Sharp AH-A9FEF Operation Manual

Sharp AH-A9FEF Operation Manual

Split type room air conditioner
Hide thumbs
Table of Contents

Advertisement

Quick Links

R22
AH-A9FEF
AH-A12FEF
OUTDOOR UNIT
INDOOR UNIT
AH-A9FEF
AU-A9FF
AH-A12FEF
AU-A12FF
AH-A9FEF
AH-A12FEF
SPLIT TYPE
ROOM AIR CONDITIONER
OPERATION MANUAL
CONTENTS
• SPECIFICATIONS .................................... 2
• TIPS ON SAVING ENERGY ..................... 5
• PART NAMES ........................................... 6
• BASIC OPERATION ................................. 10
• TIMER OPERATION ................................. 12
• TURBO COOLING OPERATION .............. 14
• ONE-HOUR OFF TIMER .......................... 14
• AUXILIARY MODE ................................... 15
• MAINTENANCE ........................................ 16
Thank you for purchasing a SHARP air
conditioner. Please read this manual care-
fully before operating the product.

Advertisement

Table of Contents
loading

Related Manuals for Sharp AH-A9FEF

Summary of Contents for Sharp AH-A9FEF

  • Page 1: Table Of Contents

    • AUXILIARY MODE ........15 • MAINTENANCE ........16 • BEFORE CALLING FOR SERVICE ..17 OUTDOOR UNIT INDOOR UNIT AH-A9FEF AU-A9FF Thank you for purchasing a SHARP air AH-A12FEF AU-A12FF conditioner. Please read this manual care- fully before operating the product.

  • Page 2: Specifications

    SPECIFICATIONS Model AH-A9FEF AH-A12FEF Cooling capacity (kJ/h) 9495 12660 Rated freqency (Hz) Rated voltage (V) Rated current (A) Rated input (W) 1100 External dimensions (mm) Indoor unit 810x270x184 790x280x200 (WxHxD) Outdoor unit 730x540x250 Indoor unit Weight (kg) Outdoor unit We reserve the right to change the materials and apecifications without notice.

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS WARNINGS FOR USE Do not pull or deform the power supply cord. Pulling and misuse of the power supply cord can result in damage to the unit and cause electrical shock. Be careful not to expose your body directly to the outlet air for a long time. It may affect your physical conditions.
  • Page 4 IMPORTANT SAFETY INSTRUCTIONS CAUTIONS FOR USE Open a window or door periodically to ventilate the room, especially when using gas appliances. Insufficient ventilation may cause oxygen shortage. Do not operate the buttons with wet hand. It may cause electric shock. For safety, turn the circuit breaker off when not using the unit for an extended period of time.

  • Page 5: Additional Notes On Operation

    ADDITIONAL NOTES ON OPERATION OPERATING TEMPERATURE RANGE INDOOR TEMP. OUTDOOR TEMP. 32˚C D.B. 43˚C D.B. upper limit 23˚C W.B. COOLING 21˚C D.B. 21˚C D.B. lower limit 15˚C W.B. D.B. = Dry-bulb W.B. = Wet-bulb • The built-in protective device may prevent the unit from operating when used out of this range.

  • Page 6: Part Names

    PART NAMES INDOOR UNIT (AH-A9FEF) 1 Inlet (Air) 2 Open Panel 3 Air Filters 4 AUX. Button 5 Indicator Panel 6 Receiver Window 7 Power Supply Cord 8 Vertical Adjustment Louvres 9 Horizontal Adjustment Louvres 0 Outlet (Air) q Remote Control w TURBO COOLING Lamp (green e TIMER Lamp (orange r OPERATION Lamp (red...
  • Page 7 INDOOR UNIT (AH-A12FEF) 1 AUX. Button 2 Inlet (Air) 3 Open Panel 4 Air Filters 5 Indicator Panel 6 Receiver Window 7 Vertical Adjustment Louvres 8 Horizontal Adjustment Louvres 9 Outlet (Air) 0 Power Supply Cord q Remote Control w TURBO COOLING Lamp (green e TIMER Lamp (orange r OPERATION Lamp (red t Inlet(Air)

  • Page 8: Remote Control

    PART NAMES REMOTE CONTROL 1 TRANSMITTER 2 DISPLAY (Liquid Crystal Display) 3 ON/OFF Button 4 TEMP. Button 5 ONE-HOUR OFF TIMER Button 6 MODE Button 7 TIMER ON Button (for setting the timer) 8 FAN Button 9 TIMER OFF Button (for setting the timer) 0 SWING Button q TIMER CANCEL Button w TURBO COOLING Button...

  • Page 9: Using The Remote Control

    USING THE REMOTE CONTROL LOADING BATTERIES Use two size-AAA (R03) batteries. Remove the battery cover at the back of the remote control. Insert batteries in the compartment, making sure the ± and — polarities are correctly aligned. • Lines will be indicated on the dis- play when batteries are properly installed.

  • Page 10: Basic Operation

    BASIC OPERATION Press the MODE button to select the operation mode. AUTO COOL Press the ON/OFF button to start operation. • The red OPERATION lamp ( ) on the unit will light. Press the TEMP. button to set the desired temperature. AUTO/DRY MODE The temperature can be changed in 1°C increments within the range of 2°C higher...

  • Page 11: Adjusting The Air Flow Direction

    ADJUSTING THE AIR FLOW DIRECTION VERTICAL AIR FLOW DIRECTION Press the SWING button on the remote con- trol once. • The vertical adjustment louvre will change its angle continuously. Press the SWING button again when the vertical adjustment louvre is at the desired position.

  • Page 12: Timer Operation

    TIMER OPERATION TIMER OFF The unit will turn off automatically according to your setting. Timer duration can be set from a minimum of half an hour (30 minutes) to a maximum of 12 hours. Up to 9.5 hours, you can set in half-hour (30-minute) increments, and from 10 to 12 hours, in 1-hour increments.

  • Page 13: Timer On

    TIMER ON The unit will turn on automatically according to your setting. Timer duration can be set from a minimum of half an hour (30 minutes) to a maximum of 12 hours. Up to 9.5 hours, you can set in half-hour (30-minute) increments, and from 10 to 12 hours, in 1-hour increments.

  • Page 14: Turbo Cooling Operation

    TURBO COOLING OPERATION In this operation, the air conditioner fan works at "extra high" speed with a setting temperature of 15°C to rapidly cool the room. Press the TURBO COOLING button during op- eration. • The remote control will display " ".

  • Page 15: Auxiliary Mode

    AUXILIARY MODE Use this mode when the remote control is not available. (AH-A9FEF) TO TURN ON Lift the front panel of the indoor unit and press the AUX. button on the operation panel. • The red OPERATION lamp ( ) on the unit will light and the unit will start operating in the AUTO mode.

  • Page 16: Maintenance

    MAINTENANCE Be sure to disconnect the power cord from the wall outlet or turn off the circuit breaker before performing any maintenance. CLEANING THE FILTERS The air filters should be cleaned every two weeks. TURN OFF THE UNIT REMOVE THE FILTERS 1 Lift the open panel.

  • Page 17: Before Calling For Service

    BEFORE CALLING FOR SERVICE The following conditions do not denote equipment malfunctions UNIT DOES NOT OPERATE SWISHING NOISE The unit will not operate if it is turned on The soft, swishing noise is the sound of immediately after it is turned off. The unit will not the refrigerant flowing inside the unit.
  • Page 20 SHARP CORPORATION Printed in Thailand TINSEA427JBRZ 05D-...
