TOSHIBA CMOS Digital Integrated Circuit Silicon Monolithic
Single-Chip DTS Microcontroller (DTS-21)
The TC9349AFG is a single-chip DTS microcontroller for portable audio
incorporating a 30 MHz prescaler, PLL, and LCD driver. In addition to an
IF counter, serial interface and buzzer function, the device incorporates an
interrupt function, timer counter, pulse counter, electronic volume function
and A/D converter
The device also supports selection of 1/4-duty 1/2 bias or 1/4-duty 1/3
bias for the LCD driver, while a built-in 3 V voltage doubler boosting
circuit implements stable operation of the LCD monitor.
The power supply voltage ranges from 0.9 V to 1.8 V. Due to its
low-current consumption, the device is suitable for use in digital tuning
systems in portable equipment such as headphone stereos.
Features
•
CMOS DTS microcontroller LSI with built-in prescaler PLL and LCD driver
•
Operating voltage range:
•
Current dissipation:
•
Operating temperature range:
•
Program memory (ROM):
•
Data memory (RAM):
•
Oscillator frequency:
•
Instruction execution time:
•
Interrupt:
•
Interrupt stack:
•
Address stack:
•
I/O port:
•
LCD driver:
•
Serial Interface:
•
Buzzer:
•
Timer counter:
•
Pulse counter:
•
Electronic volume:
•
A/D converter:
•
Amplifier for LPF:
•
DC/DC converter of VT:
TC9349AFG
VDD = 0.9 to 1.8 V (typ.: 1.5 V)
With CPU in operation: IDD = 150 µA (typ.)
With PLL in operation: IDD = 1 mA (typ. At inputting OSCin = 30 MHz)
Ta = −10 to 60°C
16-bit × 8192 steps
4-bit × 512 words
Crystal oscillator:
75 kHz (crystal oscillator)
High-speed oscillator: 300 to 600 kHz (ceramic oscillator or crystal oscillator)
Crystal oscillator: 40 µs
High-speed oscillator: 5 to 10 µs
External: 2 system (INTR1, INTR2 pin)
Internal:
4 system (serial-interface, timer-port, timer-counter, decreased voltage
detection)
4 level × 26 bit G-register, Data select, Carry flag, Data register
16 level × 13 bit (program counter)
CMOS I/O port: 36 (max)
N-ch open-drain I/O port: 9 (max)
Exclusive output port: 2 (max), exclusive input port: 1 (max)
1/4 duty, 1/2 bias or 1/4 duty, 1/3 bias: 72 segments (max)
1 system, 2 channel (N-ch open-drain, CMOS I/O port), 3 kinds (3-wired, 2-wired,
UART)
4 kinds of frequency (1 kHz, 1.56 kHz, 2.08 kHz, 3 kHz),
4 modes (continuous, single-shot, 10 Hz intermittent, 10 Hz intermittent 1 Hz interval)
8 bit, 2 kinds of timer clock (25 kHz, 1 kHz),
2 modes (timer counter, pulse width measure (INTR1 pin))
8 bit up/down counter
2 channel, 32 step (0 dB to −78 dB, −∞dB)
6 bit, 4 channel, conversion time: 240 µs
5.5 V output max. (Tout, Tin)
2 stage (0.75 V, 1.0 V) voltage detected (VDET)
15 kinds of doubler clock, 2 types of doubler clock output
(CMOS output: DDCK2, N-ch output: DDCK1)
1
TC9349AFG
Weight: 0.32 g (typ.)
2006-02-24
