B.

IR TOOL WALK-TEST

When walk-test is executed using the IR tool, only the selected device will enter the walk-test mode excluding
DUCT detectors with Remote Test Stations. All other devices will continue to operate normally. Utilize the
following procedure to perform the walk-test:
1. Enable IR communication from the control panel's Top Level Menu, F6-IR COMM for addressable
loop being tested.
2. Proceed to the first device to be tested.
3. IR select the device with the IR tool. Verify selection with flashing green LEDs.
4. Send test alarm command with the IR tool. Verify alternating red and green LEDs on device.
5. Device broadcasts a test alarm message. Message displays on control panel LCD and remote
displays (if applicable).
6. Audible devices programmed to respond to this device's activation turn on for 4 seconds
(continuous).
7. IR de-select the device or select next device to be tested (if IR single select is enabled). Device
being tested exits the test mode and the device LED returns to normal operation (flash green every 5
seconds).
8. After all devices are tested, download the panel history for testing records.
9. Disable IR communication for respective addressable loop. Devices require significantly more power
when their IR receivers are continually active.
10. Reset the control panel to return it to normal operation. Panel will be reset automatically after a
maximum of 4 hours.
6.4.1.5

BUZZER

This menu allows the user to turn off the panel's on-board buzzer during service and testing. A successful
Level 3 or higher password is required to access this feature. From the Maintenance Menu 1, press the F5
button to access the Buzzer screen:
Row C - Use the ◄►arrow buttons to move the cursor under the field; then use the +/- buttons to
•
toggle the field between NORMAL/DISABLED.

Note: The buzzer will remain disabled until the panel is reset, at which point it will return to normal
operation.
UL S2203
FM
1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0
A
B U Z Z E R
B
N O R M A L
C
D
Exhibit 6-15: Buzzer Screen
Cheetah Xi 50 Operation Manual
P/N: 06-369-2
O P E R A T I O N :
6.0 SYSTEM MAINTENANCE
Rev 8, 03/2024
6-9
