Replacing The Motor Brushes; Specifications - Evolution Fury Instruction Manual

Refer to the pictures on pages 64.
1. Place saw on a level, secure surface.
2. Remove chip collector cover by loosening the retaining
screws.
3. Engage spindle lock.
4. Using supplied wrench, loosen and remove blade drive
flange.
5. Remove saw blade.
6. Thoroughly clean inner and outer blade drive flanges
and blade mounting surface before installing new
blade.
7. Reverse process to install new blade.

REPLACING THE MOTOR BRUSHES

1. Place saw on level, secure surface.
2. Remove two (2) motor brush retainer cap screws and
slide the brushes out.
3. If the Carbon rod is less than 6mm or if there are signs
of burning or damage, replace the brushes.
4. Reverse the process to re-assemble.
Note: Always run the saw without load for several minutes
after changing brushes. Failure to do so could cause
excessive sparking and or motor damage.
Model Evolution Fury Specifications
Motor (230v-240v ~ or 110v ~ 50/60 Hz) (Watts):
Maximum Box (1/8" 3mm Wall 90
Maximum Box (1/8" 3mm Wall 45
Optimum Cutting Thickness (Mild Steel Plate):
Maximum Cutting Thickness (Wood 90º):
RPM No Load (min-1):
Recommended Maximum Duty Cycle (Minutes):
Sound Pressure Level (Under Load) (dB(A)):
Vibration Level (Under Load) (m/s
Weight:
Maximum Dimensions HWD:
Minimum Dimensions HWD:
Blade Dimensions
Maximum Diameter:
Bore Diameter:
Thickness:
Ear and eye protection MUST be worn while operating
this equipment. Do NOT touch the blade while in motion.
Always follow the Personal Protection Equipment (PPE)
recommendations while operating this tool.
Lees deze gebruiks- en veiligheidsaanwijzingen zorgvuldig en
volledig. Voor uw eigen veiligheid, en vooraleer u dit apparaat
gebruikt, controleer dat de spanning juist is en dat alle handvatten en
onderdelen stevig vastzitten. Als u vragen hebt over enig aspect van
het gebruik van dit apparaat, gelieve contact op te nemen met onze
Technische Helplijn UK: 0870 609 2297
Technische Helplijn USA: 1-866-EVO-TOOL

SPECIFICATIONS

Belangrijk
Technische Hulplijn.
):
0
):
0
):
2
(11"x15-1/2"x17-3/4") 280x395x450
(9-1/2"x10-1/4"x15-3/4") 240x260x400
9
1050
(2-1/8") 54mm
(1-3/8") 35mm
(1/8") 3mm
(2-1/8) 54mm
3500
100.8
2.80
(12-1/4 lbs) 5.5kg
(7-1/4") 185mm
20mm
(1/16") 2mm
30
