- Page 1 60cm/80cm LAM2304 Canopy Cooker Hood LAM2305 User Instructions and Installation ISSUE v2 130422 www.howdens.com/appliance-registration...
- Page 2 www.howdens.com...
-
Page 3: Table Of Contents
Welcome Dear Customer Congratulations on your choice of LAMONA Throughout this manual the domestic appliance. following symbols are used. • Please read these instructions before use to ensure safe and economical operation of Important the appliance. information or useful • Please keep these instructions in a safe hints and tips, place for your future reference. -
Page 4: Warning And Safety Information
Warning and Safety information Please read these instructions. The General safety manufacturer is not responsible if an incorrect installation and use causes injuries and/or This product is not intended to be used by damage. Always keep the instructions with the persons with physical, sensory or mental cooker hood for future reference. -
Page 5: Children And General Safety
Warning and Safety information Children and general safety Waste Electrical and Electronic Equipment (WEEE) Electrical products can be dangerous to children. Keep children away from the product when it is operating and do not allow them to symbol for waste electrical and play with or near the product. -
Page 6: Cooker Hood Overview
1. Cooker hood overview Cooker hood body Fixing clips Cooker hood fascia Control panel Lights Control panel overview Lamp On/Off/Speed www.howdens.com... -
Page 7: Installation
2. Installation Methods of extraction The very best method of clearing the kitchen of unwanted odours is by connecting the appliance to an exhaust duct and venting to the outside atmosphere via the ceiling or an Extraction via exhaust ducting Extraction via recirculation (vented outside) (vented internally) - Page 8 On opening the packaging, remove and identify each component part. Carefully place each part on a clean, scratch free surface. Do not component parts. Main hood body Fascia panel 8/10x 20mm Round head screw 4x 15mm Round head screw www.howdens.com...
-
Page 9: Installing The Cooker Hood
Installing the cooker hood This instruction must be strictly adhered to. Failure to comply could result in overheating and serious damage to your appliance. It is recommended that the installation is carried out by two people. We strongly advise that the extractor outlet slatting. - Page 10 Extraction via recirculation (vented Internally) Either can be used for recirculation (vented outside) *Any cut edges should be sealed with a water proof varnish or PVA. LAM2304 60cm = 497mm LAM2304 60cm = 497mm LAM2305 80cm = 677mm LAM2305 80cm = 677mm 13mm 13mm...
- Page 11 Installing the cooker hood 70cm or greater cabinets only. 13mm 37mm 4x 50mm Countersunk screw 13mm 37mm 4x 50mm Countersunk screw Exclusive to Howdens...
- Page 12 Installing the cooker hood panel is attached with magnets. (80cm cabinet illustrated, 60cm cabinet similar.) Fitting Option 1; Fit cooker hood body into cooker hood cabinet Ensure side supports snap into place, tighten screws to secure. Fitting Option 2; into cooker hood cabinet using screws supplied.
- Page 13 Installing the cooker hood Secure fascia panel to cooker hood. 4x 15mm Countersunk screw DO NOT: Exclusive to Howdens...
-
Page 14: Electrical Connection
Electrical connections IMPORTANT: Ensure that the electricity IMPORTANT: The wires in the mains lead are supply is switched off before connecting. coloured in accordance with the following code:- Blue.....Neutral Brown....Live and securely held in place or a cable grid is Green/ Yellow..Earth back into the motor cavity. -
Page 15: Operating The Cooker Hood
3. Operating the cooker hood Control panel Lamp On/Off/Speed Lamp; Slide button to switch on or off. On/Off/Speed; Slide the speed button to select fan speed 0-off 1-low 2-mid 3-high. 4. Care and Maintenance Before cleaning or attempting any type The manufacturer declines all liability in cases of maintenance, always make sure that the where the instructions for the appropriate... - Page 16 three months or sooner depending on the type of cooking being performed. should be washed regularly using a neutral detergent. to crockery and kitchen utensils. thoroughly dried before reinstalling on the hood. (Illustration shows a generic application, other installations are similar.) 1.
-
Page 17: Replacing Lamps
Replacing lamps will give many years of reliable service. In the used during operation of the cooker hood. They should not be left on permanently and used as a main lighting source. The cooker hood is for domestic use only. LED Candle Thermal Plastic Only use 4W 4000K... -
Page 18: Problem Solving
5 - Problem solving PROBLEM SOLVING Symptoms Possible cause Solutions • Switch off the cooker hood and allow it to cool down and the fuse will auto reset. Light functions but • Motor temperature has exceeded and the fan does not. thermal fuse has tripped. -
Page 19: Guarantee
• Your full contact details. Call the Depot number on your Proof of Purchase Document supplied with the product/kitchen. Call the LAMONA Service Line on: Within UK 0344 460 0006 Within Republic of Ireland 01525 5703 * Product installed within a domestic kitchen or a non-domestic kitchen where 8 or fewer people are using the appliance. - Page 20 Product serial number REPRISE À DÉPOSER À DÉPOSER À LA LIVRAISON EN MAGASIN EN DÉCHÈTERIE Cet appareil se recycle Points de collecte sur www.quefairedemesdechets.fr Privilégiez la répara�on ou le don de votre appareil! Howden Joinery Ltd. Thorpe Road, Howden, East Yorkshire. DN14 7PA Imported in EU by: Howdens Cuisines SAS.
Need help?
Do you have a question about the LAM2304 and is the answer not in the manual?
Questions and answers
What is the recommended installation height from a induction hob
I **** installing a Lamona 2304 unit. As it is recirculating and has filters, the instructions show the need to cut a hole in the cabinet. Does this mean that ducting is also needed to be attached even though it is recirculating?
No, the Lamona LAM2304 unit does not require ducting if it is used in recirculation mode with filters, as it vents internally.
This answer is automatically generated
Hi, in recirculation mode we’ve fitted the 2 carbon filters, do we still fit the 2 part v flaps on the top or is that section capped off if so how do we cap it?
