M-U420 Series

AU-100 Series
16
2 -STATION PRINTER
2 -STATION PRINTER
Serial Impact Dot

M-780

Options
Validation sensor
Near-end sensor
Autocutter
Serial Impact Dot
Options
Validation sensor
Near-end sensor (R / J)
Autocutter
Taiwan Mark Sensor (M-U420B)
(R / J): Receipt / Journal
AUTOCUTTER
Versatile Autocutter
Fastest two-station printer
The fastest printing in the two-station printer class
The highly reliable M-780 is the fastest printer in the two-station printer class.
Saves end-user's running cost
Helps save end-user running costs by using inexpensive 38-mm roll paper.
Convenient design
Designed with a paper-holding mechanism that prevents paper jams.
SPECIFICATIONS
Paper Width
Validation : 134 mm or more (W) x 70 mm or more (H)
Column Capacity
Printing Speed
Voltage
MCBF
Overall Dimensions
Mass
Industry-wide Standard For ECR/POS Applications
Easy operating design
The clamshell design makes it easier for the operator to insert paper and
remove jammed paper.
Excellent cost-performance ratio
The M-U420 provides the highest cost-performance ratio to customers.
Taiwan "Mark Sensor" available with the M-U420B
Users can set up the ECR/POS to fit special requirements for the Taiwanese
market.
SPECIFICATIONS
Paper Width
Validation : 135 to 210 (W) x 70 (H) mm minimum
Column Capacity
Receipt : 24 columns Journal : 24 columns Validation : 55 columns
Printing Speed
Voltage
MCBF
Overall Dimensions
Mass
The AU-100 series detects the position of the cutter blade by means of a
mechanical contact and controls the rotating direction of the motor. This
allows the AU-100/AU-110 to achieve both partial and full cutting of paper.
SPECIFICATIONS
Paper Type
Width
Thickness Normal Paper: 0.06 to 0.085 mm, Thermal Paper: 0.065 mm
Reliability (MCBF)
12 VDC ± 10 %
Voltage
Peak Current
Mean Current Approx. 800 mA
Ambient temperature
Dimensions
Mass
Impact Printers
Impact Printers
Roll paper: 37.5 ± 0.5 mm
18 columns x 2, Validation: 42 columns
3.3 lines / sec. (at 24 VDC)
24 VDC ± 5%
10%
6
3 x 10 lines
135 (W) x 227.7 (D) x 150.5 (H) mm
Approx. 1.0 kg
Roll paper : 44.5 ± 0.5 mm
3 lines / sec. (at 24 VDC)
+5%
24 VDC
-10%
6
4 x 10 lines
150.7 (W) x 251.5 (D) x 103.5 (H) mm
Approx. 1.0 kg
AU-100 AU-110
Normal Paper, Recommended Thermal Paper
37.5 to 89.5 mm
5
3 x 10 cuts (incl. full & partial)
24 VDC ± 10 %
Approx. 2 A
Approx. 3 A
Approx. 500 mA
0 to 50˚C
103.0 (W) x 71.5 (D) x 21.5 (H) mm
Approx. 400 g
