QUARTZ DIGITAL
User's Manual V1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRX Digital and is the answer not in the manual?

Questions and answers

Related Manuals for Tissot PRX Digital

Summary of Contents for Tissot PRX Digital

  • Page 1 QUARTZ DIGITAL User’s Manual V1.0...

  • Page 2: Table Of Contents

    Contents CONTENTS HOME ............................. DATE ............................T1 ............................T2 ............................LAP............................SPLIT............................TIMER ............................. AL ............................OTHER ............................ Light ....................................Sound .................................... Standby..................................Battery................................... 2 / 19 24.07.2023...

  • Page 3: Home

    HOME HOME Welcome to your QUARTZ DIGITAL watch manual Functions Setting Forward Validating START/STOP Light Backward Sound Reset Standby START/STOP Battery Splits Push-button press time Single press SPLIT Pressed for more than 0.5 second 0.5" Pressed for more than 3 seconds 3"...
  • Page 4 HOME General setting procedure All settings are made using the same process. Select the function Enter setting mode 3"  The whole screen flashes once Adjust the value Confirm and exit setting mode 4 / 19 24.07.2023...

  • Page 5: Date

    DATE DATE Setting Select DATE Enter setting mode 3"  The whole screen flashes once, then the year is displayed and flashes Adjust the value Confirm the selection and move on to the next setting  The month flashes Adjust the value Confirm the selection and move on to the next setting  The day flashes...
  • Page 6 DATE Display the date temporarily In time display mode, you can temporarily display the date Press once  The screen displays the date After 5 seconds, it reverts to time display mode 6 / 19 24.07.2023...
  • Page 7 Setting the time, setting the primary time The time can be displayed in 12- or 24-hour mode Setting Select T1 Enter setting mode 3"  The whole screen flashes once, then the hour flashes Adjust the value Confirm and move on to the next setting  The minutes flash Adjust the value Confirm and move on to the next setting...
  • Page 8 Confirm and move on to the next setting Select 12- or 24-hour display mode Confirm and exit setting mode 8 / 19 24.07.2023...
  • Page 9 Secondary time setting (second time zone) Setting Select T2 Enter setting mode 3"  The whole screen flashes once, then the hour flashes Adjust the value Confirm and move on to the next setting  The minutes flash Adjust the value  Move forward or backward +/-15 minutes Confirm and exit setting mode  The seconds cannot be set and are always identical 24.07.2023...

  • Page 10: Lap

    Timing in LAP mode (lap time) Information The LAP function is a chronometer designed to measure the lap time in a running race or motor race. For example: measuring the lap time taken for a long-distance runner. Measurement range Maximum measurement time 100 days Measurement resolution (less than 1 hour) 1/100''...
  • Page 11 Display the first recorded time  After 2 seconds, the time is displayed Press again to display the next time  Press twice to go directly to the next time  After 20 seconds, the display returns to the total time Resetting the chronograph to zero  Resetting the current timing to zero deletes the stored data 3"...

  • Page 12: Split

    SPLIT SPLIT Timing in SPLIT mode (split times) Information The SPLIT function is a chronometer for measuring the total duration of a race for up to 99 runners or vehicles participating in the same timed event. For example: measuring the finish time for several runners in a 100-metre sprint. Measurement range Maximum measurement time 100 days...
  • Page 13 SPLIT Display the first recorded time  After 2 seconds, the time is displayed Press again to display the next time  Press twice to go directly to the next time  After 20 seconds, the display returns to the total time Resetting the chronograph to zero  Resetting the current timing to zero deletes the stored data 3"...

  • Page 14: Timer

    TIMER TIMER The TIMER function enables you to start a countdown of up to 23  hours 59  mins 59 secs. Setting Select TIMER Enter setting mode 3"  The whole screen flashes once, then the hour flashes Adjust the value Confirm and move on to the next setting  The minutes flash Adjust the value Confirm and move on to the next setting...
  • Page 15 TIMER Adjust the value Confirm and exit setting mode 24.07.2023 15 / 19...
  • Page 16 The watch is equipped with an alarm function that beeps at the set time. How it works At the set time (relative to T1), a beep will sound for 30 seconds, and the display will flash until the alarm is cleared. General information •...
  • Page 17 Adjust the value Confirm and exit setting mode  The alarm is activated Clearing the alarm Press any push-button  The alarm remains active for the next set alarm time (see deactivation below). Activating/deactivating the alarm Select AL Press to deactivate the alarm  The alarm is deactivated Press again to reactivate the alarm 24.07.2023...

  • Page 18: Other

    OTHER OTHER Light Illuminating the display Press to light up the display 0.5" Light duration: 5 seconds  Pressing any push-button extends the illumination time  When the light is on, the sound is off Sound Activation/deactivation Press the 2 push-buttons simultaneously to activate or deactivate the sound.
  • Page 19 Tissot SA Customer Service Chemin des Tourelles 17 CH-2400 Le Locle Switzerland Tel.: +41 32 933 31 33 www.tissotwatches.com...
