Bosch Active Line Original Operating Instructions page 69

English – 2
Product description and
specifications
Intended Use
The Bosch eBike batteries of the smart system generation
of systems are intended exclusively for the power supply of
your drive unit of the smart system generation of systems
and must not be used for any other purpose.
Product features
The numbering of the components shown refers to the illus-
trations on the graphics pages at the beginning of the
manual.
All representations of bicycle parts, apart from the eBike
batteries and their holders, are schematic and may differ
from those on your own eBike.
In addition to the functions shown here, changes to software
relating to troubleshooting and functional modifications may
be introduced at any time.
(1) Key for the battery lock
(2) Battery lock
(3) PowerTube battery safety hook
(4) PowerTube battery (pivot)
(5) Socket for charging connector
(6) Status/battery charge indicator
(7) On/off button
Technical data
Li-ion battery
Product code
Product code
Rated voltage
Nominal capacity
Energy
Operating temperature
Storage temperature
Permitted charging temperature
range
Weight, approx.
Protection rating
Li-ion battery
Product code
Rated voltage
Nominal capacity
Energy
0 275 007 3PX | (07.02.2023)
CompactTube
400
Hori- BBP3240
zontal BBP3242
Ver- BBP3241
tical BBP3242
V= 36
Ah 11
Wh 400
°C –5 to +40
°C +10 to +40
°C 0 to +40
kg 2.0
IP55
PowerPack
Frame 400
BBP3540
V= 36
Ah 11.1
Wh 400
(8) PowerTube battery safety restraint
(9) Locking mechanism
(10) Pull strap
(11) Guide rail
(12) PowerTube battery (axial)
(13) Upper holder for PowerTube (axial)
(14) Upper holder for PowerPack battery
(15) PowerPack battery
(16) Lower holder for PowerPack battery
(socket without charging option)
(17) Lower holder for PowerPack battery
(socket with charging option)
(18) Charger
(19) Charging socket cover
(20) CompactTube battery (pivot)
(21) CompactTube battery (axial)
(22) Safety restraint
CompactTube battery (pivot)
(23) Safety restraint
CompactTube battery (axial)
(24) CompactTube unlocking element
(25) CompactTube holding element
(26) Rack-mounted battery holder
(27) Rack-mounted battery
a) Designs may vary
PowerTube 500 PowerTube 625 PowerTube 750
BBP3750
BBP3751
36
13.4
500
–5 to +40
+10 to +40
0 to +40
3.0
IP55
PowerPack
Frame 545
BBP3551
36
14.4
545
a)
BBP3760 BBP3770
BBP3761 BBP3771
36
16.7
625
–5 to +40 –5 to +40
+10 to +40 +10 to +40
0 to +40 0 to +40
3.6
IP55
PowerPack PowerPack
Frame 725 Frame 800
BBP3570 BBP3580
36
19.2
725
Bosch eBike Systems
36
20.1
750
4.3
IP55
36
22.2
800
67
