Appendix 3: Expander Numbers For Reporting Expander Trouble; Keypads; Remote Power Supply Nx-320E; Wireless Receiver Nx-448E - GE NetworX NX-8-EUR Installation Manual

A
PPENDIX
The tables below list the device numbers that will be reported for each expander/keypad where a trouble condition
is present. For trouble conditions relating to the control panel, the device number is "0".

Keypads

KEYPAD PART 1
1 192
2 200
3 208
4 216
5 224
6 232
7 240
8 248

Remote power supply NX-320E

Power supply
1
2
3
4
5
6
7
8

Wireless receiver NX-448E

Wireless receiver
1
2
3
4
5
6
7
8
NX-8-EUR Installation manual
3: E
XPANDER NUMBERS FOR REPORTING
EXPANDER TROUBLE
PART 2 PART 3
193 194
201 202
209 210
217 218
225 226
233 234
241 242
249 250
DIP 1 DIP 2 DIP 3
OFF OFF OFF
ON OFF OFF
OFF ON OFF
ON ON OFF
OFF OFF
ON OFF
OFF ON
ON ON
DIP 1 DIP 2 DIP 3
OFF OFF OFF
ON OFF OFF
OFF ON OFF
ON ON OFF
OFF OFF
ON OFF
OFF ON
ON ON
Page 110
PART 4 PART 5
195 196
203 204
211 212
219 220
227 228
235 236
243 244
251 252
Expander number
reported
84
85
86
87
ON 88
ON 89
ON 90
ON 91
Expander number
reported
35
36
37
38
ON 39
ON 32
ON 33
ON 34
PART 6 PART 7
197 198
205 206
213 214
221 222
229 230
237 238
245 246
253 254
PART 8
199
207
215
223
231
239
247
255
02/07/06
