Page 2
(N.O.R.M.) AND 85 (N.O.M.M.) AND HIGH PERFORMANCE SYNTHETIC OIL FOR 2 STROKE ENGINES. THE USE OF FUELS AND LUBRICANTS DIFFERENT FROM THOSE INDICATED CAUSES SEVERE FUNCTIONAL INCONVENIENCES TO THE VEHICLE AND THE VOIDING OF THE aprilia GUARANTEE. To have the catalytic converter functioning correctly for long periods and to reduce possible problems regarding the contamination of the thermal unit and of the exhaust, it is necessary to avoid covering long distances with the engine running at constantly low rpm.
Page 3
CATALYTIC SILENCER The catalytic version of the MX50 is fitted with a silencer with metal catalytic converter of the “platinum- rhodium bivalent” type. This device provides for the oxidation of the CO (carbon monoxide) and of the HC (unburned hydrocarbons) contained in the exhaust gases, changing them into carbon dioxide and steam, respectively.
Page 4
To keep your aprilia vehicle always in perfect operat- ing conditions, we advise you to insist on Original Spares and to have repairs carried out only by aprilia Authorized Outlets and Official Dealers. When ordering spare parts from the Dealers, always...
Carefully observe the instructions preceded by the CONTENTS following warning signs: Pag. Safety norms and regulations to protect CATALYTIC MUFFLER ..........2 the driver and other people from severe CATALYTIC SILENCER ..........3 injuries or grave risks ARRANGEMENT OF THE CONTROLS....18 INSTRUCTIONS FOR USE ........
Page 6
BASIC SAFETY RULES To drive the vehicle it is necessary to be in posses- sion of all the requirements prescribed by law (driving licence, minimum age, psychophysical ability, insu- rance, state taxes, vehicle registration, number plate, etc.). Gradually get to know the vehicle by driving it first in areas with low traffic and/or private areas.
Page 7
Avoid obstacles that could damage the vehicle or make you lose control. Avoid riding in the slipstream created by preceding vehicles in order to increase your speed. Always drive with both hands on the han- dlebars and both feet on the footrests (or on the rider’s footboards), in the correct driving posture.
Page 8
If necessary, have the vehicle inspected by an Con- cessionario Ufficiale aprilia who should carefully check the frame, handlebars, suspensions, safety parts and all the devices that you cannot check by yourself.
Page 9
Any modification of the vehicle and/or the removal of original components can compromise vehicle perfor- ONLY ORIGINALS mance levels and safety or even make it illegal. We recommend respecting all regulations and natio- nal and local provisions regarding the equipment of the vehicle.
Page 11
LOAD Be careful and moderate when loading your luggage. Keep any luggage loaded as close as possible to the center of gravity of the vehicle and distribute the load uniformly on both sides, in order to reduce umbalan- ce to the minimum. Furthermore, make sure that the load is firmly secured to the vehicle, especially during long trips.
Page 12
Low pressure can cause handling prob- TYRE INFLATION PRESSURE lems and the tendency to weave and in Driver only extreme cases loss of control. Kind of drive Moreover this will cause a great increase of roll- Front Rear ing friction. On asphalt 1,8 bar 1,9 bar...
ARRANGEMENT OF THE CONTROLS The control devices are positioned as indicated in fi- gures 3 and 4, as follows: 1) Clutch lever 2) Cold start control 3) Front brake lever 4) Twist grip 5) Rear brake pedal 6) Kick-starter 7) Gear pedal Fig.
Page 15
MULTIFUNCTION COMPUTER The display is provided with an automatic shutoff function. In case the vehicle or the display are left unused for more than 30 min- 88:88 88:88 ASS PD MS ASS PD MS AR TT AR TT utes, the display will be automatically disabled. All the pre-set data will nevertheless be stored.
Page 16
By simply setting the front wheel circum- ference, two different types of vehicles, bike 1 and bike 2, can be stored inside the multi- function computer memory. 88:88 88:88 Left display: Vehicle (1), total distance covered (2), AR TT AR TT partial distance covered (3) and maintenance func- tions (4) can be selected;...
