Samsung HG43Q60AAAJ Quick Setup Manual

Quick Setup Guide
To register this product please visit www.samsung.com
1. List of Parts
• The provided accessories may vary depending on the model.
1 2
Samsung Smart Remote Power Cable
4 5
Data Cable Antenna adapter
3 43"
50-75"
NOTE
• Make sure to distinguish between the front and back of each component when assembling them.
• Make sure that at least two persons lift and move the TV.
2. Installing the LED TV Stand
Assembling the Stand and Components
When installing the stand, use the provided components and parts.
-01
Stand
3
1
Warranty Card / Quick Setup Guide /
Regulatory Guide
(Not available in some locations)
• Place a soft cloth over the table to protect the TV, and then place the TV so that its screen faces down toward the
table surface.
3. The Connection Panel
BACK OF TELEVISION
SPEAKER
Volume Control Box
USB
HDD
LAN
ARC
DATA
LAN
ANT IN
2
Holder-Cable
25 mm
• Insert the Stands into the slot on the bottom of the TV.
• Slide and assemble it to the end line in the direction of arrow.
4. Connecting the antenna adapter
Connect the provided antenna adapter to an antenna terminal on the wall, and then connect the antenna cable, which is
connected to ANT IN on the TV, to the antenna adapter.
The connected antenna adapter prevents overload that may occur due to potential difference between the antenna
terminal on the wall and the antenna cable, consequently being able to prevent product damage or fire.
• Be sure to use the provided antenna adapter.
• The method for connecting the antenna adapter and the markings on the antenna terminals may differ depending on
• If you use the antenna adapter where antenna signals are weak, the screen may become blurry.
O
the model and geographical region.
