A r n o l d
Monitor 44cm, 100/120HZ
Maintenance Instructions
Monitor 44cm, 100/120HZ
Monitor 44 cm, 100/120 Hz
The protocol SPR2-230.105.01.02.02 is required for
these instructions
Print No.:
SPR2-230.101.01.02.02
Replaces: SPR2-230.101.01.01.02
01102628
SP
1998
© Siemens AG
The reproduction, transmission or use
of this document or its contents is not
permitted
without
express
authority. Offenders will be liable for
damages. All rights, including rights
created by patent grant or registration
of a utility model or design, are
reserved.
English
Doc. Gen. Date: 08.05
written
Advertisement
Table of Contents
Related Manuals for Siemens 30 64 581 B5310
Summary of Contents for Siemens 30 64 581 B5310
- Page 1 Maintenance Instructions Monitor 44cm, 100/120HZ Monitor 44 cm, 100/120 Hz The protocol SPR2-230.105.01.02.02 is required for these instructions 01102628 1998 © Siemens AG The reproduction, transmission or use of this document or its contents is not permitted without express written authority.
- Page 2 Assemblers and other persons who are not employed by or otherwise directly affiliated with or authorized by Siemens or one of its affiliates are directed to contact one of the local offices of Siemens or one of its affiliates before attempting installation or service pro- cedures.
-
Page 3: Table Of Contents
Maintenance ............23 5 _______ Final result/quality inspection and maintenance _____________________ 24 6 _______ Changes to Previous Version_____________________________________ 25 Siemens AG SPR2-230.101.01.02.02 Monitor 44cm, 100/120HZ... -
Page 4: Requirements
Requirements These maintenance instructions apply to the 100/120 Hz standard monitor, part number 30 64 581 B5310. The monitor is a component of the system or system configuration. Maintenance for these systems or system configurations should be performed in accordance with the cor- responding maintenance instructions. -
Page 5: Required Documents
Required documents • Safety information according to ARTD, part 2 • Maintenance protocol SPR2-230.105.01.. • System binder for the system or system configura- tion Siemens AG SPR2-230.101.01.02.02 Monitor 44cm, 100/120HZ Page 5 of 26 Medical Solutions 08.05 CS PS 24... -
Page 6: Required Tools, Measurement And Auxiliary Devices
Set of Allen keys* • Protective conductor tester Safety tester UNIMRT 1100 51 38 727 • Luminance meter SPOTMETER for SM fit ACT 77 52 848 Monitor 44cm, 100/120HZ SPR2-230.101.01.02.02 Siemens AG Page 6 of 26 08.05 CS PS 24 Medical Solutions... -
Page 7: Emphasized Text
Fig. 1: Safety Notes Siemens AG SPR2-230.101.01.02.02 Monitor 44cm, 100/120HZ Page 7 of 26 Medical Solutions 08.05... -
Page 8: Safety Information And Protective Measures
TD00-000.860.01... must be complied with. CAUTION Electrical voltage! Non-compliance can result in material damage. When working on the system, ESD regulations must be observed. Monitor 44cm, 100/120HZ SPR2-230.101.01.02.02 Siemens AG Page 8 of 26 08.05 CS PS 24 Medical Solutions... -
Page 9: Radiation Safety Information
Perform the required work with special care and atten- tion to detail. If needed, wear work gloves. Siemens AG SPR2-230.101.01.02.02 Monitor 44cm, 100/120HZ Page 9 of 26 Medical Solutions 08.05... -
Page 10: Safety Information - Risk Of Infection
The protective conductor resistance of 0.1 ohms between the ground contact of the unit plug and the touchable conductive unit parts may not be exceeded. Monitor 44cm, 100/120HZ SPR2-230.101.01.02.02 Siemens AG Page 10 of 26 08.05 CS PS 24 Medical Solutions... -
Page 11: Information On Measuring The System Leakage Current
For the purpose of traceability, reference to the new report is to be written on the old report. The reason for newly determining the first measured value is to be documented and confirmed with a name and signature. Siemens AG SPR2-230.101.01.02.02 Monitor 44cm, 100/120HZ Page 11 of 26 Medical Solutions 08.05... - Page 12 Measuring circuit for measuring the system leakage current according to the differential current method in compliance with DIN VDE 0751-1:2001-10, Fig. C6 for protection class Monitor 44cm, 100/120HZ SPR2-230.101.01.02.02 Siemens AG Page 12 of 26 08.05 CS PS 24 Medical Solutions...
