Intel Desktop Board DQ67SW Product Guide
Setting the BIOS Configuration Jumper
NOTE
Always turn off the power to the computer before moving the jumper. Moving the
jumper with the power on may result in unreliable computer operation.
Figure 25 shows the location of the Desktop Board's BIOS configuration jumper block.
Figure 25. Location of the BIOS Configuration Jumper Block
58
