- Page 1 BLCE 7203 Benutzer- und Wartungshandbuch User and maintenance manual Manuel d'utilisation et d'entretien Handleiding voor gebruik en onderhoud...
- Page 3 IMPORTANT SAFETY INSTRUCTIONS YOUR SAFETY AND THAT OF OTHERS IS VERY IMPORTANT This manual and the appliance itself provide important safety warnings, to be read and observed at all times. This is the danger symbol, pertaining to safety, which alerts users to potential risks to themselves and others. All safety warnings are preceded by the danger symbol and the following terms: Indicates a hazardous situation which, if not avoided, will cause serious injury.
- Page 4 - If the surface of the induction plate is cracked, do not use it and switch off the appliance to avoid the possibility of electric shock (only for models with induction function). - Do not touch the appliance with any wet part of the body and do not operate it when barefoot.
- Page 5 - Do not use containers made of synthetic materials. - Overheated oils and fats catch fire easily. Always remain vigilant when cooking foods rich in fat and oil. - Never leave the appliance unattended during food drying. - If alcoholic beverages are used when cooking foods (e.g. rum, cognac, wine), remember that alcohol evaporates at high temperatures.
- Page 6 GENERAL RECOMMENDATIONS Before use: Remove cardboard protection pieces, protective film and adhesive labels from accessories. Remove the accessories from the oven and heat it at 200° for about an hour to eliminate the smell and fumes from the insulating materials and protective grease. During use: Do not place heavy objects on the door as they could damage it.
- Page 7 AFTER-SALES SERVICE Before calling the After-Sales Service: See if you can solve the problem yourself with the help of the suggestions given in the “Troubleshooting guide“. Switch the appliance off and back on again it to see if the fault persists. If after the above checks the fault still occurs, get in touch with the nearest After-sales Service.
- Page 8 MAINTENANCE Use protective gloves. WARNING Ensure the oven is cold before carrying out the following operations. Disconnect the appliance from the power supply. REMOVING THE DOOR To remove the door: Open the door fully. Lift the catches and push them forwards as far as they will go (fig. 1). Close the door as far as it will go (A), lift it up (B) and turn it (C) until it is released (D) (fig.
- Page 9 REPLACING THE OVEN LAMP To replace the rear lamp (if present): Disconnect the oven from the power supply. Unscrew the lamp cover (Fig. 9), replace the lamp (see note for lamp type) and screw the lamp cover back on. Reconnect the oven to the power supply. To replace the side lamp (if present): Disconnect the oven from the power supply.
- Page 10 INSTRUCTIONS FOR OVEN USE FOR ELECTRICAL CONNECTION, SEE THE PARAGRAPH ON INSTALLATION Control panel Upper heating element/grill Cooling fan (not visible) Dataplate (not to be removed) Light Circular heating element (not visible) Turnspit (if present) Bottom heating element (not visible) 10.
- Page 11 INSERTING WIRE SHELVES AND OTHER ACCESSORIES IN THE OVEN The wire shelf and other accessories are provided with a locking mechanism to prevent their accidental removal. Fig. 1 Insert the wire shelf horizontally, with the raised part “A” upwards (Fig. 1). Angle the wire shelf when it reaches the locking position “B”...
- Page 12 DESCRIPTION OF DISPLAY A. Display of heating elements activated during the various cooking functions B. Time management symbols: timer, cooking time, end of cooking time, time C. Information regarding selected functions D. Automatic BREAD/PIZZA function selected Indication of door locked during automatic cleaning cycle (pyro-cleaning) Internal oven temperature G.
- Page 13 FAST PREHEATING Turn the “Functions” knob to the symbol to select the fast preheating function. Confirm by pressing : the settings are shown on the display. If the proposed temperature is that desired, press button . To change the temperature, proceed as described in previous paragraphs.
- Page 14 TIMER This function can be used only with the oven switched off and is useful, for example, for monitoring the cooking time of pasta. The maximum time which can be set is 23 hours and 59 minutes. With the “Functions” knob at zero, turn the “Browse” knob to display the desired time. Press button to start the countdown.
- Page 15 BREAD/PIZZA FUNCTION SELECTION Turn the “Functions” knob indicator to the symbol to access a submenu containing two automatic cooking functions for “bread” and “pizza”. Bread Turn the “Functions” knob to symbol : the display shows “BREAD” and AUTO at the side. Press to select the function.
- Page 16 FUNCTION DESCRIPTION TABLE FUNCTION SELECTOR KNOB To stop cooking and switch off the oven. LAMP To switch the oven interior light on/off. To speed up defrosting of food. Place food on the middle shelf. Leave food in its packaging in order to prevent it from drying out on the outside. DEFROST For keeping just-cooked food hot and crisp (e.g: meat, fried food or flans).
- Page 17 FUNCTION SELECTOR KNOB (Continued) To grill steak, kebabs and sausages; to cook vegetables au gratin and toast bread. Place food on the 4th or 5th shelf. When grilling meat, use the drip GRILL tray to collect the cooking juices. Position it on the 3rd/4th shelf, adding approx.
- Page 18 COOKING TABLE Recipe Function Pre- Shelf (from Temp. Time Accessories and notes heating bottom) (°C) (min) 160-180 30-90 Cake tin on wire shelf Shelf 4: cake tin on wire Leavened cakes shelf 160-180 30-90 Shelf 1: cake tin on wire shelf Drip tray/baking tray or 160-200...
- Page 19 Recipe Function Pre- Shelf (from Temp. Time Accessories and notes heating bottom) (°C) (min) 180-190 40-55 Cake tin on wire shelf Meat & potato pies Shelf 4: cake tin on wire (vegetable pie, shelf 180-190 45-60 quiche lorraine) Shelf 1: cake tin on wire shelf 190-200 20-30 Drip tray / baking tray...
- Page 20 Recipe Function Pre- Shelf (from Temp. Time Accessories and notes heating bottom) (°C) (min) Drip tray or oven tray on wire shelf (turn food two Leg of lamb / Shanks 2 (Medium) 60-90 thirds of the way through cooking if necessary) Drip-tray / baking tray (if necessary, turn food two...
- Page 21 TESTED RECIPES (in compliance with IEC 60350-1:2011-12 and DIN 3360-12:07:07) Recipe Function Pre- Shelf (from Temp. Time Accessories and notes heating bottom) (°C) (min) IEC 60350-1:2011-12 § 7.5.2 15-25 Drip tray / baking tray Shortbread Shelf 4: baking tray 25-40 Shelf 1: drip tray/baking tray IEC 60350-1:2011-12 §...
- Page 22 RECOMMENDED USE AND TIPS How to read the cooking table The table indicates the best function to use for any given food, to be cooked on one or more shelves at the same time. Cooking times start from the moment food is placed in the oven, excluding pre-heating (where required).
- Page 24 Printed in Italy 02/2012 5019 400 00756 Copyright Whirlpool Europe s.r.l. 2010. All rights reserved...
