O M T I M E For setting the time manually. PROGR/RANDOM I N T R O / R E P E AT TIME...
-
Page 7: The Hifi Display
OVERVIEW __________________________________________________________________________________ The HiFi display In standby mode: shows the time and special functions. PRESET The »JAZZ« sound setting is activated. JAZZ ALBUM The bass boost is activated. -< TRACK In tuner mode: displays the waveband, frequency, station name, RDS time and radio text. FLAT CLASSIC POP JAZZ ROCK... - Page 8 OVERVIEW __________________________________________________________________________________ In MP3 or CD-DA mode: displays playback of a CD. In MP3 or CD-DA mode: pauses playback. PRESET In MP3 mode: displays total number of albums and the ALBUM current album. ALBUM -< TRACK In CD-DA mode: displays the number of CD tracks, the TRACK number of the current track and the number of stored tracks.
-
Page 9: The Back Of The Hifi System
OVERVIEW __________________________________________________________________________________ The back of the HiFi system FM ANTENNA Antenna socket for the rooftop antenna or for the wire antenna supplied. MW ANTENNA Antenna terminals for the wire antenna supplied. Audio signal input for an external AUX IN device. Connections for the loudspeakers SPEAKER MW ANTENNA... -
Page 10: The Remote Control
OVERVIEW __________________________________________________________________________________ The remote control Switches the HiFi system to and from standby mode. ON/OFF In MP3 or CD-DA mode: selects the » « input source. ON/OFF Starts and interrupts CD playback. In tuner mode: deletes individual station positions. In MP3 or CD-DA mode: press once to interrupt or resume TUNER/ BAND CD playback. - Page 11 OVERVIEW __________________________________________________________________________________ For setting the sleep timer. SLEEP In MP3 or CD-DA mode: for playing the introductions of INTRO/REPEAT ON/OFF files or tracks. For repeating a file or track or a whole CD. TIMER In standby mode: for setting the switch-on and -off timer. In tuner mode: for storing radio stations.
-
Page 12: Connection And Preparation
CONNECTION AND PREPARATION _______ Connecting the antenna Plug the rooftop antenna connector into the » ANTENNA« socket on the HiFi. Note: If no rooftop antenna is available, use the auxiliary antenna supplied. This antenna provides reasonably good reception of local FM (VHF) stations. Do not shorten the auxiliary antenna. -
Page 13: Connecting Headphones
CONNECTION AND PREPARATION _______________________________________ Connecting headphones A U X U B S Insert the headphone plug (ø 3.5 mm) into the »0« socket on the front of O N / O F F D S C the HiFi system. – The loudspeakers of the HiFi system are switched off. Connecting the power cord Note: Check that the mains voltage on the type plate (on the back of the HiFi... -
Page 14: Additional Information For Units Sold In The Uk
In no circumstance must any of the wires be connected to the terminal marked with the letter “E”, earth symbol “ ”, coloured green, or green & yellow. Replacement mains lead sets can be obtained from your local dealer, or by contacting Grundig Consumer Relations (01788 570088) Moulded 3-pin lead set, suitable for UK use:... -
Page 15: Settings
SETTINGS ____________________________________________________________________________ Setting the clock The following settings may only be performed in standby mode. To set the 12-hour format, briefly press » TIME«. – Display: » « briefly, then the current time, e.g. »PM « (»AM« for the morning, »PM« for the afternoon/evening). To set the 24-hour format, press »... - Page 16 SETTINGS ____________________________________________________________________________________ Even when the reception is very good, the time synchronisation can take several minutes, and the accuracy depends on the time signal being trans- mitted. Automatic setting is always activated when the HiFi is switched from standby to tuner mode and receives a suitable RDS station. If you wish, you can switch off the RDS time synchronisation by pressing »...
-
Page 17: Setting And Storing Radio Stations
SETTINGS ____________________________________________________________________________________ Setting and storing radio stations Automatic station search After the HiFi system has been connected to the mains for the first time, the devi- ce searches in tuner mode on the FM wavelength for the 40 stations with the best PRESET reception and stores them. - Page 18 SETTINGS ____________________________________________________________________________________ Manual station search To change the frequency in steps, briefly press »TUNING UP/DOWN« on the HiFi several times. – The frequency changes in steps of 50 kHz. Storing stations on station positions Select the frequency band (FM or MW) by pressing »TUNER/BAND«. PRESET »TUNING UP/DOWN«...
