- Page 1 DocuPrint C1110/C1110B Service Manual 1st Edition...
- Page 3 This service manual is issued intending use by maintenance service personnel authorized by CAUTION Important changes including FUJI XEROX Co. Ltd. Copying, transferring or revisions of spare part leasing this manual without prior consent by numbers and adjustment FUJI XEROX Co. Ltd. is prohibited.
- Page 4 Company Name Department Name Telephone No. Full Name Employee No.
- Page 5 Introduction Getting to know the Service Manual How to use the Service Manual Terms and Symbols Abbreviations Chapter 1 Service Call Procedure Chapter 2 Troubleshooting Chapter 3 Image Quality Troubleshooting Chapter 4 Repairs and Adjustments Chapter 5 Parts List Chapter 6 General Chapter 7 Wiring Data Chapter 8 Accessories Chapter 9 BSD (Block Schematic Diagram) Not yet...
- Page 7 Preface...
-
Page 8: Table Of Contents
Preface Table of Contents Table of Contents Getting to know the Service Manual .............. Preface-1 How to use the Service Manual ..............Preface-1 Contents of Manual ......................Preface-1 Information on Updating ....................Preface-2 Terms and Symbols ..................Preface-3 Abbreviations ....................Preface-4... -
Page 9: Getting To Know The Service Manual
Introduction 1. Getting to know the Service Manual Getting to know the Service Manual This manual is used as the standard service manual for the DocuPrint C1110/C1110B. • Publication Comment Sheet Enter any comments and/or corrections regarding the DocuPrint C1110/C1110B service manual into the Publication Comment Sheet, and send it to FX/CSS/IBS through the OpCo TS or CS department. -
Page 10: Information On Updating
Additional Memory Chapter 9 BSD (Block Schematic Diagram) (Not yet issued) Chapter 10 Machine Overview This chapter gives an overview of the functions of the main components of DocuPrint C1110/ C1110B. Information on Updating This manual will be revised and sent to each customer engineer as specified below. Revisions must be incorporated correctly to keep the manual up-to-date. -
Page 11: Terms And Symbols
Safety Critical Components (SCC) Control of the safety of components that are designated Safety Critical Components shall conform to Fuji Xerox Co. Ltd-stipulated rules and regulations on Safety Critical Components. Important Information Stored Component (ISC) Important Information Stored Components store customers’ important information they have entered after machine installation. -
Page 12: Abbreviations
Introduction 4. Abbreviations Abbreviations Abbreviations This manual contains abbreviations that are specific to this manual, as well as general abbreviations, which include: Automatic Density Control Mag. Roll Analog Ground Machine Control Unit Auto Paper Select Marks On Belt Auto Registration Control Motor ASSY Assembly... - Page 13 Chapter 1 Service Call Procedure...
- Page 14 Chapter 1 Service Call Procedure Table of Contents Table of Contents 1.1 Before Starting the Servicing ..................1-1 1.1.1 Safety ............................. 1-1 1.1.2 Notes on the Handling of Customer Information ..............1-2 1.1.3 Other Things to Note ......................1-3 1.2 Servicing Call Procedure ..................1-4 1.3 TRIM Servicing ......................1-5 1.3.1 TRIM Servicing Procedure .....................
-
Page 15: Before Starting The Servicing
Chapter 1 Service Call Procedure 1.1 Before Starting the Servicing Before Starting the Servicing 1.1.1 Safety To prevent any accident that may occur during maintenance servicing, any WARNING or CAUTION regarding the servicing must be strictly observed. Do not perform any hazardous operation. 1. -
Page 16: Notes On The Handling Of Customer Information
Chapter 1 Service Call Procedure 1.1 Before Starting the Servicing 1.1.2 Notes on the Handling of Customer Information 1. Handling electronic customer information such as copy/print/received Fax samples (paper information) and log files (activity report, etc.). When taking samples back to your base for the purpose of investigation/analysis, obtain consent from the customer without fail. -
Page 17: Other Things To Note
• Record the service details and the consumables and parts replaced at visit in the Machine Service Log. DocuPrint C1110/C1110B weighs 18kg. Always have 2 people available to move the printer. Refer to the Installation Procedures for details. -
Page 18: Servicing Call Procedure
Chapter 1 Service Call Procedure 1.2 Servicing Call Procedure Servicing Call Procedure 1. Ask the operator(s) about the machine condition. 2. Record the billing meter readings. Initial Actions 3. Inspect any printing error, then check the machine. 4. Check the Service Log. 1. -
Page 19: Trim Servicing
Chapter 1 Service Call Procedure 1.3 TRIM Servicing TRIM Servicing TRIM Servicing for DocuPrint C1110/C1110B is performed in all SM/UM to maintain the performance of the machine. Independent visits for TRIM Servicing does not take place. 1.3.1 TRIM Servicing Procedure 1. -
Page 20: Machine Consumables And Periodic Replacement Parts
Chapter 1 Service Call Procedure 1.3 TRIM Servicing 1.3.2 Machine Consumables and Periodic Replacement Parts • Check the total number of copies printed during TRIM Servicing before replacing the machine consumables. Machine Consumables Product Name Country Product Code Expected yield AP/Korea/Taiwan CT201114 2kPV...
