AIR PURIFYING DEHUMIDIFIER

MODEL

MJ-EH155JV-H

MJ-EH142JV-H

INSTRUCTION MANUAL

Features

z Dehumidifying, air-purifying and

deodorizing all in one.

z Automatic switch dehumidification and

air-purification smartly.

z Clearly display the cleanliness of indoor

air quality.

This appliance is designed for use in Hong Kong and Macau only and please do not use in any other countries.

z This appliance is not intended for users (including children) with insufficient physiological, sensory or mental capabilities or the

lack of experience or knowledge, unless it is used under the supervision or instruction of someone in charge of their safety.

z Children should be supervised to ensure that they do not play with the appliance.

z If the power cord is damaged, it must be replaced by Mitsubishi Electric Service Centre in order to avoid a hazard.

Table of Contents

z Recommended Ways of Using the Unit 2

z Features of This Dehumidifier

z Safety Requirements

z Precautions

z Names and Functions of Parts

z Preparation

z Moving the Unit

z Smart Auto Operation

z Dehumidifying

z Laundry Drying

z Air Purifying

z Timer Setup

z How to Operate the Automatic Louvre 20

z Using the Child Safety Lock

z Dry Inside Operation

z Draining

z Continuous Drainage

z Maintenance

z Replacement of Consumables

z Storage

z Troubleshooting

z Specifications

z Disposal

English

Need help?

Do you have a question about the MJ-EH155JV-H and is the answer not in the manual?

