Pre-disassembly Instructions
Do the following prior to starting any maintenance procedures:
1. Place the system on a stable work surface.
2. Remove the power adapter from the DC-IN jack (A) or USB Type-C ports (B and C) as
shown in Figure
3. Remove all cables from system.
Figure 1-1. AC Adapter Outlet
4. Remove the microSD card from the microSD card slot (D)
Figure 1-2. MicroSD Card Removal
Disassembly Procedures
1-1.
A B C
(Figure
D
0
1-2).
