AG-HMR 10 Sy ste m A p pl i ca t i ons
High-Quality, Full-HD Video Input and Output
A Portable Recorder for Various Situations and Applications
Tapeless Recording from Existing Camera Recorders
The HD-SDI input terminal on the AG-HMR10 allows it to record full-HD video signals
sent from a wide range of devices, including tape-based camera recorders. An Auto REC
function also automatically starts and stops recording in sync with the camera operation,
to allow easy backup recording without operating the AG-HMR10.
HD-SDI
REC Start/Stop
Trigger
HD Camera Recorder
* To use linked and automatic recording,
the function must be supported by the connected camera recorder.
Handy for Recording Data onto SDHC/SD Memory Cards
Connection is also possible to existing HD box cameras or weather cameras via
HD-SDI. Image can be recorded to a large-capacity SDHC/SD Memory Card,
which enables up to approx.12 hours of HD recording*.
HD-SDI
HD BOX Camera
* In HE (extended time) mode using a 32 GB SDHC Memory Card.
Easy Output of High-Quality, Full-HD Images
HD-SDI output and an HDMI terminal make it possible to output full-HD images for
large displays. Auto Repeat playback comes in handy for displays at events and
digital signage.
SDHC/SD
Memory Card
HD-SDI/HDMI
1080i/720p
AG-HMR10
Auto Repeat
Playback function
* An optional input board may be necessary for some models.
SDHC/SD
AG-HMR10 Memory Card
Auto REC function*
SDHC/SD
AG-HMR10 Memory Card
PDP/ projector *
* The illustration is an image intended only to
show the installation condition.
