Marantz NR1603 Specification

NR1603
AV SURROUND RECEIVER
Slim Line 7.1 Channel 3D Pass Through,
Networking Home Theater Receiver with AirPlay
Delivering crystal clear sound and network capability, the Marantz NR1603 7.1 Home Theater Receiver offers powerful
performance in a Slim Line design. The receiver's comprehensive features include easy on-screen setup, an Ethernet
port, six HDMI inputs including 1 on the front which can be used to connect mobile devices such as a camcorder or tablet,
allowing you to immediately enjoy videos, photos, and music, and playback of the latest hi-definition audio formats. AirPlay
allows you to stream music wirelessly from your iPhone, iPod Touch and iPad over your home network. The NR1603's
advanced technology provides cutting-edge performance for all your movies and music.
Audio/Video Connections
Fully discrete power amplifiers
n
for all 7 channels
(50 W x 7 ch, 8ohm 20-20kHz 0.08%)
2.1 Channel Preamp-Out
n
Front Panel USB Input
n
AirPlay
®
n
FM Tuner
n
56 Tuner Presets
n
3 RCA Analog inputs
n
1 Optical, 1 Coaxial Digital Inputs
n
3D pass-through technology
n
6/1 HDMI In/Out (incl. FRONT HDMI Input)
n
-CEC (Control)
-ARC(Audio Return Channel)
-Standby source setting via HDMI control
-Auto Lip Sync.
-Deep Color, x.v.Color
-Pass through in Standby mode
3/1 Composite In / Out
n
2/1 Component video in / out
n
Headphone Out
n
Advanced Connections
Bluetooth wireless connectivity via
n
optional RX-101 Bluetooth Receiver
External IR Receiver
n
Marantz D-Bus(RC-5) Remote In / Out
n
Mobile App control
n
Audio/Video Processing
ANALOG DEVICES:
n
SHARC 32-bit Processor
Dolby: True HD/Digital Plus & EX/
n
Pro Logic IIz / IIx / II
DTS: HD Master & High Res. Audio/ES/96/24/
n
Discrete/Matrix6.1 /Neo:6 /Express
Multi Ch Stereo
n
Audyssey MultEQ Auto Calibration w/ MIC
n
Audyssey Dynamic EQ
n
Audyssey Dynamic Volume
n
9 Band EQ, -20dB - +6dB
n
Independent Crossover Setting for each
n
speaker
Lip-sync (digital audio delay) 0-200 msec
n
Volume Control Setting: Limit,
n
Power On Level, Mute Level,
Display type (0-98 or dB)
GUI output over HDMI
n
User Configurable Features
Input Level Adjust
n
Input Assign
n
(HDMI In/ Component In/ Digital In)
Input Rename
n
Input Skip
n
Graphic User Interface
n
Display Status Info.
n
Setup Assistant
n
Marantz Audio Advantage
All-discrete, 50w x 7 Class AB Output Stage
n
High Current Linear Power Supply
n
EI Core Power Transformer
n
Pure Direct / Source Direct
n
M-DAX (Marantz Dynamic Audio eXpander)
n
192kHz/24-bit Audio DACS
n
