M E D I U M V O LTA G E P R O D U C T S
VD4/R-VD4/L-VD4/R-SEC-VD4/L-SEC
Installation and operating instructions
12...24 kV - 630...1250 A - 12...25 kA

Table of Contents

I.
3
3
4
5
6
7
8
21
23
26
27
31
32
39
