Air conditioner (split type)

Advertisement

Quick Links

AIR CONDITIONER (SPLIT TYPE)
Installation Manual
Scan QR CODE to access installation and owner's manual on website.
https://www.toshiba-carrier.co.th/manuals/default.aspx
Manual are available in EN/FR/DE/IT/ES/PT/NL/GR/RU/TR/SV/FI/DA/
NO/PL/BG/RO/EE/LV/CR/SK/SI/HU/CZ/AR.
Outdoor Unit
Model name:
RAV-GM561ATP-E1
RAV-GM561ATJP-E1
For commercial use
English

Advertisement

Table of Contents
loading

Summary of Contents for Toshiba RAV-GM561ATP-E1

  • Page 1 AIR CONDITIONER (SPLIT TYPE) Outdoor Unit For commercial use Installation Manual Model name: RAV-GM561ATP-E1 RAV-GM561ATJP-E1 Scan QR CODE to access installation and owner’s manual on website. https://www.toshiba-carrier.co.th/manuals/default.aspx Manual are available in EN/FR/DE/IT/ES/PT/NL/GR/RU/TR/SV/FI/DA/ NO/PL/BG/RO/EE/LV/CR/SK/SI/HU/CZ/AR. English...
  • Page 2: Table Of Contents

    – 1 – Original instruction Center of gravity Please read this Installation Manual carefully before installing the Air Conditioner. • This Manual describes the installation method of the indoor unit. (Unit: mm) • For installation of the outdoor unit, follow the Installation Manual attached to the outdoor unit. ADOPTION OF R32 REFRIGERANT This air conditioner adopts the HFC refrigerant (R32) which does not destroy the ozone layer.
  • Page 3: Accessory Parts

    Cautions for outdoor unit installation space Accessory parts • In the event that the outdoor unit is installed in a small space Part name Q’ty Shape Usage and refrigerant leaks, accumulation of highly concentrated Installation Manual Booklet For hand this directly to the customer. refrigerant may cause a fi...
  • Page 4: Installation Conditions

    – 3 – Installation conditions Conventional tools (R32 or R410A) Vacuum pump Vacuum drying Usable if the backflow prevention adapter is installed. Before installation Air purge To purge air, use a vacuum pump. Vacuum pump with backflow Vacuum drying Conventional tools (R32 or R410A) Be sure to prepare to the following items before prevention function Do not use refrigerant charged in the outdoor unit to...
  • Page 5 Installation location <Example> Necessary space for CAUTION Suction hood (Side) installation (Unit: mm) Discharge hood WARNING Install the outdoor unit in a location where the discharge air is not blocked. Obstacle at rear side Discharge Install the outdoor unit properly in a location that When an outdoor unit is installed in a is durable enough to support the weight of the Upper side is free...
  • Page 6 – 5 – Obstacle in front Obstacles in both front and rear of unit Installation of outdoor unit Set the out margin of the anchor bolt to 15 mm or less. Open above and to the right and left of the unit. Above unit is free The height of an obstacle in both the front and rear of Before installation, check the strength and...
  • Page 7: Refrigerant Piping

    Refrigerant piping CAUTION Do not scratch the inner surface of the flared part Optional installation parts Flaring when removing burrs. 1. Cut the pipe with a pipe cutter. (Locally procured) Flare processing under the condition of scratches Flare nut Be sure to remove burrs that may cause a gas leak. on the inner surface of flare processing part will 2.
  • Page 8: Air Purging

    – 7 – Refrigerant pipe length Air purging Single Airtight test After completing the refrigerant piping work, perform an airtight test. Connect a nitrogen gas cylinder and Allowable pipe length (m) Height difference (Indoor-outdoor H) (m) pressurize the pipes with nitrogen gas as follows to conduct the airtight test. Model Total length L Indoor unit: Upper...
  • Page 9 Air purge Vacuum pump Pump down process Valve handling precautions Open the valve stem until it strikes the stopper. It is unnecessary to apply further force. With respect to the preservation of the terrestrial 1. Turn off the Air Conditioner system. As shown in the figure, connect the charge hose after Securely tighten the cap with a torque wrench.
  • Page 10 – 9 – Charging additional refrigerant Insulating the Pipes The temperatures at both the liquid side and gas side will be low during cooling so in order to prevent Figure of Single condensation, be sure to insulate the pipes at both of these sides. Insulate the pipes separately for the liquid side and gas side.
  • Page 11: Electrical Work

    How to wire Electrical work 1. Remove the terminal cover by taking off the mounting screw (1 piece). 2. Connect the power supply wires and Indoor/Outdoor connecting wires to the terminal block of the electrical Wiring between indoor unit CAUTION control box.
  • Page 12: Earthing

    – 11 – Earthing Air conditioner operating conditions For proper performance, operate the air conditioner under the following temperature conditions: WARNING Cooling operation Dry bulb temp. –15°C to 46°C Be sure to connect the earth wire. Heating operation Wet bulb temp. –15°C to 15°C Incomplete earthing may cause an electric shock.
  • Page 13 Refrigerant recovery Steps taken to recover the refrigerant 1. Operate the indoor unit in the fan mode. When recovering the refrigerant in situations such as when relocating an indoor unit or outdoor unit, the recovery 2. Check that the LED displays are placed in their initial status. If not, place them in the initial status. operation can be performed by operating the SW01 and SW02 switches on the P.C.
  • Page 14 – 13 – Existing piping How to check the existing piping settings You can check whether the existing piping settings are enabled. The following settings are required when using a pipe Ø19.1 mm as the existing piping at the gas pipe side. 1.
  • Page 15: Troubleshooting

    Troubleshooting Appendix Work instructions You can perform fault diagnosis of the outdoor unit with the LEDs on the P.C. Board of the outdoor unit in addition 5. When a commercially available dryer is attached to to using the check codes displayed on the wired remote controller of the indoor unit. the existing pipes.
  • Page 16: Specifications

    Model Weight (kg) Is it possible to operate the existing air conditioner? Cooling Heating RAV-GM561ATP-E1 After the existing air conditioner is operated in RAV-GM561ATJP-E1 cooling mode for approx. 30 minutes or longer, * recover the refrigerant. * Under 70 dBA Refer to “12 Refrigerant recovery”.
  • Page 17 Declaration of conformity Declaration of conformity Manufacturer: Toshiba Carrier (Thailand) Co., Ltd. Manufacturer: Toshiba Carrier (Thailand) Co., Ltd. 144 / 9 Moo 5, Bangkadi Industrial Park, Tivanon Road, Tambol Bangkadi, 144 / 9 Moo 5, Bangkadi Industrial Park, Tivanon Road, Tambol Bangkadi,...
  • Page 18 – 17 – Warnings on refrigerant leakage To Fix the Fluorinated Fill in the label as follows: Greenhouse Gases Label Check of concentration limit This product contains fluorinated greenhouse gases. The room in which the air conditioner is to be installed requires a design that in the event of refrigerant Do not vent gases into the atmosphere.
  • Page 19: Installation Check List

    – 18 –...
  • Page 20 144 / 9 Moo 5, Bangkadi Industrial Park, Tivanon Road, Tambol Bangkadi, Amphur Muang, Pathumthani 12000, Thailand 1 1 2 4 1 5 3 6 0 1 A...