-
Page 19: Deleting Settings
SETTINGS ____________________________________________________________________________________ Storing your favourite stations (Favourite Station Memory) »TUNING UP/DOWN« on the HiFi to select the station you want to store. PRESET Press »PROGR« to activate the storage function. – Display: »PRESET« flashes for approx. 10 seconds. Select station position 01 with »FSM« on the remote control. To store the station, press »PROGR«... -
Page 20: General Functions
GENERAL FUNCTIONS _________________________________________ Switching on and off Switch on the HiFi system from standby mode by pressing »ON/OFF«. – The last input source used is automatically selected. Note: The following buttons on the HiFi or the remote control can also be used to switch on the system: »TUNER /BAND«... -
Page 21: Sound Settings
GENERAL FUNCTIONS ______________________________________________________________ Sound settings You can select between five different sound settings: You can select the sound settings » FLAT«, » POP«, » CLASSIC«, » ROCK« and » JAZZ«, depending on the type of music you are listening to. The basic setting is PRESET »FLAT«. -
Page 22: Tuner Mode
TUNER MODE ________________________________________________________________ Selecting the tuner input source PRESET Select the input source by pressing » TUNER /BAND«. – The most recently selected station is activated (Last Station Memory). – Display: e.g. » « or » «. Selecting a station position Select the frequency band (FM or MW) by pressing »... - Page 23 TUNER MODE _____________________________________________________________________________ Automatic station search By starting the automatic station search, you can delete all the existing preset stations and at the same time allocate new radio stations to them. Start the automatic search in tuner mode by pressing and holding down »PROGR«.
-
Page 24: Rds Station Service
TUNER MODE _____________________________________________________________________________ RDS station service RDS (Radio Data System) is an information system which is transmitted additio- nally by most FM stations. When the HiFi system is receiving an RDS station, the station name, e.g. » «, and » «... - Page 25 TUNER MODE _____________________________________________________________________________ Radiotext Some RDS stations provide ”radio text” as additional information. Radiotext appears as ticker text in the display. As the station transmits this information PRESET character by character, it may take some time before the text is received in full. Call up the radiotext by pressing »TEXT«...
- Page 26 TUNER MODE _____________________________________________________________________________ Radio traffic news Some RDS stations broadcast additional traffic news. If a such a station is being received, the » « symbol appears in the display. The EON (Enhanced Other Network) function is an additional RDS service with PRESET which you can switch automatically to a station with traffic news.
-
Page 27: Cd Mode
CD MODE ___________________________________________________________________________ Basic CD mode functions The HiFi system is suitable for music CDs bearing the logo shown here (CD-DA), and for CD-Rs and CD-RWs with audio data or MP3 formats. MP3 files must be created at a sampling frequency of 44.1 kHz. Several sessions with MP3 data can be read on a CD, i.e. -
Page 28: Selecting The Cd Input Source
CD MODE ____________________________________________________________________________________ Selecting the CD input source Select the input source using the » II« button. – If there is no CD in the compartment, the messages » «, and afterwards » « appear. – If there is a CD-R with MP3 formats in the compartment, » «... -
Page 29: Playing Back A Cd
CD MODE ____________________________________________________________________________________ Playing back a CD Press »CD « to start playback. ALBUM – Playback always starts with the first file of the first album (MP3) or with the first track (CD-DA). – Display in MP3 mode: » «, the number of the current album, the num- ber of the current file and the elapsed playing time of the file. -
Page 30: Selecting Another File Or Track
CD MODE ____________________________________________________________________________________ Interrupting/resuming playback (resume) You can interrupt the playback at any point and then resume it with the same file/track. You can also do this by switching to the » « input source or by ALBUM switching the HiFi to standby by pressing » ON/OFF«. To interrupt playback press »... -
Page 31: Searching For A Passage Within A File Or Track
CD MODE ____________________________________________________________________________________ Searching for a passage within a file or track During playback, press » « or » « and hold it down until 5 a § s s s 6 you find the passage you want to hear. When »... -
Page 32: Special Cd Mode Features
CD MODE ____________________________________________________________________________________ Special CD mode features Playing the introductions of files or tracks on the CD Press »INTRO« in the STOP position. – Display in MP3 or CD-DA mode: »INTRO«. ALBUM – The first ten seconds of each file or track on the CD are played. INTRO «... - Page 33 CD MODE ____________________________________________________________________________________ Repeating a file or a title (Repeat One) Press »CD II« to start playback. Press » « or » « to select the desired file or track. 5 a § s s 6 ALBUM Select the repeat function by pressing »REPEAT« once. –...
