Model No. Serial No. Dear Customers Thank you for purchasing this JVC product. Before use, please read the Safety Precautions and Cautions on p.2 and p.4 to ensure use of this product. Detailed User Guide This product is provided with "Basic User Guide"...
• Remove the mains plug immediately if the Make a backup of important recorded data camcorder functions abnormally. JVC will not be responsible for any lost data. It is recommended to copy your important recorded CAUTION: data to a disc or other recording media for storage •...
Page 3
Plug", as shown. 13. Refer all servicing to qualifi ed service personnel. For this AC plug adapter, consult your nearest JVC Servicing is required when the apparatus has been dealer. damaged in any way, such as power-supply cord or...
Cautions Recording Medium Main Unit • Be sure to follow the guidelines below to • For safety, DO NOT prevent corruption or damage to your recorded ... open the camcorder's chassis. data..disassemble or modify the unit. • Do not bend or drop the recording medium, or ...
Page 5
... do not modify or disassemble..do not expose the battery to temperatures Changes or modifi cations not approved by JVC exceeding 60°C (140°F), as this may cause could void the user's authority to operate the the battery to overheat, explode or catch fi re.
• Do not remove the rear cover or connect Cautions cables while wet. • Do not remove the rear cover while wet. • Note that JVC KENWOOD Corporation • Do not use the unit in water; otherwise bears no responsibility for any loss of a malfunction may occur.
Verifying the Accessories AC Adapter * AC cord LAN Cable QAL1466-001 Software CD-ROM Rear Cover Basic User Guide (This manual) *1 Use the supplied AC cord when connecting the AC adapter. ● Purchase an SD card separately. Operation confirmed with the following SD cards. Manufacturer Panasonic TOSHIBA...
Component Names and Functions ● Camera <Front> <Back> RESET DIRECT WLAN LAN(OFF) ETHERENT <Top> <Bottom> Internal mic: Transmits/Records User Guide." sounds coming through this mic when SD card slot: For compatible cards, no external mic is connected. see p.7. Lens: Do not touch it directly. [MIC] terminal: Connect an external LED light: Works as a light in dark mic.
Attaching/Removing Devices Inserting/Removing an SD card Insert a commercially available SD card before recording. ● Inserting ● Removing Insert the card straight with the terminal Push the card in once, and pull it out facing to the right. straight. • Turn off the power before inserting/removing the SD card. •...
Preparation before Use Connecting the Camera to Connecting the AC Adapter Your Computer Connect the supplied AC adapter to the To set up the camera, fi rst connect it to DC connector. your computer. Required operating environment RESET Browser: Internet Explorer 9 or later DIRECT WLAN LAN(OFF) ETHERENT...
Page 11
Configuring the Camera Settings Changing the settings Appropriate for Your Needs Select "NETWORK", "CAMERA/PAN TILTER", or "MANAGE" in the left window Specify the video format, zoom, etc. of the screen to change the settings. Click appropriate for your needs. Confi gure the "+"...
Using the Camera Viewing on a Browser Installing the Supplied Software Access "http://192.168.1.100:80" by "JVC CAM Control" allows you to control Internet Explorer. multiple cameras, change the angle, etc. If you log in using the user name and Insert the supplied software CD-...
Page 13
Download the software appropriate with “JVC CAM Control.” for your environment. • Smartphone (Android OS 2.3 or later) Download "JVC CAM Control Single" from Google Play Store. • Android tablet (Android OS 2.3 or later, Screen size: 7 inches or more, Resolution: 1024 x 600 or more) Download "JVC CAM Control Multi"...
Specifications Camera Power supply Using the AC adapter: DC 5 V, Using a battery pack: DC 3.6 V Power consumption 4.8 W Dimensions (mm) 73 x 48 x 89 (2 7/8'' x 1 15/16'' x 3 9/16'') (W × H × D) Approx.
Page 15
MEMO For more details, refer to the Detailed User Guide at http://manual3.jvckenwood.com/...