Page 17
START-UP SETTING Metric system setting (KM/H or MPH) Keep the three push buttons simultaneously pres- ◆ sed for about 2 seconds, then press any of them KM/H to start settings. Press left push button to change the unit of mea- ◆...
Page 18
Setting the “WS” wheel diameter To change the flashing value, press the left push ◆ button. 11 11 Press right push button to go to next value and ◆ KM/H then press left push button again to change this value. MODE Pre-set value 1840.
Page 19
Time setting Press left push button to select time displaying ◆ (24h or 12 h). Press right push button to set the ≈hour∆. Press ◆ 12:00:- - left push button to change the value. Press right push button to set the ≈minutes∆. ◆...
Page 20
Preventative lubrication check The preventative lubrication check is alrea- dy pre-set after the first 100 km (60 mi) for vehicle 1 and after the first 300 km (200 mi) for vehi- cle 2. To change lubrication interval, refer to page 25 MODE (STANDARD SETTING).
Page 21
Preventative maintenance check The preventative maintenance check is already pre-set after the first 300 km (200 mi) for vehicle 1 and after the first 990 km (600 mi) for vehicle 2. To change maintenance check interval, refer to MODE page 25 (STANDARD SETTING). Press left push button to modify the value.
Page 22
Checking the total distance covered (ODO) Press left push button to modify the value. ◆ Press right push button to shift to next value. ◆ Keep centre ≈MODE∆ push button pressed for ◆ about 1.5 seconds to confirm. Then start total race time setting (ART).
Page 23
Checking the total race time (ART) Press left push button to modify the value. ◆ Press right push button to shift to next value. ◆ 00:00 Keep centre ≈MODE∆ push button pressed for ◆ about 2 seconds to confirm. Start-up setting is now completed.
Page 24
Programming the second vehicle Keep the right push button pressed for about 5 se- 0:00 conds. The ≈WS∆ wheel diameter value of the second KM/H vehicle will appear on the left display. The menu rela- 11:53:48 ting to the second vehicle will be automatically ena- bled after a few seconds.
Page 25
STANDARD SETTING Keep the two outer push buttons pressed for about 2 seconds to enable the STAN- DARD SETTING programme. This menu will allow you to modify the wheel diame- MODE ter, the time setting, the vehicle lubrication and main- tenance interval, the total distance covered (ODO) and the total race time (ART).
Page 26
PARAMETERS SETTING/DISPLAYING Press the centre MODE push button to 0:00 scroll the different setting screens. KM/H 11:53:48 MODE During operation, screen (A) - showing the distance covered after the last resetting (TT), the current spe- ed, time and partial race time (RT) - will be displayed. 0:00 Press centre push button ≈MODE∆...
Page 27
Keep centre push button ≈MODE∆ and right push but- ton simultaneously pressed for about 2 seconds to shift to screen (D) - showing the preventative mainte- 30:42 nance check function - and press them again to shift KM/H again to screen (E) showing the preventative lubrica- 11:49:08 tion check function.
Page 28
DISABLING THE SCHEDULED MAINTENANCE SERVICES Whenever the scheduled maintenance or lubrication service intervals are not respected, the relating value will start flashing on the left display. MODE To switch this value off, keep the right and left push button simultaneously pressed for about 2 seconds. MODE Keep centre push button ≈MODE∆...
Page 29
CHRONOMETER The multifunction computer is equipped with a chro- 30:42 nometer, to be displayed on screen (B) together with trip meter (TT). KM/H 11:49:08 Press left push button to enable chronometer. ◆ Press centre push button ≈MODE∆ to display scre- ◆...
Page 30
RESETTING THE PARTIAL VALUES This function is used to reset the partial values stored 30:42 inside the computer memory. In particular: √ Partial distance covered (DST) KM/H 11:53:48 √ Trip meter (TT) √ Partial race time (RT) MODE √ Maximum speed (MS) √...
Page 31
ALIGNING THE PARTIAL VALUES (TRIP) The partial distance covered (DST) can be modified by increasing or decreasing the value appearing on 30:47 the display. This function can be used during compe- KM/H 11:49:13 titions to make the displayed value match the one re- lating to the racetrack.