- Page 34 CD MODE ____________________________________________________________________________________ Repeating all files or tracks (Repeat All) Press »CD II« to start playback. Select the repeat function by pressing »REPEAT« until » ALL« appears ALBUM in the display. – The whole CD is played back repeatedly. To quit this function, press »REPEAT«. –...
- Page 35 CD MODE ____________________________________________________________________________________ Creating a track memory – playing back files or tracks in selected order You can create a track memory of up to 32 files on different albums (MP3) or up to 32 tracks (CD-DA) for the current CD in any order you choose and then play them back in that sequence.
- Page 36 CD MODE ____________________________________________________________________________________ Selecting and storing tracks (CD-DA only) Place a CD in the CD compartment. Note: The HiFi system must be in STOP mode. When this setting is being made, if no button is pushed for more than 10 seconds, the HiFi system will end the process automatically.
- Page 37 CD MODE ____________________________________________________________________________________ Changing the selection of files or tracks Press » « once during playback. – Display in MP3 mode: the current file, e.g. » «, and the current album, ALBUM e.g. » «. – Display in CD-DA mode: the current track number and » «.
-
Page 38: Timer Mode
TIMER MODE __________________________________________________________________ Your HiFi system has two timer modes: – The switch-on timer, which switches the HiFi system on and off at a preset time. – The sleep timer, which switches the HiFi system off at a preset time. Switch-on timer Setting the switch-on timer Note:... -
Page 39: Sleep Timer
TIMER MODE ______________________________________________________________________________ If you select Tuner, set the desired station position with » § « or » « and press »TIMER«. s s s 6 Set the desired volume using »+ VOLUME –«. Press »TIMER« to finish the settings. Deactivating the switch-on timer To deactivate the switch-on timer, briefly press »TIMER«... -
Page 40: Information
INFORMATION _____________________________________________________________ Cleaning the CD unit If the stereo system no longer scans CDs perfectly, use a commercially available cleaning CD to clean the laser optics. Other cleaning methods may damage the laser optics. To clean CDs use a lint-free cloth and wipe them in a straight line from the centre of the disc outwards. Do not use cleaning fluid for vinyl records or other solvents or scouring agents. -
Page 41: Rectifying Minor Problems
INFORMATION __________________________________________________________________________ Rectifying minor problems Not every kind of sound interference is caused by a defect in your HiFi system. Impairment can also be caused by leads having been accidentally pulled out, damaged CDs and worn out batteries in the remote control. If the following measures do not bring about satisfac- tory results, consult an authorised dealer. -
Page 42: Grundig Service
GRUNDIG Service GRUNDIG Deutschland Ihre regionale Kundendienst-Stelle in Deutschland erreichen Sie unter: Telefon 0180/5 23 18 52* • Telefax 0180/5 23 18 46* *gebührenpflichtig GRUNDIG BELUX N.V. GRUNDIG IRELAND LTD. GRUNDIG PORTUGUESA GRUNDIG DANMARK A/S GRUNDIG AUSTRIA Ges.m.b.H. Deltapark, Weihoek 3, Unit 3G 2 Waverley Office Park, Old Comércio de Artigos Electróni-... - Page 43 Grundig AG Beuthener Str. 41 D-90471 Nürnberg http://www.grundig.com • • •...