- Page 13 Document the measuring procedure (differential measurement or direct measurement) and the measuring device used (designation and serial number). In the case of repeat measurements, the measured value is also to be evaluated. Siemens AG SPR2-230.101.01.02.02 Monitor 44cm, 100/120HZ Page 13 of 26 Medical Solutions 08.05...
- Page 14 2.5 mA is not exceeded. The evaluation is not necessary in the case of a new determination. File the report sheet in the system folder or log book. Monitor 44cm, 100/120HZ SPR2-230.101.01.02.02 Siemens AG Page 14 of 26 08.05 CS PS 24 Medical Solutions...
-
Page 15: Descriptions Of Abbreviations
The sequence for complete maintenance and inspection is de- scribed on the following pages. Each work step must be performed on an annual basis, if not oth- erwise specified. Siemens AG SPR2-230.101.01.02.02 Monitor 44cm, 100/120HZ Page 15 of 26 Medical Solutions 08.05... -
Page 16: Maintenance Interval
General information Maintenance interval 12 months Monitor 44cm, 100/120HZ SPR2-230.101.01.02.02 Siemens AG Page 16 of 26 08.05 CS PS 24 Medical Solutions... -
Page 17: Inspection Of Exterior
Inspection of exterior and surroundings Inspection of exterior and surroundings Inspection of exterior Damage Inspect the monitor for damage, e.g. to the housing or to the finish. Siemens AG SPR2-230.101.01.02.02 Monitor 44cm, 100/120HZ Page 17 of 26 Medical Solutions 08.05... -
Page 18: Inspection Of Surroundings
Inspect the power outlet for damage. Line voltage • Measure the line voltage and compare this value to the line voltage for the monitor. Monitor 44cm, 100/120HZ SPR2-230.101.01.02.02 Siemens AG Page 18 of 26 08.05 CS PS 24 Medical Solutions... -
Page 19: Mechanical Safety
Ensure that all required warning labels are attached and in good condition. Replace any illegible labels. ID labels • Ensure that all required ID labels are attached and in good condition. Replace any illegible labels. Siemens AG SPR2-230.101.01.02.02 Monitor 44cm, 100/120HZ Page 19 of 26 Medical Solutions 08.05... -
Page 20: Electrical Safety
- even if the limit value of 0.2 ohms is not exceeded. (Protective conductor or contacts) Leakage current Monitor 44cm, 100/120HZ SPR2-230.101.01.02.02 Siemens AG Page 20 of 26 08.05 CS PS 24 Medical Solutions... - Page 21 Document the measuring procedure (differential measurement or direct measurement) and the measuring device used (designation and serial number). • In the case of repeat measurements, the measured value is also to be evaluated. Siemens AG SPR2-230.101.01.02.02 Monitor 44cm, 100/120HZ Page 21 of 26 Medical Solutions 08.05...
- Page 22 (damaged insulation, damage caused by water ingress or humidity, defective interference suppressor, etc.) - even if the limit value of 0.5 mA is not exceeded. Monitor 44cm, 100/120HZ SPR2-230.101.01.02.02 Siemens AG Page 22 of 26 08.05 CS PS 24 Medical Solutions...
-
Page 23: Maintenance
Remove the light-proof cover from the ambient sensor. • Shine a light on the ambient sensor. The luminance in the white field must reach the val- ue >400 cd/m Siemens AG SPR2-230.101.01.02.02 Monitor 44cm, 100/120HZ Page 23 of 26 Medical Solutions 08.05... - Page 24 This test is part of system maintenance and should be performed at the end of system maintenance. The image quality test does not need to be performed twice. Monitor 44cm, 100/120HZ SPR2-230.101.01.02.02 Siemens AG Page 24 of 26 08.05 CS PS 24...
- Page 25 Changes to Previous Version Changes to Previous Version Document was converted to DMS. Siemens AG SPR2-230.101.01.02.02 Monitor 44cm, 100/120HZ Page 25 of 26 Medical Solutions 08.05 CS PS 24...
- Page 26 Changes to Previous Version Monitor 44cm, 100/120HZ SPR2-230.101.01.02.02 Siemens AG Page 26 of 26 08.05 CS PS 24 Medical Solutions...
