SoC-FPGA Design Guide [DE0-Nano-SoC Edition]
examine the details of pin J18, to which
connected to 4 sources:

TRACE_D5

SPIS1_MOSI

CAN1_TX

HPS_GPIO54
This can be seen in Qsys, as shown in Figure 9-5.
Depending on how you configure the Peripheral Pins tab, you can configure pin J18 to use any of the sources
above. For example, if you want to use this pin as an SPI slave control signal, you would use the configuration
shown in Figure 9-6.
However, if you don't want to use any of the peripherals available at the top of the Peripheral Pins tab, then
you can always use one of the 2 buttons on the right side of Figure 9-5:

GPIOXY: Configures the pin to be connected to the HPS' GPIO peripheral.

LOANIOXY: Configures the pin to be connected to the FPGA fabric. This pin can be exported from
Qsys to be used by the FPGA.

9.3.1.2.2 Configuration

16. We want the HPS to directly control the
pins J18 and A20 to the HPS' GPIO peripheral.

Click on the

Click on the
"HPS_KEY_N"
17. We want to connect to our DE0-Nano-SoC with an SSH connection later in the tutorial, so we need to
enable the Ethernet MAC interface.

Configure
in Figure 9-7.

Click on the
"HPS_ENET_INT_N"
03/10/2018
"HPS_KEY_N"
Figure 9-5. HPS_KEY_N & HPS_LED on Qsys Peripheral Pins Tab
Figure 9-6. Using Pin G21 for SPI
"HPS_KEY_N"
button. This corresponds to pin A20, which is connected to
"GPIO53"
button. This corresponds to pin J18, which is connected to
"GPIO54"
.
to
"EMAC1 pin" "HPS I/O Set 0"
button. This corresponds to pin B14, which is connected to
"GPIO35"
.
P a g e
is connected. The schematic shows that pin G21 is
and
"HPS_LED"
and the
"EMAC 1 mode"
| 33
pins. To do this, we will connect
"HPS_LED"
to , as shown
"RGMII"
.
