- Page 1 MeacoDry Arete ® 20 / 25L Dehumidifier and Air Circulator ae: Greek goddess of “Excellence in all things”; in Ancient Greek Mythology • • Instruction Manual...
- Page 2 Thank you for choosing Meaco Thank you for choosing Meaco, we really appreciate it. After the success of the Arete® One range, we’ve built Arete® Two: a range of combined dehumidifiers and air purifiers for customers who want even more control over the humidity in their home. We took the time to design a dehumidifier that blends into your home without compromising on its performance.
-
Page 3: Table Of Contents
Contents Safety information ........Register your Meaco warranty ....Meaco app ..........What’s included ........... Product identification ........First steps ........... Operation ............ Water tank ........... Continuous drainage ......... Maintenance ..........Storing ............Troubleshooting .......... Meaco customer care ........ Specifications .......... -
Page 4: Safety Information
If these areas become wet for any reason, thoroughly dry them before using the dehumidifier. If in doubt, do not use the dehumidifier and consult a qualified electrician or a Meaco approved engineer. Domestic use only: This dehumidifier is designed for domestic use only and should not be used in commercial environments. - Page 5 • If there is any damage to the dehumidifier then do not use it and contact Meaco or your retailer. • As with all dehumidifiers, always keep upright and leave the dehumidifier standing upright for six hours before using it upon receipt.
- Page 6 Declaration of conformity Hereby, Meaco declares that this radio equipment is in compliance with Directive 2014/53/EU and with the relevant statutory requirements. The full text of the EU declaration of conformity and the UK declaration of conformity is available at the following internet address: www.meaco.com/pages/compliance-data.
- Page 7 E or coloured GREEN or GREEN/YELLOW. 4. Always ensure that the cord grip is positioned and fastened correctly. 5. Only ever use the same fuse as fitted in the original product. If in doubt please contact Meaco first or a qualified electrician.
-
Page 8: Register Your Meaco Warranty
Register your Meaco warranty Your Meaco dehumidifier comes with a free five year warranty. Simply register your details online and you’ll be covered for parts and labour for five years from the date of purchase, subject to the terms and condition of the warranty. As a thank you, you will be entered into our monthly free prize draw to help support the David Shepherd Wildlife Foundation. -
Page 9: Meaco App
Meaco App Control your new dehumidifier with the Meaco app. Scan the QR code to install the Meaco app or download the Meaco app from the App store or Google Play. Open the app and follow the instructions to create a new account and pair your dehumidifier. -
Page 10: What's Included
What’s included Carefully unpack the dehumidifier. Keep all packaging materials away from children. We recommend flat packing and keeping hold of the box should you need it in the future. 1. MeacoDry Arete® Two Dehumidifier and Air Purifier 2. Free H13 HEPA Filter 3. -
Page 11: Product Identification
Product identification 1. Handle 6. Castors 2. Air outlet 7. Combined dust filter and case 3. Water tank 8. Cable tidy 4. Louvre 9. Air inlet 5. Hose adaptor 10. H13 HEPA filter Important! Remove the plastic bag around the H13 HEPA filter before use. To lift the handle use two hands: one on the left-hand side and one of the right-hand side, then lift. -
Page 12: First Steps
First steps When you first receive your dehumidifier, it is important you follow the steps below carefully: 1. Check your dehumidifier and its box and packaging for any transport damage. In case of damage, inform the sender immediately. 2. Leave the dehumidifier to stand for six hours before turning it on. This will allow any refrigerant that may have moved during transit to settle. - Page 13 Dehumidifying your house Your dehumidifier can be used to maintain an optimum humidity level throughout your house or flat. Moisture in the air from the entire house/flat will migrate towards the dehumidifier, reducing the humidity level. When doing so, we would recommend the following: •...
-
Page 14: Operation
Operation When the dehumidifier is first plugged into the mains it will beep once, the power and timer button will light up. • All buttons on the control panel only require a short press: press the buttons firmly and quickly. •... - Page 15 If the humidity level has increased more than 3% above the target, the compressor will turn on and the dehumidifier will start to run again – the dehumidifying indicator will be solid. If the humidity level is within 3% of the target, the dehumidifier will go back to sleep and check the humidity level in another 30 minutes.
- Page 16 Night Mode: Press the Night Mode / child lock button once to enter Night Mode. The fan speed will be reduced to low (only if it is currently in high); the buttons will not beep when pressed and all lights on the display will turn off (the Night Mode indicator will turn off 3 seconds later than the rest of the display).
-
Page 17: Water Tank
Water tank The dehumidifier can be used to collect water in one of two ways: via the water tank or via continuous drainage. For more information on how to use continuous drainage, see page 15. When the water tank is full and requires emptying, the dehumidifier will turn off, beep five times (except in Night Mode) and the water tank full indicator will light up on the chase display. -
Page 18: Continuous Drainage
Continuous drainage Continuous drainage can be used to drain water from the dehumidifier without having to empty the water tank. This is ideal for customers who wish to leave their dehumidifier unattended in garages or second homes. The right-angle adaptor required can be found in the lid of the water tank. This adaptor has been designed to fit a standard garden hose (ID: 12.5mm). - Page 19 Remove the water tank Remove the right-angle adaptor from the water tank lid and push it onto the spout. The spout is where water drips out of the dehumidifier and is located on the left-hand side. Attach the hose to the spout. Insert the water tank back into the dehumidifier.
-
Page 20: Maintenance
Maintenance To ensure your dehumidifier is always performing at its best, it’s important to regularly clean it. • Always unplug your dehumidifier from the mains before cleaning. • Do not allow the dehumidifier to get wet. Cleaning the exterior Clean the exterior with a soft, dry cloth. If the dehumidifier is extremely dirty, use a slightly damp cloth. Never spray the device with water. - Page 21 • To insert/replace the H13 HEPA filter, place it inside the combined filter case and dust filter, then slide the combined filter case and dust filter into the dehumidifier. • Replacement H13 HEPA filters can be purchased from meaco.com. Cleaning the water tank To clean inside the water tank, simply remove the water tank lid.
-
Page 22: Storing
4. Clean the filter and store the device in a dust-free location away from direct sunlight, preferably covered with a sheet of plastic. Troubleshooting If you come across a problem with your dehumidifier, check the table below and try the suggestions. If the problem persists, contact Meaco. Error Action Dehumidifier indicator is not displayed The dehumidifier is checking the humidity level to see if it has risen above the set target. - Page 23 3) Change the dehumidifier to Night Mode, you will hear the change to low fan speed. Please contact Meaco. Please contact Meaco. Please contact Meaco. The environment the dehumidifier is being used in is too warm.
-
Page 24: Meaco Customer Care
Meaco customer care If you have a question about your Meaco dehumidifier, contact our Customer Service team who will be happy to help. Make sure you have your serial number and details of where and when you purchased your dehumidifier. -
Page 25: Warranty Terms & Conditions
3. If your dehumidifier has been opened or tampered with or not genuine components have been fitted by yourself or anyone other than a Meaco engineer, your warranty is invalid. 4. Components subject to normal wear and tear, the combined dust filter and case, H13 HEPA filter and hose adaptor are not covered by the warranty. - Page 26 Version: EN301 Meaco (U.K.) Limited Meaco House, Parklands, Railton Road, Surrey GU2 9JX meaco.com...
