3.4

LAN, IPMI and UID LEDs

On the rear of the device, there are two LAN ports, one IPMI port and one UID LED. Each LAN
port as well as the IPMI port has two LEDs.
LED
LAN 1/LAN 2
LED on the
right
LAN 1/LAN 2
LED on the
left
IPMI LED on
the right
IPMI LED on
the left
UID LED
2022-10 | V02 | F.01U.407.903
LED state Description
Green flashing Indicates HDD activity.
Solid red Indicates HDD failure.
Red flashing (1 Indicates HDD re-build and hot spare.
Hz)
Red flashing (4 Identify the HDD from a remote location through IPMI.
Hz)
LED state Description
Amber flashing Indicates LAN activity.
Solid green Indicates a bandwidth of 100 Mbps.
Solid amber Indicates a bandwidth of 1 Gbps.
Off Indicates a bandwidth of 10 Mbps.
Amber flashing Indicates activity.
Solid green Indicates a bandwidth of 100 Mbps.
Solid amber Indicates a bandwidth of 1 Gbps.
Blinking blue Remote UID is on.
(300 msec) Use this indication to locate the unit from a remote
location through IPMI interface.
