- Page 1 (English) UM-6T80A-007 User's Manual Shift Lever (2-WAY RELEASE) https://si.shimano.com...
-
Page 2: Table Of Contents
Contents IMPORTANT NOTICE..................3 Important safety information ................ 4 Notice....................... 5 Regular inspections before riding the bicycle ..........6 Names of parts ....................7 How to operate....................8 How to operate (RAPIDFIRE PLUS MONO lever)......... 10... -
Page 3: Important Notice
A dealer's manual for professional and experienced bicycle mechanics is available on our website ( https://si.shimano.com For safety, be sure to read this user's manual thoroughly before use, follow it for correct use, and store it so that it can be referenced at any time. -
Page 4: Important Safety Information
Important safety information Important safety information Do not disassemble or modify the product. This may cause the product to not operate correctly, and you may suddenly fall and be seriously injured. -
Page 5: Notice
Notice Notice Be sure to keep turning the crank arm during the lever operation. Products are not guaranteed against natural wear and deterioration from normal use and aging. For maximum performance we highly recommend SHIMANO lubricants and maintenance products. -
Page 6: Regular Inspections Before Riding The Bicycle
Regular inspections before riding the bicycle Regular inspections before riding the bicycle Before riding the bicycle, check the following items. If any problems are found, consult your place of purchase or a distributor. Is gear shifting carried out smoothly? Are the levers securely installed to the handlebar? Do any abnormal noises occur during operation? Is the lever pad free from abnormal wear, excess play, and other abnormalities? (For models where a pad is attached to the lever.) -
Page 7: Names Of Parts
Names of parts Names of parts Front Rear Lever B Lever B Lever A Lever A RAPIDFIRE PLUS MONO lever Lever C Crank arm... -
Page 8: How To Operate
How to operate How to operate Gear shifting operation Be sure to keep turning the crank arm during the lever operation. Caution on operation After gear shifting is completed, both levers A and B return to their initial position. Right-hand lever operation The number of sprocket shifts depends on the lever stroke. - Page 9 How to operate Lever B initial position Gears can be shifted by pushing or pulling the lever. Some models have two-step gear shifting. Example: From the 4th to 3rd sprocket Left-hand lever operation Lever A: Shifts from the smallest to the largest chainring side Lever A initial position Lever B: Shifts from the largest to the smallest chainring side Lever B initial position...
-
Page 10: How To Operate (Rapidfire Plus Mono Lever)
How to operate (RAPIDFIRE PLUS MONO lever) How to operate (RAPIDFIRE PLUS MONO lever) Operate with one lever. Gear shifting operation Be sure to keep turning the crank arm during the lever operation. RAPIDFIRE PLUS MONO lever operation Lever C-1: Shifts from the smallest to largest chainring Lever C * After shifting, the lever is kept in position C-2. - Page 11 One Holland, Irvine, California 92618, U.S.A. Phone: +1-949-951-5003 High Tech Campus 92, 5656 AG Eindhoven, The Netherlands Phone: +31-402-612222 3-77 Oimatsu-cho, Sakai-ku, Sakai City, Osaka 590-8577, Japan Please note: specifications are subject to change for improvement without notice. (English) © Feb. 2022 by SHIMANO INC. ITP...
