Securam SafeLogic TopLit EC-0601A-PL Series Operating Instructions

Table of Contents

Download this manual

SafeLogic TopLit Series Operating Instructions

This manual is for the SafeLogic TopLit Series EC-0601A-PL series EntryPad used in conjunction

with EL-0601, EL-0701, or EL-0801 lock bodies.

Important:

● For indoor use only.

● Battery Low Voltage: 5.2 ± 0.2V. Repeated beeping (8 beeps) during an unlock

operation indicates that the battery is low and needs immediate replacement.

PLEASE REPLACE THE BATTERY IMMEDIATELY.

Battery Replacement Instructions

The safe lock system is powered by (1) 9V alkaline battery. The battery is housed inside the

EntryPad.

Follow the steps below to replace the battery.

Turn the housing ring counterclockwise until it cannot move

(about 20°), then pull it off from the entrypad base. See Fig.2.

Doc.No.:PLU-EC0601APL201222

Version No.: V1.01 USER

Table of Contents

Do you have a question about the SafeLogic TopLit EC-0601A-PL Series and is the answer not in the manual?

Page 1 Doc.No.:PLU-EC0601APL201222 Version No.: V1.01 USER SafeLogic TopLit Series Operating Instructions This manual is for the SafeLogic TopLit Series EC-0601A-PL series EntryPad used in conjunction with EL-0601, EL-0701, or EL-0801 lock bodies. Important: ● For indoor use only. ● Battery Low Voltage: 5.2 ± 0.2V. Repeated beeping (8 beeps) during an unlock operation indicates that the battery is low and needs immediate replacement.
Page 2 2. Push the battery from the bottom left side of the entrypad and unsnap the battery from the connecter. See Fig.3. 3. Snap a new 9V alkaline battery onto the battery clip and put it back into the compartment by pushing it from the right side. Note: Tuck the cable into the the compartment and make sure the cable does not get caught in the housing ring.
Page 3 press within 10 seconds. Standby status is indicated by two short beeps. 6. Automatic Re-lock The safe lock system automatically relocks after 6 seconds of being opened by a valid code. 7. Low Battery Alert a) Repeated beeping (8 beeps) during an unlock operation indicates that the battery is low and needs immediate replacement.
Page 4 Working Humidity (max): <90% Code Length: 6 Digits Mechanical System Life Span: >10,000 Cycles (UL requirement) >100,000 Cycles (SECURAM design criteria) SECURAMÏ Systems Inc. U.S.A.