Page 32
BACKLIGHTING Press right push button to enable display backlight- MODE ing, The light will be automatically switched off after 4 seconds. 88:88 ASS PD MS AR TT KM/H 88:88:88 Fig. 35...
Page 33
CHANGING THE BATTERY Remove headlight fairing. ◆ Loosen the 2 cross-head screws between instru- ◆ ment holder and metal plate. Disconnect the 2-way connector from speedome- ◆ ter transmission unit. To remove the digital instrument from its holder, ◆ slightly press on LCD side. Disconnect the ≈sliding shoe∆...
Page 34
IGNITION SWITCH / STEERING LOCK / STEERING LOCK LIGHT SWITCH Never turn the key to the " " position The ignition switch can be turned to three positions: while driving, in order to avoid losing First click clockwise = ≈ ≈ (start) ◆...
Page 35
CRASH-HELMET LOCK (Fig. 37) Using the ignition key it is possible to have access to the crash-helmet lock positioned on the rear part of the vehicle. Fig. 37 GLOVE / TOOL COMPARTMENT (Fig. 38) It is positioned on the inner part of the left side of the fairing.
After the first month of use, let the 1 servicing cou- that the tyres are inflated to the correct pressure pon be made by an aprilia Official Dealer. (see ≈TYRE INFLATION PRESSURE∆) and fill the fuel tank with premium grade petrol (see ≈TECH- If there is no oil left in the mixer oil tank, NICAL DATA∆).
Page 37
PRELIMINARY CHECKING OPERATIONS Component Check Page F r o n t a n d r e a r d i s c Check the functioning, the idle stroke of the control levers, the fluid level and 49-50 brakes make sure there are no leaks. Check the wear of the pads. If necessary, top up the fluid tank.
Page 38
STARTING (Fig. 39) Open the fuel coock on the tank (Fig. 39). ◆ Insert the ignition key and turn to ≈ ∆ position. ◆ In case of cold start refer to page 39 (COLD ◆ START), switch the cold start control on. ≈...
Page 39
Strongly push the start pedal, then release it im- ◆ mediately. If necessary, repeat this operation until engine is started. Keep front brake lever pulled and do not open ◆ throttles until departure. Do not accelerate abruptly with the engi- ne cold.
Page 40
Fig. 41 Before riding the motor cycle we advise you to get to know the controls and all their functions as explained in this manu- al. Contact your aprilia Offical Dealer if there is anything you do not understand.
If you need assistance or technical advice consult your aprilia Official Dealer, who can ensure you It is absolutely forbidden to put the vehi- quick and careful servicing. cle on the stand while being seated on it.
Page 42
24 months (after 1 month) OPERATIONS TO BE CAR- Battery - Terminal fastening - √ Electrolyte level RIED OUT BY THE aprilia Of- ficial Dealer (WHICH CAN BE every 3 months: Spark plug every 6 months: CARRIED OUT EVEN BY THE USER).
Page 43
OPERATIONS TO BE CAR- End of running- Every Every Component in period RIED OUT BY THE aprilia Of- 12 months 24 months (after 1 month) ficial Dealer. Rear shock absorber √ √ Carburettor √ √ Transmission cables and controls √...
IDENTIFICATION DATA It is a good rule to write down the frame and engine numbers in the space provided in this manual. The frame number can be used for the purchase of spare parts. Do not alter the identification numbers if you do not want to incur severe penal and administrative sanctions.
Page 45
◆ In case of oil leakages or malfunctions, Place a suitably large container (min. 1000 cm ◆ contact your aprilia Official Dealer. under the engine to catch the old oil. Unscrew the drain plug (3) placed on the bottom. ◆...
Page 46
(Fig. 46). If it is not possible to adjust the clutch by means of the adjusters, contact your aprilia Official Dealer Fig. 45 The clutch must be adjusted when it does not "re- lease" correctly and the vehicle tends to move even with the clutch pulled.