Questions and answers

Summary of Contents for Mitsubishi Electric MJ-EH155JV-H

Page 1 Children should be supervised to ensure that they do not play with the appliance. z If the power cord is damaged, it must be replaced by Mitsubishi Electric Service Centre in order to avoid a hazard.
Page 2 Recommended Ways of Using the Unit For automatic dehumidification and air purification Smart Auto operation Auto Speed ˜ For automatic operation ˜ For reduce blowing sound Speed operation For dehumidification Dehumidify ˜ When you want to set Auto Speed the humidity High Speed ˜...
Page 3 Features of This Dehumidifier ˜ Room temperature may rise ˜ The operating room 2–4°C during operation. temperature range is 5 to 35°C. The dehumidifier does not have a cooling function If the room temperature exceeds 35°C, the blower While it is operating, heat is generated, so the room will operate or the airflow rate will increase.
Page 4 If the power cord is damaged, please fully may cause dust to accumulate, contact Mitsubishi Electric Service Centre for resulting in fire and/or electric shock. replacement in order to avoid causing a fire or electric shock.
Page 5 CAUTION If the temperature of the Do not cover the air outlet surroundings of the drain pipe or inlet with a cloth or is 0°C or lower, continuous blanket. drainage is not possible. The interior of the hose will freeze Do not Forbidden Poor ventilation may result in fire and/...
Page 6 Mitsubishi Electric Service Centre. * If the power cord is damaged, please contact Mitsubishi Electric Service Centre for replacement. * For details of cleaning and other maintenance of the unit, please refer to section "Maintenance".
Page 7 Precautions ˜ Do not place the unit sideways or upside ˜ Drying laundry down Remove water from the laundry and flatten any wrinkles before hanging up the clothes. Use swinging Inclining the unit may cause water in the tank to louvre and blow air to the laundry.
Page 8 Note It is impossible to remove the back panel because the four places shown are tightened with four special screws. If the unit has any malfunctions, contact the Mitsubishi Electric Service Centre.
Page 9 Back Handle Odor Sensor (left and right) Detects the smell of cigarettes, etc. P10, 25 Rear Air Inlet Highly-Sensitive Dust Sensor P10, 11, 25 Detects cigarette smoke, dust, pollen, Pre-filter P12, 25 and other dirt in the air. Cooling Port Activated Carbon Filter Air Purifying...
Page 10 Names and Functions of Parts (Cont.) Control Panel Louvre (Wind Direction) Indicator (White) Main Display (White) Operation Mode Indicator (White) Speed Indicator (White) Power Switch Mode Switch Louvre (Wind Direction) Power Lamp Mode Lamp Switch (White) (White) Louvre (Wind Direction) Lamp (White) Speed Switch Speed Lamp (White)
Page 11 Timer Display (White) Full Lamp (Red) Filter Replacement Indicator (Red) Child Safety Lock Switch Child Safety Lock Lamp (White) z The “Mode”, “Humidity Set”, “Speed”, and “Louvre” switches will light up (in white). Dry Inside Switch z This air purifying dehumidifier can store the operation mode.
Page 12 Preparation Installing the Activated Carbon Filter and Air Purifying Filter in the Unit Take out the activated carbon filter and air purifying Install the fi lters in the unit. filter from the plastic bag and install it. 1 Push all the way in 2 Push all the way in air Pull out the pre-fi lter.
Page 13 Moving the Unit Use the casters for moving Hold the handle while moving the unit Handle (left and right) Casters (4) z Do not hold onto the louvre while moving the unit. z Sometimes, it is hard to push the unit due to the z Pay attention to prevent the power cord from getting orientation of the casters.
Page 14 Smart Auto Operation There are two wind speed modes: “Auto” and “Low”. This operation monitors the room condition and operates accordingly. Blip “Smart Auto” Operation Press to begin operation. When the humidity sensor, odor sensor, z Power lamp lights. and highly-sensitive dust sensor are used z The operation mode and wind speed are displayed.
Page 15 Dehumidifying There are four wind speed modes: “Auto”, “High”, “Middle”, and “Low”. Blip “Dehumidify” Press to begin operation. It is recommended to apply this mode when you want to maintain a comfortable level of humidity. z Power lamp lights. Smart Flap will be opened for operation. z The operation mode, wind speed, and louvre are displayed.
Page 16 Laundry Drying There are two wind speed modes: “High” and “Low”. The duration of laundry drying will be estimated and the unit stops automatically. Blip Press to begin operation. z Power lamp lights. z The operation mode, wind speed, and louvre are displayed.
Page 17 “Laundry” (Automatic Stop) The unit will monitor the humidity in the room, and then estimate the duration of laundry drying and stop automatically. Operation time is approximately 1 hour and can be up to approximately 12 hours. Laundry Drying Tips How to Hang Clothes z Pull to remove any wrinkles on the laundry.
Page 18 Air Purifying There are four wind speed modes: “Auto”, “High”, “Middle”, and “Low”. Blip “Air Purify” Press to begin operation. When air quality is a concern, it is z Power lamp lights. advised to apply this mode. z The operation mode, wind speed, and Smart Flap will be closed and start operation.
Page 19 Timer Setup ON Timer Operation OFF Timer Operation The start time of operation can be set between 1 to 12 hours. The duration of operation can be set between 1 and 12 hours. Set the timer when the power is off. Set the timer when the power is on.
Page 20 How to Operate the Automatic Louvre The louvre can swing. Select the desired direction while in use. Press • Automatic louvre starts z The wind speed switches each time when it is pressed. Blip Blip Blip Blip Blip Recommended Movement Louvre Description The louvre swings from the top to the front so that the wind Wide...
Page 21 Using the Child Safety Lock The switches can be locked. To prevent children from operating this unit, use this function. Press and hold for 3 seconds or more z Child safety lock lamp lights z If you lock the unit when the power is off The unit will not turn on, even if you press the power switch to turn it on.
Page 22 Dry Inside Operation The inside of the unit can be dried to suppress mildew growth on the cooler. The Dry Inside operation is recommended after dehumidification is completed. Automatic Operation Manual Operation The Dry Inside operation is performed upon Start the Dry Inside operation immediately. completion of each operation.
Page 23 Draining When the water tank is full (approximately 5.5 L), the unit automatically stops and the Full lamp lights. Please empty the water tank. When the water tank becomes full, the Full lamp lights. z After pouring out the water, replace the z Full lamp lights water tank, and the Full lamp will go out.
Page 24 Continuous Drainage If water collected by the dehumidifier can be discharged directly to the surroundings, a commercially-available hose (with an internal diameter of 15 mm) may be connected to allow continuous drainage. Continuous drainage saves the trouble of emptying the water tank whenever it is full and allows operation over an extended period of time. z Commercially-available hose (ID 15 mm) Install the air purifying filter and Long enough to reach the drain from the...
Page 25 Maintenance Do not use detergents, cleaning agents for heat exchange equipment, decontamination powders, chemically treated cloth, gasoline, volatile oil, thinners, etc. They can damage the water tank or the unit, which may result in leakage. Once Every Two Weeks Once Every Six Months Air inlet, Smart Flap, humidity Highly-sensitive dust sensor, cooling port, odor sensor...
Page 26 Model: MJPR-ECJVFT-H According to the Japan Electrical Manufacturers’ Association Standard Mitsubishi Electric original products must (JEM1467), durability of the filter is three years. be used, please contact the Mitsubishi (In the case of five cigarettes a day) Electric Service Centre for purchase.
Page 27 Storage Storage CAUTION Leave the unit for one day after it stops running so that residual water inside the unit dries up, and then perform the following. When storing the power cord, put on the power plug cap and be careful not to Perform the Dry Inside damage the power cord.
Page 28 Troubleshooting z For the symptoms listed below, refer to the remedies listed on the right. Symptom Cause/Remedy z The unit blows out warm air because dehumidified air passes through the The unit blows warm air. re-heating coil. (There is no cooler function.) This is not a malfunction. z Are the temperature and humidity too low? No water in the water tank.
Page 29 Inside operation be absorbed by water inside the unit. The power plug or power socket z Stop operation and contact the Mitsubishi Electric Service Centre. generates abnormal heat. z Check to see if the pre-filter is dirty. → Perform maintenance of the pre-filter.
Page 30 If the symptoms persist even after following the prescribed remedies, or the error message does not disappear, unplug the power plug, and contact the Mitsubishi Electric Service Centre. z If the power cord is damaged, it must be replaced by the Mitsubishi Electric Service Centre in order to avoid a hazard.
Page 31 Specifications Model MJ-EH155JV-H MJ-EH142JV-H Power supply Single-phase, 220 V, 50 Hz Temperature 26.7 26.7 ° ° ° ° Condition Relative humidity Dehumidifying capacity 15.5 L/day 28.0 L/day 14.2 L/day 26.0 L/day Power consumption 250 W 290 W 230 W 260 W...
Page 32 Unit Do not disassemble. Dispose according to the garbage regulations in your district. Sole Agent in Hong Kong Mitsubishi Electric (Hong Kong) Ltd. Office -Tel.: 2510 0555, Service Centre – Tel.: 2427 8484 Web Site: https://www.mitsubishielectric.com.hk/en Please complete the following form for your future reference.
