Niagara JACE-9000 System Backup & Recovery page 17

CAUTION: Recovering factory defaults removes all platform and station data from the device.
Make sure this is what you intend before you follow this procedure.
To reset a JACE-9000 to factory default state:
1. With the outer panel cover open, press and hold the SHUT DOWN button on the
JACE-9000 control panel.
1 SHUT DOWN shuts down the controller and serves as the factory defaults recovery button.
2 STAT (status LED) blinks during recovery of factory defaults.
3 DEBUG port is a USB-C port for serial debug communications between the controller and serial shell
running in the PC.
4 BEAT (Yellow); heartbeat LED that blinks at 1Hz during normal operation. Refer to "BEAT (Heartbeat) LED"
section for details.
2. While still pressing the SHUT DOWN button, reboot the controller using one of the
following actions:
• Add power to a powered off controller.
• Choose option
confirmation prompt.
Reboot is initiated.
3. Release the SHUT DOWN button 5 seconds after reboot is initiated.
Factory default restoration process begins.
When the BEAT LED blinks at normal rate the process is complete.
To setup the restored controller platform you will need to login to the serial shell using factory
default credentials.
Parent topic: Restore procedures
9 Reboot from the serial shell menu and enter "Y" at the