Page 47
SEPARATE LUBRICATION (Fig. 47) Top up the mixer oil tank every 500 km. The vehicle has a separate lubrication system which includes an mixer oil tank (Fig. 47) (1,3 with a re- serve of 0,5 ) and a variable-capacity oil supply pump (the capacity varies according to the number of revs of the motor and the opening of the throttle).
Page 48
Unscrew the drainage screw (1) and at the same ◆ time completely rotate the pump control lever (2) until the oil drains off, then tighten the screw again. Keep the pump lever rotated until all traces of air ◆ bubbles have completely disappeared from the carburettor supply pipe.
Page 49
ADJUSTING THE REAR BRAKE nut (3). (Fig. 49) Check the braking efficiency. The brake pedal is positioned ergonomically during If necessary, contact your aprilia Official the assembly phase. Dealer. If necessary, it is possible to adjust the height of the brake pedal: Refit the pin and the clip.
Page 50
CHECKING THE BRAKE PAD WEAR (Fig. 50) Check brake pads for wear every 2,000 km. In case of off-road use, with mud or sand, check brake pads after every ride. The pads present a groove that must always be visi- ble.
Page 51
From above, on the rear part, for rear brake cali- ◆ per. The excessive wear of the friction mate- rial would cause the contact of the pad metal support with the disc, with conse- quent metallic noise and production of sparks from the caliper;...
Page 52
ADJUSTING THE REAR SUSPENSION (Fig. 52) The rear suspension comprises a single spring- shock absorber unit and a lever unit with A.P.S. The standard rear suspension is suitable for a driver weighing about 75 kg. If your weight or your needs are different, work on the length of the shock absorber spring, by acting on the nut (1) to restore the right driving position.
Page 53
CHAIN ADJUSTMENT (Fig. 53) Stand the vehicle in an upright position and com- ◆ pletely extend the rear suspension. Check that the vertical movement in the lower part ◆ of the chain, at a point mid-way between the pin- ion and the crown, is about 30 mm. If this distance is not correct, proceed as follows: Loosen the rear wheel pin fastening nut.
Page 54
CHAIN LUBRICATION (Fig. 54) Proceed to chain lubrication frequently (see ≈LU- BRICANT CHART∆), every 4,000 km, every time the vehicle is used off-road on mud or sand. Fig. 54 CHAIN CHECKING (Fig. 55) From time to time check the wear condition of the chain;...
Page 55
COOLANT CHECKING Every 2000 km or after using the vehicle in difficult conditions, check the coolant level with cold engine; change the coolant every two years. Do not use the vehicle if the coolant is be- low the minimum allowed level. The coolant level must be included between 1/4th and 3/4ths of the expansion tank capacity.
Page 56
Do not exceed this level, otherwise the fluid will overflow when the engine is run- ning. Put back the plug on the expansion tank. ◆ If it is necessary to top up the coolant too frequently, contact your aprilia Official Dealer for a check.
Page 57
The minimum speed of the engine (idling) must be about 1500 rpm. By twisting the throttle, accelerate and decelerate ◆ a few times to verify the correct functioning and to check if the idling speed is constant. If necessary, contact your aprilia Official Dealer.
Page 58
ADJUSTING THE ACCELERATOR CONTROL (Fig. 58) The slack of the accelerator control must be about 2- 3 mm, measured on the the twist grip. To adjust the slack, proceed as follows: Remove the protection element (1). ◆ Release the nut (2). ◆...
Page 59
ELECTRICAL SYSTEM For battery efficiency (Fig. 59) it is very important that the correct load of acid be observed and that maintenance be car- ried out properly. If the following instructions are scrupulously observed, the battery life will be considerably prolonged. Preparing the vehicle for the road, charging the bat- tery: It is important to let the battery sit for at least 3 -...
Page 60
Battery shall be always kept FULLY CHARGED. BATTERY MAINTENANCE ◆ During winter, proceed to battery charging at least It is important to check the level of the electrolyte ◆ once a month. at least once a month or even more frequently It is also a good rule to recharge the battery from during the summer months.
