- Page 1 UPS2000-G-(1 kVA–3 kVA) Battery Pack Quick Guide Issue Date 2022-05-23 HUAWEI DIGITAL POWER TECHNOLOGIES CO., LTD.
- Page 2 Notice The purchased products, services and features are stipulated by the contract made between Huawei Digital Power Technologies Co., Ltd. and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information, and recommendations in this document are provided "AS IS"...
-
Page 3: About This Document
Indicates a potentially hazardous situation which, if not avoided, could result in equipment damage, data loss, performance deterioration, or unanticipated results. NOTICE is used to address practices not related to personal injury. Issue 05 (2022-05-23) Copyright © Huawei Digital Power Technologies Co., Ltd. - Page 4 China. 2016-05-15 Updated the documentation. 2015-10-12 Added the 2 kVA UPS battery pack. 2015-08-10 Updated the battery pack dimensions. 2015-06-25 The issue is the first official release. Issue 05 (2022-05-23) Copyright © Huawei Digital Power Technologies Co., Ltd.
-
Page 5: Table Of Contents
4.1 Connecting Battery Packs to a 1 kVA UPS........................13 4.2 Connecting Battery Packs to a 2 kVA UPS........................14 4.3 Connecting Battery Packs to a 3 kVA UPS........................15 A Acronyms and Abbreviations..................... 17 Issue 05 (2022-05-23) Copyright © Huawei Digital Power Technologies Co., Ltd. -
Page 6: Safety Information
Do not transport the equipment by holding the mounting ears, front panel, or wiring port covers. Move the equipment in compliance with the corresponding requirements. Figure 1-1 shows the transportation rules. Figure 1-1 Transportation rules Issue 05 (2022-05-23) Copyright © Huawei Digital Power Technologies Co., Ltd. -
Page 7: Appearance And Characteristics
Figure 2-1 Appearance and external ports of the standard battery pack (ESS-96V12-9AHBPVBB02) for the 3 kVA UPS with long backup time (1) DC port 1 (2) DC port 2 (3) Protection switch Issue 05 (2022-05-23) Copyright © Huawei Digital Power Technologies Co., Ltd. -
Page 8: Characteristics
● Panel material: plastic ● Rear panel color: gray (SECC/SGCC) ● Dimensions (H x W x D): 88 mm x 438 mm x 410 mm ● Weight: 17.3 kg Issue 05 (2022-05-23) Copyright © Huawei Digital Power Technologies Co., Ltd. -
Page 9: Kva Ups Battery Pack
● Panel material: plastic ● Rear panel color: gray (SECC/SGCC) ● Dimensions (H x W x D): 88 mm x 438 mm x 410 mm ● Weight: 21.7 kg Issue 05 (2022-05-23) Copyright © Huawei Digital Power Technologies Co., Ltd. -
Page 10: Kva Ups Battery Pack
● Panel material: plastic ● Rear panel color: gray (SECC/SGCC) ● Dimensions (H x W x D): 88 mm x 438 mm x 510 mm ● Weight: 28.9 kg Issue 05 (2022-05-23) Copyright © Huawei Digital Power Technologies Co., Ltd. - Page 11 UPS2000-G-(1 kVA–3 kVA) Battery Pack Quick Guide 2 Appearance and Characteristics Graphics of the Interior Figure 2-4 ESS-96V12-9AHBPVBB02 or ESS-96V12-9AHBPVBB02-C battery pack interior Issue 05 (2022-05-23) Copyright © Huawei Digital Power Technologies Co., Ltd.
-
Page 12: Installing A Battery Pack
Do not use battery packs of different models together. For details, see the nameplate on the enclosure. The following figures are for reference only. Figure 3-1 Same model Figure 3-2 Different models Issue 05 (2022-05-23) Copyright © Huawei Digital Power Technologies Co., Ltd. -
Page 13: Unpacking And Checking
Appearance, Specifications, and Name Multimeter Phillips screwdriver Flat-head Torque (PH2 x 150 mm, screwdriver (2 screwdriver PH3 x 250 mm) mm x 80 mm) Wire stripper Insulation tape Cotton cloth Heat-shrink tubing Issue 05 (2022-05-23) Copyright © Huawei Digital Power Technologies Co., Ltd. -
Page 14: Procedure
3.3 Procedure Battery packs of rack-mounted UPSs can either be rack-mounted or tower- mounted. 3.3.1 Rack-mounted Installation Procedure Step 1 Install mounting ears. Step 2 Install the battery pack. Issue 05 (2022-05-23) Copyright © Huawei Digital Power Technologies Co., Ltd. -
Page 15: Tower-Mounted Installation
The recommended torque for tightening the screws is 3 N·m. ----End 3.3.2 Tower-mounted Installation Procedure Step 1 Remove the front panel. Step 2 Adjust the battery pack panel as shown in the following figure. Issue 05 (2022-05-23) Copyright © Huawei Digital Power Technologies Co., Ltd. - Page 16 UPS2000-G-(1 kVA–3 kVA) Battery Pack Quick Guide 3 Installing a Battery Pack Step 3 Adjust the Huawei logo and reinstall the front panel. Step 4 Assemble the support base and extension kit. NO TE The support base installed here is the standard configuration of the UPS. The standard configuration of the battery pack contains only the extension kit.
- Page 17 3 Installing a Battery Pack Step 5 Install the battery pack. NO TE The assembled UPS and battery pack are 300 mm deep in total. Step 6 Complete the installation. ----End Issue 05 (2022-05-23) Copyright © Huawei Digital Power Technologies Co., Ltd.
-
Page 18: Connecting Battery Packs To A Ups
● Before connecting cables, ensure that the circuit breakers on the battery packs are OFF. Issue 05 (2022-05-23) Copyright © Huawei Digital Power Technologies Co., Ltd. -
Page 19: Connecting Battery Packs To A 2 Kva Ups
● Before connecting cables, ensure that the circuit breakers on the battery packs are OFF. Issue 05 (2022-05-23) Copyright © Huawei Digital Power Technologies Co., Ltd. -
Page 20: Connecting Battery Packs To A 3 Kva Ups
● Before connecting cables, ensure that the circuit breakers on the battery packs are OFF. Issue 05 (2022-05-23) Copyright © Huawei Digital Power Technologies Co., Ltd. - Page 21 UPS2000-G-(1 kVA–3 kVA) Battery Pack Quick Guide 4 Connecting Battery Packs to a UPS Figure 4-3 Connection between the ESS-96V12-9AHBPVBB02 or ESS-96V12-9AHBPVBB02-C battery packs and a UPS Issue 05 (2022-05-23) Copyright © Huawei Digital Power Technologies Co., Ltd.
-
Page 22: A Acronyms And Abbreviations
UPS2000-G-(1 kVA–3 kVA) Battery Pack Quick Guide A Acronyms and Abbreviations Acronyms and Abbreviations uninterruptible power system Issue 05 (2022-05-23) Copyright © Huawei Digital Power Technologies Co., Ltd.
