INSTALL YOUR
CUPHOLDER
Item # CH-2000/CH-2000R
a.
1
Remove cupholder from container.
Unscrew adjustment knob to
disassemble all parts. Attach the
inner clamp with flange facing
down (Figure 1).
3
Wrap the flexible clamp around the
inner clamp and insert the screw
through the square cutout in the
flexible clamp and through the
other side (Figure 3).
HOW TO
a. (1) Cupholder
b. (1) Adjustment knob
c. (1) Screw
Figure 1
Figure 3
WHAT'S IN THE BOX
d. (1) Flexible clamp
b.
2
Insert the screw through hole
inside the cupholder. The head of
the screw should be flush against
the inside (Figure 2).
4
Tighten the adjustment knob onto
the screw until the cupholder is
secured to tube (Figure 4).
No tools required
Quick installation
Easy to follow
step-by-step
with inner clamp
c.
*Updated January 25, 2017
instructions
d.
Figure 2
Figure 4
Advertisement
Related Manuals for Nova CH-2000
Summary of Contents for Nova CH-2000
- Page 1 HOW TO INSTALL YOUR No tools required Quick installation Easy to follow step-by-step CUPHOLDER instructions Item # CH-2000/CH-2000R WHAT’S IN THE BOX a. (1) Cupholder d. (1) Flexible clamp b. (1) Adjustment knob with inner clamp c. (1) Screw Figure 1 Figure 2 Remove cupholder from container.
- Page 2 WARNING Read all instructions carefully before use. Failure to do so may result in serious injury. NOVA Medical Products shall have no liability for any damage or injury resulting from improper use of this product. CAUTION: To avoid scratching or cuts, DO NOT allow the end of the screw to be exposed from the back of the adjustment knob.
