Viper 4+ with 600S
Operation Manual
Revised 10/18/2019
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Viper 4+ and is the answer not in the manual?

Questions and answers

Related Manuals for Raven Viper 4+

Summary of Contents for Raven Viper 4+

  • Page 1 Viper 4+ with 600S Operation Manual Revised 10/18/2019...

  • Page 2: Table Of Contents

    Viper 4+ with 600S Setup Manual Section Description Page Reference (common instructions) Spraying with Scout Groups Running a Self Test Remote Support Mapping with a Viper File Manager Appendix A (Field Boundary naming and colors) Appendix B (Error Messages) Appendix C (Common Widgets)

  • Page 3: Reference (Common Instructions)

    Section 1 Reference: Pages The Viper 4+ Field Computer functions similarly to an iPad or other computer where you can swipe across multiple pages. For the purpose of this manual we will refer to page number starting with page 1 as the first page on the left and numerically increasing for each page to the right.

  • Page 4: Spraying With Scout Groups

    Section 2 Spraying with Scout Groups Make sure you have the correct tractor selected. Click Start Job icon Touch the generic Job Name to rename your spray job. Turflux recommends naming spray jobs for better reference later. Click on the label with the generic name to the right of ‘Job Name’...
  • Page 5 Next you will need to enter your application rate. Click on the button under the Rate Mode to enter the rate. Enter your desired rate on the number pad, and then hit the Green Check to save it. Double check your Job Name, Scout Group, and Application Rate.
  • Page 6 Verify that all of the switches shown on your ‘On Screen Switch Box’ widget are set to Accu. Your sprayer has also been equipped with an individual mechanical Master Switch. Be sure that this switch is turned on and you are now ready to spray. (Note: The Master Switch is also an easy way to turn everything off, even while operating in an active Job, and back on when ready to continue.)

  • Page 7: Running A Self Test

    Section 3 Running a Self Test (Note: You need to be in a Job to run a self test.) Touch and hold the GPS Status widget. The GPS Status (Health) screen will open up. Touch the number field to the right of ‘Test Speed’ near the bottom left of the GPS Health screen.

  • Page 8: Remote Support

    Section 4 Remote Support There are 2 ways to access Remote Support. If you are not in an active Job you can access Remote Support by touching ‘Administrator at the top of your screen. (If you are in an active Job—see below) Touch the ‘System Manager’...
  • Page 9 A Service Code will be displayed in the Remote Support area of the screen. You may need to provide this number to Raven or Turflux personnel for them to access your screen. Remote Support (while in a Job) If you are already in an active Job you can access Remote Support by touching and holding the ‘Slingshot...

  • Page 10: Mapping With A Viper

    Section 5 Mapping with a Viper Mapping is best done by antenna position. Change to the Mobile Mapping configuration before you start mapping. Hit the current machine icon (top left), or if the Mobile Mapping configuration is already selected skip ahead to Start your mapping Job (see below) Choose the Mobile Mapping configuration to highlight the icon.
  • Page 11 If you are adding boundaries to an existing group, touch the Active Group name and select the existing group, or hit the Plus Sign (+) to the right of Active Group to start a new group. If you are entering a new Active Group (using the plus sign), you will be prompted to enter name for scout group, otherwise if using an existing group skip to the next step.
  • Page 12 While recording your widget changes to a stop, pause button. You can pause at any point on the boundary you are making and then restart again at a point further along the boundary. Restarting will create a straight line from the point where you paused and the point where you restart.

  • Page 13: File Manager

    Section 6 File Manager Copying and deleting files such as Scout Groups, Jobs, or Screenshots is done through the File Manager First click on Administrator at the top of your screen. Click on the File Manager icon After a Viper 4+ has been in use for a while there may be many files stored in memory so you may wish to filter your selection before copying or deleting files.
  • Page 14 The files shown on the right hand side are the ones that can now be copied or deleted. To copy files to a USB, insert the USB in one of the USB ports on the side of the Viper, and then click on the folder icon with and arrow pointing out, at the top of the right column.
  • Page 15 Once the files have been successfully copied to your USB you will get a ‘Transfer Complete’ message. Click ‘OK’ Deleting Files (Before deleting files you may want to copy them to a USB drive, using the procedure above, in case you accidentally delete a file you may still need.) If you are deleting the files you have selected (and moved to the right hand column) you will click on the...

  • Page 16: Appendix A (Field Boundary Naming And Colors)

    Appendix A Field Boundary naming and color format CAUTION: Regardless of whatever format you use to name your Field Boundaries, it is best to avoid symbols in the field boundary name. Sometimes symbols can cause issues when copying and backing up your files. (Turflux recommendation) 1.

  • Page 17: Appendix B (Error Messages)

    Appendix B - Error Messages These are typical error messages that you may encounter with an explanation as to how they occur and what to do when they do occur. Forward Direction Cannot be Determined This message you can just hit “Ignore” Reverse Alarm sounds or displays on screen You should have a Reverse Sensing widget on your screen.

  • Page 18: Appendix C (Common Widgets)

    Appendix C Common Widgets Typical Sprayer Screen Widget Seq Name Screen Scouting (Scout Group) Forward Override GPS Status (Health) Vehicle Speed AccuBoom Override Section Status Widest On-screen Switch Box Liquid Pressure Product Levels Tally Registers Individual Product Control Slingshot Connection Status (remote support)
