Panasonic TC-L50ET60 Specification

50" lcd hdtv7

Hide thumbs Also See for TC-L50ET60:

Download this manual See also: Owner's Manual

Dimensions (W x H x D)

Mass

Power Source

Top View

Front View

44.3 (1123)

17.8 (450)

Back View

15.8 (400)

Note:

To make sure that the LCD TV fits the cabinet properly when a high degree of precision

is required, we recommend that you use the LCD TV itself to make the necessary

cabinet measurements. Panasonic cannot be responsible for inaccuracies in cabinet

design or manufacture.

SPECIFICATIONS

44.3" (1,123 mm) x 28.2" (714 mm) x 10.9" (275 mm)

(Including pedestal)

44.3" (1,123 mm) x 26.0" (659 mm) x 1.4" (35 mm)

(TV Set only)

41.9 lb. (19.0 kg) (Including pedestal)

35.3 lb. (16.0 kg) (TV Set only)

AC 110-127 V, 60 Hz

DIMENSIONS

Side View

5.2 (129.8)

TC-L50ET60

50" LCD HDTV7

Side Panel

1.4 (35)

10.9 (275)

Bottom Panel

JACKS

Specifications are subject to change without notice.

Non-metric weights and measurements are

approximate.

P121226
