Giant FAITH 0 Datasheet

92
Faith 0
Specifications
SIZES XS,S,M,L
COLORS Brushed/Blue
ALUXX SL-Grade Aluminum,
FRAME
7.0" Maestro Suspension
RockShox Totem Solo Air w/ 20mm
FORK Thru Axle and tapered steerer,
180mm travel
SHOCK RockShox Vivid 5.1
HANDLEBAR Race Face Respond DH, low rise 31.8
STEM Race Face Diabolus D2
SEATPOST Giant Connect SL, 30.9
SADDLE Giant DJ
PEDALS Giant Alloy Platform, sealed
SHIFTERS SRAM X9 trigger
FRONT DERAILLEUR MRP Mini G2 guide, Custom for Giant
REAR DERAILLEUR SRAM X9
BRAKES Avid Elixir CR 203F/180R
BRAKE LEVERS Avid Elixir CR
CASSETTE Sram PG970 11x32, 9-speed
CHAIN
Shimano HG-73
CRANKSET Race Face Atlas FR, 36T
BOTTOM BRACKET Race Face X Type, External
RIMS Sun Ringle MTX31
[F] Giant Tracker w/ 20mm Axle, [R] Sun
HUBS
Jumping Flea w/ 12mm Axle, 32h
SPOKES DT Competiton, 14/15g
TIRES Kenda Nevegal, 26x2.5 Stick-E
EXTRAS Convertible Dropouts
Specifications and availability subject to change without notice.
SPLIT-SECOND LINE CHOICES. BLIND DROPS.
SKETCHY LANDINGS. IN KURT SORGE'S
WORLD, EQUIPMENT IS KING. THAT'S WHY
KURT CHOOSES FAITH.
Frame Technology
Unveiled by Kurt with a podium finish at the Red Bull Rampage contest, the all-new Faith is the
most advanced 7-inch freeride bike ever created. With lightweight ALUXX SL aluminum tubing
and a unique convertible rear dropout system, it's bombproof enough for Kurt yet versatile enough
for your home trails.
Key Upgrades (over Faith 1)
— RockShox Totem Solo Air, 180mm suspension fork, RockShox Vivid 5.1 rear shock
— SRAM X.9 shifters/X.9 rear derailleur with Avid Elixir CR disc brakes
— Race Face Respond DH handlebar/Diabolus stem with Giant Connect SL seatpost
— Sun Ringle MTX31 rim/Giant Tracker 20mm (f) hub/Formula Disc (r) hub, wheelset
frame geometry
Actual Part Head Seat
Frame Size Number Angle Angle*
inches degrees degrees
XS 348652 66.8 65.2 / 64.7
S 348653 66.8 62.9 / 62.4
M 348654 66.8 62.2 / 61.7
L 348655 66.8 63.3 / 62.8
*Seat angle is actual
**Toptube is measured from the center of the headtube horizontally back to the top of the effective extension of the seattube
***Standover height is based on the largest size tire that will fit the bike, not necessarily the included size tire
Seat Angle, Chainstay and Wheelbase are adjustable with Convertible Dropouts
+
Toptube** Headtube Chainstay
inches inches inches
+ 20.1 4.5 17.4 / 17.5 +
22.1 4.5 17.4 / 17.5
+ +
23.2 4.5 17.4 / 17.5
+ +
24.4 4.5 17.4 / 17.5
+ +
Standover
Wheelbase
Height***
inches inches
43.3 / 43.4 + 28.7
43.9 / 44.0 29.9
+
44.8 / 44.9 30.0
+
46.2 / 46.4 31.1
+