Page 61
FUSE REPLACEMENT (Fig. 60) The fuse (7,5 A) is positioned under the saddle. If any device ceases to operate, check the fuse that protects the circuit. If the fuse is burnt-out the filament will be broken. Before replacing the fuse, look, if possible, for the cause of the fault.
Page 62
ADJUSTING THE HEADLIGHT BEAM (Fig. 61-62) To rapidly check the correct direction of the beam, place the vehicle on flat ground, 10 m away from a wall.Turn on the low beam, sit on the vehicle and ver- ify that the headlight beam projected on the wall is slightly under the horizontal line of the headlight (about 9/10th of the total length - Fig.
Page 63
CHANGING THE HEADLIGHT BULBS (Fig. 63) To change the low and high beam bulbs, proceed as follows: To extract the bulb electric connector, do not pull its electric wires. The headlight contains: A parking light bulb (1). ◆ A low beam/high beam bulb (halogenous) (2). ◆...
Page 64
LOW / HIGH BEAM BULB (HALOG-ENOUS) For the installation: To extract the bulb electric connector, do Insert the bulb in the bulb socket, making not pull its electric wires. the relevant positioning seats coincide. Grasp the bulb electric connector, pull it and di- Position bulb holder (8) into reflector and turn it ◆...
Page 65
PARKING LIGHT BULB To extract the bulb socket, do not pull its electric wires. Grasp the bulb socket (6), pull and disconnect it ◆ from its seat. Withdraw the parking light bulb (1) and replace it ◆ with one of the same type. Fig.
Page 66
Pos. Warning light Colour 2 stroke oil reserve ( Direction green indicators ( Neutral indicator ( ) green Low beam ( green High beam ( blue Withdraw the bulb and replace it with a new one of ◆ the same type. Fig.
Page 67
CHANGING THE REAR LIGHT BULBS (Fig. 68) Proceed as follows: Unscrew the two screws (1); ◆ Remove the glass (2); ◆ Press the bulb (3) slightly and rotate it anticlock- ◆ wise; Remove the bulb from its seat. ◆ The introduction of a new bulb can be carried out in one sense only, since the two guide pins are misaligned.
Page 68
CLEANING LONG INACTIVITY We advise cleaning the vehicle frequently, not only If the vehicle has to remain inactive for several for the sake of its appearance, but also because months, we advise: cleanliness helps to keep your vehicle in good Clean and protect the painted parts with polish;...
Page 69
TECHNICAL FEATURES MOTOR CARBURETTOR Model ..............AM6 Model ........... Dell»Orto PHBN 16 Diffuser............Æ 16 mm Type ........2 stroke single-cylinder with lamellar inlet AIR FILTER Cooling......Liquid with forced circulation Lubrication ..........Separate Sponge Bore / stroke........40,3 mm / 39 mm Displacement ..........49,75 cm IGNITION Compression ratio........
Page 70
LUBRICATION BRAKES Gearbox and primary transmission . 820 cm of oil (*) Front.........disc brake Æ 230 mm with hydraulic control COOLING and floating caliper with two parallel pins Rear .........disc brake Æ 220 mm Cooling circuit capacity ......... 0,9 with hydraulic control (60% antifreeze + 40% water) and fixed caliper Minimum operating temperature .......-17°C...
Page 71
DIMENSIONS WARNING LIGHTS Max. length ..........2050 mm Gear in neutral .......... 12 V - 2 W Max. width............. 820 mm Direction indicators ........12 V - 2 W Max. height to handlebars......1,200 mm Low beam ..........12 V - 2 W Seat height............
Page 72
LUBRICANT CHART Gearbox oil (recommended): F.C., SAE 75W - 90 or GEAR SYNTH, SAE 75W - 90. As an alternative to the recommended oil, it is possible to use high-quality oils with characteristics in compliance with or superior to the A.P.I. GL-4 specifications. Mixer oil (recommended): GREEN HIT 2 or CITY 2T.
Page 73
Yellow Pages or the map provided at our web site: www.aprilia.com When you demand aprilia Original Parts, you are purchasing products that have been developed and te- sted as early as the vehicle design stage. aprilia Original Parts systematically undergo strict quality control procedures to ensure total reliability and long service life.
